Omron NJ-PA3001 — front face showing the green PWR LED and AC input marking

Omron NJ-PA3001 — 30 W AC Power Supply for NJ

SKU: NJ-PA3001

USD 70.00

AC power supply for NJ/DX-series controller racks. 100-240 VAC input, 5 VDC at 6 A and 24 VDC at 1 A, 30 W, RUN output.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NJ-PA3001 is the AC-input power supply for the NJ/DX-series machine controllers. It accepts a single-phase 100-240 VAC feed and delivers 5 VDC at 6.0 A and 24 VDC at 1.0 A, for 30 W total. The unit sits in the supply slot of the CPU rack and provides the bus power the controller and the I/O units need. It also includes a RUN output contact that closes while the CPU is in RUN status, and a green PWR LED for local status.

Why it is the first choice for NJ panels

The NJ-PA3001 is the supply Omron ships against the NJ CPU for cabinets fed from 100-240 VAC. It is compatible with NJ-series CPU racks and expansion racks, and it also powers the DX-series CPU rack. Choose the PD3001 instead only when the cabinet already has a regulated 24 VDC rail and you want to skip the AC step.

Pick AC or DC input

Both NJ-PA3001 and NJ-PD3001 share the same 5 VDC and 24 VDC outputs to the rack, so they are interchangeable from the I/O side. The decision is the cabinet feed. Use NJ-PA3001 with single-phase AC, and NJ-PD3001 with 24 VDC. Allow at least 120 VA on the AC feed and size the upstream 24 V supply for 60 W when the PD version is used.

Before ordering

Add the 5 VDC and 24 VDC current for every I/O unit planned on the rack, and confirm the totals stay within 6 A and 1 A. Check the wire and breaker ratings for the measured supply voltage, especially at 85 VAC low-line. Leave space around the vented housing and follow the temperature and derating notes in the datasheet.

Key Features

  • Dedicated AC supply for NJ/DX-series CPU racks
  • 100-240 VAC wide-range input
  • 5 VDC at 6 A and 24 VDC at 1 A outputs
  • 30 W total output
  • RUN output contact that mirrors CPU status
  • Green PWR indicator on the front
  • Screw-terminal connection on M4 self-raising posts
  • SKU: NJ-PA3001
  • Series: NJ / DX
  • Voltage: 100-240 VAC
  • I/O: 100 I/O

Best-Fit Applications

  • Main supply for NJ-series CPU racks in AC-fed control cabinets
  • Power source for NJ/DX-series controller racks in AC-fed cabinets
  • Replacement supply for failed NJ-PA3001 modules in installed panels
  • Control power for packaging, material-handling, and assembly machines
  • New NJ builds that will use CJ-series expansion racks

Buying Checklist

  • Confirm the cabinet feed is single-phase AC within 100-240 VAC.
  • Check the planned 5 VDC and 24 VDC loads against 6 A and 1 A limits.
  • Choose NJ-PD3001 instead when the cabinet has a regulated 24 VDC rail.
  • Confirm the RUN output wiring before energising the controller.
  • Check upstream protection supports the 120 VA inrush at low-line voltage.
  • Allow for airflow space around the vented housing and derate for high temperature.

Technical Specifications

Series NJ / DX
Compatible Controller NJ-series CPU and expansion racks
Input Voltage 100-240 VAC, 50/60 Hz (allowable 85-264 VAC)
Power Consumption 120 VA max.
Inrush Current 20 A / 8 ms at 100 VAC; 40 A / 8 ms at 200 VAC
Output Voltage (Logic) 5 VDC, 6.0 A
Output Voltage (Service) 24 VDC, 1.0 A
Total Output Power 30 W max.
RUN Output SPST-NO contact; 250 VAC 2 A resistive, 24 VDC 2 A resistive
Connection M4 screw terminals
Operating Temperature 0 to 55 °C
Dimensions (W × H × D) 70 × 90 × 90 mm

FAQ for NJ-PA3001

What is the difference between NJ-PA3001 and NJ-PD3001?
The two are the same 30 W supply for NJ/DX racks but with different inputs. NJ-PA3001 accepts 100-240 VAC at 120 VA; NJ-PD3001 accepts 24 VDC at 60 W. Both deliver 5 VDC at 6 A and 24 VDC at 1 A to the rack. Choose by the cabinet feed rather than by the I/O load.
Can NJ-PA3001 also power CJ-series expansion racks?
Yes. When the NJ CPU rack already has an NJ-PA3001, an NJ expansion rack can use the same supply to keep one feed for the whole controller. Confirm the CJ-series expansion rack uses the matching I/O control and interface units listed in the NJ manuals.
Does the NJ-PA3001 have a remote alarm output?
It has a RUN output that closes while the CPU is in RUN status. It is not a low-voltage or maintenance alarm, and there is no maintenance-forecast display on this model. Wire it to a status light, an interlock, or a higher-level PLC input that needs to know the CPU is running.
