Omron NJ501-1400 — NJ5 CPU, 32 EtherCAT Axes
SKU: NJ501-1400USD 1120.00
Omron NJ501-1400 Sysmac NJ5 CPU, 20 MB program memory, 32 EtherCAT axes, EtherNet/IP, 0.5 ms cycle. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NJ501-1400 is a Sysmac NJ5-series machine automation controller CPU, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NJ-series Robot Controller documentation.
It runs motion control, sequence control, and an OPC-UA server from a single program. The built-in EtherCAT master handles up to 32 servo axes (192 total EtherCAT nodes). The built-in EtherNet/IP port connects to HMIs and remote I/O. Primary task cycle time is 0.5 ms, with 20 MB of program and 6 MB of variable memory.
Programming is in Sysmac Studio (IEC 61131-3 plus CFC and structured text). The unit is 90 x 96 x 150 mm, 550 g. The NJ501-1300 sibling is the 16-axis version on the same body; the NJ501-1420 adds database connectivity (SQL client); the NJ501-1500 is the 64-axis version. The NJ301-1200 is the smaller 4-axis NJ3 CPU.
Key Features
- Sysmac NJ5-series machine automation controller, 20 MB program memory, 6 MB variable memory, 0.5 ms primary task cycle
- Built-in EtherCAT master handles up to 32 synchronous servo axes (192 total nodes) for Accurax G5 / 1S servo drives
- Built-in EtherNet/IP port, OPC-UA server, USB Type-B slave for Sysmac Studio programming, SD card slot for project transfer
- Up to 40 CJ-series expansion units (3 expansion racks, 2,560 I/O points) on the CJ I/O Bus; NX-series units require an NX-EIC/NX-EIC2 coupler plus CJ-series expansion units on the CJ I/O Bus, 90 x 96 x 150 mm DIN-rail body, 550 g
- SKU: NJ501-1400
- Series: Omron Sysmac NJ5-series machine automation controller (NJ501 family)
- I/O: 2560 points
Best-Fit Applications
- Motion controller on a 32-axis cartoning line running 1S servo drives over EtherCAT and reporting to a NA5 HMI
- Multi-station assembly cell where the NJ5 replaces a CJ2H plus a separate motion controller and consolidates into one Sysmac Studio project
- Spare replacement on a packaging line where the existing NJ501-1400 fails and the project loads directly from SD card to the new CPU
Buying Checklist
- Pick the NJ501-1400 for a Sysmac NJ5 CPU with 20 MB memory, 32 EtherCAT axes, and EtherNet/IP, with no safety.
- Pick the NJ501-1300 instead when the cabinet only needs 16 EtherCAT axes on the same Sysmac NJ5 platform.
- Pick the NJ501-1500 instead when the cell needs CIP-Safety (SL3) integrated safety on top of 64 EtherCAT axes on the same NJ5 body.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron Sysmac NJ5-series machine automation controller (NJ501 family) |
| Model / SKU | NJ501-1400 |
| Program / Variable Memory | 20 MB program memory, 6 MB variable memory, retentive variables held by replaceable CJ1W-BAT01 battery (5-year life at 25 C) |
| Primary Task Cycle | 0.5 ms (125 us / 250 us / 500 us / 1 ms / 2 ms / 4 ms / 8 ms selectable) |
| Motion Control | Up to 32 synchronous axes, 32 axes total including virtual axes, max 0 robots, electronic cam and gear |
| EtherCAT Master | Built-in, up to 192 nodes, DC sync supported for Accurax G5 and 1S servo drives |
| EtherNet/IP | Built-in 10/100 Mbps port for HMI / NS-series / NA-series / remote I/O / message communication, 32 CIP connections, 3,000 pps |
| OPC-UA / Function Blocks | OPC-UA server built in (DA profile, NJ501-1@00 family), function block library, structured text / ladder / CFC programming |
| Option Boards | Up to 2 CJ1W-IC101 I/O control units for serial (RS-232C / RS-422 / RS-485), DeviceNet, PROFIBUS, PROFINET, CompoNet, MODBUS |
| Local I/O | Up to 40 CJ-series expansion units (3 expansion racks, 2,560 I/O points) on the CJ I/O Bus; NX-series units require an NX-EIC/NX-EIC2 coupler (NX-EC, NX-EIC, NX-ILM, NX-AD, NX-DA, NX-OD, NX-ID series), plus CJ-series expansion on the CJ I/O Bus |
| Dimensions / Environment | 90 (W) x 96 (H) x 150 (D) mm, 550 g, 0 to +55 C operating, IP20, DIN-rail mount, CE / cULus / KC / Lloyd / NK listed, 1.90 A at 5 VDC |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NJ501-1400
What is the Omron NJ501-1400 used for?
It is the Sysmac NJ5-series machine automation controller with 20 MB program memory, a built-in EtherCAT master for up to 32 servo axes, a built-in EtherNet/IP port, and an OPC-UA server. It is the 32-axis non-safety step up from the NJ501-1300 and replaces a separate PLC + motion controller + network gateway pair with a single Sysmac Studio project.
NJ501-1400 vs NJ501-1300 - what is the difference?
Both are NJ5 CPUs with 20 MB memory, EtherCAT, EtherNet/IP, and OPC-UA. The 1400 addresses up to 32 synchronous servo axes; the 1300 is the 16-axis version. Pick the 1400 when the machine needs more than 16 axes; pick the 1300 for the typical 16-axis packaging cell on the same Sysmac Studio project.
Does the NJ501-1400 have built-in safety?
No. The NJ501-1400 is the non-safety 32-axis variant. For CIP-Safety (SL3) on the same NJ5 body, pick the NJ501-1500 (64 axes + safety) or add a separate NX-SL5500 safety CPU and an NX-CSG320 communication unit. The NJ501-1300, NJ501-1400, and NJ501-1500 all share the same 20 MB program memory.
What software does the NJ501-1400 run?
Sysmac Studio version 1.0 or later. The package supports IEC 61131-3 languages (ladder, structured text, function block), CFC, and the Syscam motion toolkit for configuring 1S / G5 servo drives and Accurax inverters. Project files transfer over USB or SD card. The OPC-UA server exposes variables to MES and SCADA clients.
Can the NJ501-1400 connect to a CJ-series I/O rack?
Yes, with a CJ1W-IC101 I/O control unit on the option-board slot. The IC101 maps a CJ-series expansion rack onto the NJ5 I/O table, so existing CJ1W special I/O modules and CJ1W basic I/O stay in the cabinet during a migration. Up to 40 CJ expansion units on 3 racks.
