Omron NX-AD2204 — Analog Input, 2-ch, 4-20 mA

SKU: NX-AD2204

USD 125.00

NX-series analog input, 2-ch 4-20 mA differential, 1:8000, 250 us/ch, push-in. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-AD2204 is a 2-channel analog input unit from the NX modular I/O family It is manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).

The two inputs accept 4-20 mA in differential mode with a 13-bit resolution (1:8000 of full scale). Conversion time is 250 microseconds per point.

The body is 12 x 100 x 80.1 mm, 70 g. Key specs: Number of Channels 2; Input Signal 4 to 20 mA (differential input); Input Conversion Range -5 to 105 percent of full scale; Resolution 1/8000 (13-bit) of full scale; Overall Accuracy +/- 0.2 percent FS at 25 degC; +/- 0.4 percent FS at 0 to 55 degC; Conversion Time 250 us / point; I/O Connection Screwless push-in, 8-terminal, removable; NX Bus Power 1.25 W max from NX bus; no I/O power supply terminals.

Key Features

  • NX-series analog input, 2-ch, 4 to 20 mA differential
  • 13-bit resolution (1:8000 of full scale), 250 us/point conversion time
  • Accuracy +/- 0.2 percent FS at 25 degrees C, +/- 0.4 percent FS at 0-55 degrees C
  • Screwless push-in 8-terminal removable connector, NX bus powered
  • SKU: NX-AD2204
  • Series: Omron NX-series modular I/O analog input unit

Best-Fit Applications

  • Two-zone temperature transmitter reading on an NX102 cell where the 4-20 mA loop drives 0.1 degree C resolution on the PLC tag
  • Pressure and flow feedback on a compressor cell where the differential input rejects the common-mode noise from the VFD cable tray
  • Spare replacement on an NX-ECC202 EtherCAT coupler where the original NX-AD2204 has lost the input disconnection detection

Buying Checklist

  • Pick the NX-AD2204 for a 2-channel 4-20 mA differential input on the NX bus with 13-bit resolution.
  • Pick the NX-AD2203 instead when the field wiring is single-ended (sensor shares ground with the NX bus).
  • Pick the NX-AD2208 instead when the loop needs 15-bit (1:30000) resolution at 10 us per point conversion.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NX-series modular I/O analog input unit
Model / SKU NX-AD2204
Number of Channels 2
Input Signal 4 to 20 mA (differential input)
Input Conversion Range -5 to 105 percent of full scale
Resolution 1/8000 (13-bit) of full scale
Overall Accuracy +/- 0.2 percent FS at 25 degC; +/- 0.4 percent FS at 0 to 55 degC
Conversion Time 250 us / point
I/O Connection Screwless push-in, 8-terminal, removable
NX Bus Power 1.25 W max from NX bus; no I/O power supply terminals
Dimensions / Weight 12 (W) x 100 (H) x 80.1 (D) mm; 70 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-AD2204

What does differential input mean on the NX-AD2204?
Each input has its own + and - terminal at the module. The two channels do not share a common ground. This rejects common-mode noise from VFD cables and ground loops. For single-ended wiring (one wire per sensor, common ground), use the NX-AD2203.
Does the NX-AD2204 need a 24 VDC field supply?
No. The NX-AD2204 has no I/O power supply terminals and takes all its power from the NX bus. The 4-20 mA loop is powered from the transmitter side (2-wire device) or from an external 24 VDC rail (4-wire device).
Which CPUs and couplers accept the NX-AD2204?
All NX-series CPU units (NX102, NX502, NX1P2) and all NX-ECC201 / NX-ECC202 EtherCAT couplers. Mounts on DIN track IEC 60715 TH35-7.5 / TH35-15 in any orientation.
What is input disconnection detection on the NX-AD2204?
If the 4-20 mA loop is broken (wire cut or transmitter failure), the input signal falls below 4 mA. The NX-AD2204 detects this and raises a disconnection flag in the input tag, so the PLC can raise an alarm before the process value drifts to 0.
Can the NX-AD2204 read 0-10 V signals?
No. The NX-AD2204 is a current input (4-20 mA differential). For 0-10 V or +/- 10 V inputs on the same 2-ch form factor, use the NX-AD2604 (voltage, differential). For thermocouple / RTD inputs, use the NX-TS3101 or NX-TS3201.
