Omron NJ101-9000 — front face of the Sysmac NJ1 CPU showing the four status LEDs (PWR / RUN / ERR / PRPHL) at the top, the rotary dipswitch cover for node-address setting, the 7-segment 5-digit LED display, the USB programming port under the sliding cover, the SD memory card slot and the NJ101-9000 type label

Omron NJ101-9000 — NJ1 CPU, 3 MB, EtherCAT

SKU: NJ101-9000

USD 680.00

Omron NJ101-9000 Sysmac NJ1 CPU, 3 MB program memory, built-in EtherCAT and EtherNet/IP, no motion axes. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NJ101-9000 is the Sysmac NJ1-series entry-level machine automation controller CPU, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

It runs sequence control programs out of 3 MB of program memory, with 0.5 MB of retained variable memory and 2 MB of non-retained variable memory. Up to 2,560 local I/O points (8,960 with NX-series remote I/O) and 40 Units total per CPU across 3 Expansion Racks. Primary task cycle time is 1 ms.

Three built-in ports handle EtherCAT master (up to 64 slave nodes), EtherNet/IP (10 / 100 BASE-TX), and USB programming. An SD memory card slot supports data logging and project backup. Programming is in Sysmac Studio with IEC 61131-3 languages. The 2-axis motion variant is the NJ101-1000. The 16-axis high-end CPU is the NJ501-1300.

Key Features

  • Sysmac NJ1 CPU with 3 MB program memory, 0.5 MB retained + 2 MB non-retained variable memory, 1 ms primary task
  • Built-in EtherCAT master for up to 64 slave nodes, EtherNet/IP, USB programming, SD card slot
  • 2,560 local I/O points (8,960 with NX-series remote I/O), 40 Units total per CPU, 3 Expansion Racks
  • Sequence control only, no motion axes; ladder, structured text, function block programming in Sysmac Studio
  • SKU: NJ101-9000
  • Series: Sysmac NJ1-series machine automation controller (entry-level sequence CPU)
  • I/O: 2 I/O

Best-Fit Applications

  • Line control on a conveyor cell where the NJ101-9000 sequence-controls 16 NX-OD5256 outputs and 32 NX-ID4442 inputs without motion
  • Data logging cell where the NJ101-9000 polls 4 E6C2-CWZ6C 1024P-R 2M encoders over EtherCAT and writes counts to the SD card
  • Spare replacement on a Sysmac NJ1 install where the original NJ101-1000 is swapped for the motion-less NJ101-9000 to free EtherCAT for I/O

Buying Checklist

  • Pick the NJ101-9000 for a Sysmac NJ1 entry-level sequence-control CPU with 3 MB program memory and built-in EtherCAT + EtherNet/IP.
  • Pick the NJ101-1000 instead when the cell needs 2 axes of point-to-point motion control in the same NJ1 entry-level form factor.
  • Pick the NJ501-1300 instead when the application needs 16 EtherCAT axes and 20 MB of program memory on the NJ5 high-end platform.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Sysmac NJ1-series machine automation controller (entry-level sequence CPU)
Model / SKU NJ101-9000
Program Memory 3 MB program memory, 0.5 MB retained variables (battery-backed), 2 MB non-retained variables
Task Cycle 1 ms primary task cycle time
I/O Capacity 2,560 local I/O points, 8,960 with NX-series remote I/O, 40 Units per CPU, 3 Expansion Racks
Motion / CNC / DB 0 motion axes, no CNC, no DB connection, no OPC-UA (sequence control only)
Built-in Ports EtherCAT master, EtherNet/IP (10 / 100 BASE-TX), USB programming, SD memory card slot
Programming Software Sysmac Studio with IEC 61131-3 languages (ladder, structured text, function block)
Current Draw 5 VDC at 1.90 A, 24 VDC at 0.22 A from the NJ-PA3001 (100-240 VAC) or NJ-PD3001 (24 VDC) PSU
Dimensions / Weight 90 (H) x 65 (D) x 80 (W) mm on the CPU Rack, approximately 280 g
Environment / Battery 0 to 55 C operating, 10 to 90 percent humidity (no condensation); battery CJ1W-BAT01, 5-year life at 25 C

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NJ101-9000

What is the Omron NJ101-9000 used for?
It is the Sysmac NJ1-series entry-level machine automation controller CPU. It runs sequence-control programs out of 3 MB of memory and talks to EtherCAT slaves and EtherNet/IP devices from the built-in ports. Typical uses are conveyor line control, data-logging cells, and any mid-size machine where motion axes are not needed.
NJ101-9000 vs NJ101-1000 - what is the difference?
Both belong to the Sysmac NJ1 entry-level family with 3 MB program memory, built-in EtherCAT and EtherNet/IP, and the same primary task cycle time. The NJ101-9000 has 0 motion axes; the NJ101-1000 has 2 axes of point-to-point motion control. Pick the -9000 for sequence-only cells; pick the -1000 when the machine needs 2 motion axes on the same entry-level CPU.
Can the NJ101-9000 connect to a CJ1W expansion rack?
Yes. The NJ101-9000 supports up to three CJ-series Expansion Racks via a CJ1W-IC101 I/O Control Unit on the CPU Rack and a CJ1W-II101 I/O Interface Unit on each Expansion Rack. The connecting cable is the CS1W-CN[]3 series.
What software programs the NJ101-9000?
Sysmac Studio. The NJ101-9000 supports IEC 61131-3 languages (ladder, structured text, function block) in Sysmac Studio version 1.02 or higher. CX-One and CX-Programmer do not program the Sysmac NJ/NX controllers; they program the legacy CS/CJ/CP families.
