Omron NJ501-1500 — Sysmac NJ5 CPU, 64 Axes
SKU: NJ501-1500USD 1590.00
Omron NJ501-1500 Sysmac NJ5 motion CPU, 20 MB, 64 axes, EtherCAT + EtherNet/IP. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NJ501-1500 is a Sysmac NJ5-series machine automation controller from the NJ platform, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The unit runs motion, logic and sequence control in a single CPU. Program memory is 20 MB and variable memory is 6 MB (2 MB retained plus 4 MB non-retained). The primary task cycle time is 0.5 ms and the controller runs up to 64 motion axes across 192 EtherCAT nodes.
Built-in ports are EtherCAT master, EtherNet/IP and USB. An OPC-UA server sits on the hardware. Supply is 5 V at 1.9 A from an NJ-PA3001 AC PSU or NJ-PD3001 DC PSU on the same rack. The body is 90 x 96 x 150 mm, 550 g, DIN-rail mounted. For 32 axes at the same 20 MB, pick the NJ501-1400.
Key Features
- Sysmac NJ5 motion + logic controller with 20 MB program and 6 MB variable memory
- 64 motion axes across 192 EtherCAT nodes, 0.5 ms primary task cycle
- Built-in EtherCAT + EtherNet/IP + USB with OPC-UA server on the hardware
- 5 V 1.9 A from NJ-PA3001 (AC) or NJ-PD3001 (DC), 90 x 96 x 150 mm, 550 g
- SKU: NJ501-1500
- Series: Omron Sysmac NJ5-series machine automation controller
- I/O: 40 I/O
Best-Fit Applications
- Multi-axis packaging line where the 64 axes cover the indexer, the wrapper and the case packer in one EtherCAT network
- Robotic pick-and-place cell where the 0.5 ms cycle time matches the vision system and the 192 EtherCAT nodes carry all servos and I/O
- Spare CPU drop-in for an existing NJ501-1500 cell where the Sysmac Studio project loads via the USB port and the EtherCAT topology stays the same
Buying Checklist
- Pick the NJ501-1500 for a Sysmac NJ5 CPU with 64 axes, 192 EtherCAT nodes and a built-in OPC-UA server.
- Pick the NJ501-1400 instead when the cell needs only 32 axes at the same 20 MB program memory.
- Pick the NJ501-1300 instead when the cabinet needs only 16 axes at the same 20 MB program memory.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron Sysmac NJ5-series machine automation controller |
| Model / SKU | NJ501-1500 |
| Controller Function | Motion control, sequence control, OPC-UA server |
| Program Memory | 20 MB |
| Variable Memory | 6 MB (2 MB retained + 4 MB non-retained) |
| Motion Axes | 64 axes max; 192 EtherCAT nodes max |
| Primary Task Cycle | 0.5 ms |
| Communication Ports | EtherCAT master, EtherNet/IP, USB 2.0 |
| I/O System | CJ-series I/O bus; up to 40 units across 3 expansion racks |
| Current Consumption | 5 VDC 1.9 A from rack PSU |
| Dimensions (W x H x D) | 90 × 96 × 150 mm; 550 g |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NJ501-1500
How many motion axes can the NJ501-1500 control?
Up to 64 motion axes and up to 192 total EtherCAT nodes in a single controller. The same controller also handles the sequence logic, so no separate PLC is needed for the I/O side.
Does the NJ501-1500 have a built-in OPC-UA server?
Yes. The OPC-UA server runs on the hardware and exposes variables to MES and SCADA clients over the EtherNet/IP port without a separate gateway. Security is handled with the standard OPC-UA certificate and user authentication.
What power supply does the NJ501-1500 need?
An NJ-PA3001 (100-240 VAC, 30 W) or NJ-PD3001 (24 VDC, 30 W) on the same rack. The CPU draws 5 V at 1.9 A. CJ-series power supplies cannot be used on an NJ-series rack.
Can the NJ501-1500 reuse CJ-series I/O?
Yes. Mount a CJ1W-IC101 I/O control unit on the NJ CPU rack and connect a CJ expansion rack with CS1W-CN223 or CS1W-CN713 cables. Existing CJ I/O and Special I/O units drop in without rewiring.
