Omron NJ301-1200 — 8-Axis Machine Controller
SKU: NJ301-1200USD 860.00
NJ Sysmac machine controller, 8 sync motion axes, 5 MB + 2.5 MB memory, EtherCAT master, EtherNet/IP, 0.5 ms cycle.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NJ301-1200 is the 8-axis variant of the NJ301-series Sysmac machine controller. It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
It carries 5 MB of program memory, 2.5 MB of variable memory, and a built-in EtherCAT master port plus a built-in EtherNet/IP port on the CPU itself. Up to 8 axes of motion control run synchronously with the primary task cycle (0.5 ms fastest selectable).
The NJ301-1200 remains the right pick when the cabinet must hold CJ1W I/O alongside modern EtherCAT servo drives. Key specs: Model NJ301-1200; Synchronous Axes 8 (15 axes including virtual); Program Memory 5 MB program + 2.5 MB variable memory; Primary Task Cycle 0.5 ms fastest (500 / 1000 / 2000 / 4000 us selectable); Built-in Ports EtherCAT master + EtherNet/IP + USB; EtherCAT Nodes Up to 192 nodes, ring topology supported; EtherNet/IP Connections Up to 32; Memory Card SD / SDHC card slot.
Key Features
- NJ-series Sysmac controller, 8 synchronous motion axes / 15 axes including virtual
- 5 MB program + 2.5 MB variable memory, 0.5 ms primary task cycle
- Built-in EtherCAT master (192 nodes, ring topology) + EtherNet/IP (32 connections)
- CJ-series Special I/O and CPU Bus units supported on the side bus
- SKU: NJ301-1200
- Series: NJ-series Sysmac machine controller
Best-Fit Applications
- Retrofit of a CJ2M application where the cabinet needs more axes than CJ2M-CPU35 offers.
- 8-axis pick-and-place line with EtherCAT 1S servo drives on a ring topology.
- Synchronous conveyor with flying-cut shear following the line encoder in 0.5 ms.
Buying Checklist
- Choose NJ101-1000 when the application is logic-only with no motion control.
- Choose NJ501-1500 when 16 axes of motion or robot kinematics are needed.
- Confirm the axis count - for 4-axis applications, pick NJ301-1100 to save budget.
Technical Specifications
| Model | NJ301-1200 |
|---|---|
| Series | NJ-series Sysmac machine controller |
| Synchronous Axes | 8 (15 axes including virtual) |
| Program Memory | 5 MB program + 2.5 MB variable memory |
| Primary Task Cycle | 0.5 ms fastest (500 / 1000 / 2000 / 4000 us selectable) |
| Built-in Ports | EtherCAT master + EtherNet/IP + USB |
| EtherCAT Nodes | Up to 192 nodes, ring topology supported |
| EtherNet/IP Connections | Up to 32 |
| Memory Card | SD / SDHC card slot |
| I/O Expansion | CJ1W Special I/O and CPU Bus units on the side bus |
| Programming | Sysmac Studio 1.0X or later |
| Dimensions | 90 x 96 x 150 mm, 530 g |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NJ301-1200
What is the difference between NJ301-1200 and NJ301-1100?
Both are NJ301-series Sysmac controllers with the same memory and CPU. The NJ301-1200 supports 8 synchronous motion axes (15 including virtual); the NJ301-1100 supports 4 synchronous axes. For applications that need more than 4 axes, the NJ301-1200 is the right pick.
Can the NJ301-1200 drive 1S-series servo drives?
Yes - the built-in EtherCAT master port talks to R88D-1SN-ECT and R88D-KN-ECT drives directly. The drives expose the CiA 402 profile, and Sysmac Studio's axis setup wizard configures the drive parameters without manual commissioning or DIP switches. The drives expose their parameters via the EtherCAT slave information file so commissioning does not require any drive-side software.
What programming software does the NJ301-1200 use?
Sysmac Studio version 1.0X or later. CX-Programmer and CX-One are not used for the NJ-series. Sysmac Studio includes the ladder, structured-text, and function-block editors plus the motion / cam / gearing setup wizard. Sysmac Studio also includes a built-in simulator for offline testing of the NJ301 project before going live on the shop floor.
How many EtherCAT nodes can the NJ301-1200 master drive?
Up to 192 EtherCAT slave nodes. The master supports cable ring redundancy, so a single cable break does not stop the line - the drives continue to communicate on the return path automatically after a break is detected. This is one less maintenance task to track on the machine's annual service checklist.
