Omron NS12-TS00B-V2 — 12.1" HMI, Black, No Ethernet
SKU: NS12-TS00B-V2USD 845.00
Omron NS12-TS00B-V2 12.1-inch NS-series HMI, 800 x 600 TFT, 60 MB, 24 VDC, black bezel. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NS12-TS00B-V2 is a 12.1-inch TFT programmable terminal from the NS series, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the Sysmac Studio or NB-Designer project file on a USB drive included.
The unit ships with a 12.1-inch TFT color LCD at 800 x 600 SVGA resolution, displaying 256 colors (32 768 for .BMP and .JPG screens). Project memory is 60 MB and the touch panel is analog resistive. Power is 24 VDC at 25 W. Communication is two RS-232C DB9 ports, one USB Host, and one USB Slave.
This TS00 variant does NOT include Ethernet. The bezel is black. Front panel is IP65, rear IP20, and panel cutout 302 x 228 mm for flush mounting. The product is officially discontinued and stocked on the surplus market; CX-Designer (in CX-One) and NS-Designer / NS-Runtime are the project tools. For Ethernet, pick the NS12-TS01B-V2.
Key Features
- NS-series 12.1-inch TFT programmable terminal, 800 x 600 SVGA, 256 colors (32 768 for BMP/JPG)
- 60 MB project memory, analog resistive touch, 24 VDC at 25 W
- 2 x RS-232C DB9 ports, 1 USB Host, 1 USB Slave, no built-in Ethernet (TS00 variant)
- Black bezel, IP65 front panel, IP20 rear, flush-mount cutout 302 x 228 mm
- SKU: NS12-TS00B-V2
- Series: Omron NS-series programmable terminal (HMI)
- Voltage: 24 VDC
Best-Fit Applications
- Operator panel on a mid-size packaging machine where the 60 MB holds recipe, alarm log, and trend screens on a 12.1-inch flush-mount display
- Spare replacement on an existing NS12-TS00B-V2 retrofit where serial-only wiring cannot migrate to the Ethernet-based NS or NA series
- SCADA overview terminal on a water-treatment skid where the 12.1-inch 800 x 600 panel reads from across a control room
Buying Checklist
- Pick the NS12-TS00B-V2 for a 12.1-inch NS-series HMI with a black bezel and no Ethernet.
- Pick the NS12-TS01B-V2 instead when the panel needs built-in Ethernet on top of the 12.1-inch TFT.
- Pick the NS10-TV01B-V2 instead when a smaller 10.4-inch screen is enough and the cabinet budget is tighter.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NS-series programmable terminal (HMI) |
| Model / SKU | NS12-TS00B-V2 |
| Display | 12.1-inch TFT color LCD, 800 x 600 SVGA, 256 colors (32 768 for BMP/JPG) |
| Memory | 60 MB project memory |
| Touch Panel | Analog resistive, 1 000 000 operations |
| Power Supply | 24 VDC (20.4 to 27.6 VDC), 25 W max |
| Serial Ports | 2 x RS-232C DB9 female, 1 x USB Host, 1 x USB Slave |
| Ethernet | None (TS00 variant - use TS01B-V2 for Ethernet) |
| Front Panel / Cutout | IP65 front, IP20 rear, cutout 302 x 228 mm, flush mount |
| Dimensions / Weight | 323 (W) x 241 (H) x 48.5 (D) mm, 2.5 kg max |
| Environment / Approvals | 0 to +55 C, 35-85% RH (0-40 C), CE / cULus / Lloyd / NK |
FAQ for NS12-TS00B-V2
Does the NS12-TS00B-V2 have built-in Ethernet?
No. The TS00 variant is RS-232C + USB only. The TS01B-V2 sibling is the 12.1-inch NS-series panel with built-in Ethernet on the same black bezel.
Is the NS12-TS00B-V2 still in production?
No. Omron has officially discontinued the NS series. The NS12-TS00B-V2 is available on the surplus / replacement market for retrofit and spare-part applications.
What software programs the NS12-TS00B-V2?
CX-Designer (part of CX-One / CX-One Lite) for new projects, or NS-Designer / NS-Runtime for legacy NS screens. CX-Designer includes a simulator that runs without the panel.
How is the NS12-TS00B-V2 different from the NS12-TS00-V2?
TS00B has a black bezel; TS00 has a standard beige/silver bezel. Both are 12.1-inch 800 x 600 TFT, 60 MB, RS-232C + USB, no Ethernet, discontinued.
