Omron NX-AD2208 — NX 2-Ch 4-20 mA Input, 1/30000
SKU: NX-AD2208USD 378.00
Omron NX-AD2208 NX-series 2-channel differential 4-20 mA analog input, 1/30000 resolution, 10 us/point. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-AD2208 is a 2-channel differential 4-20 mA analog input unit for the NX-series I/O platform, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).
It reads two 4 to 20 mA loops at 1/30000 full-scale resolution and 10 us per point. Accuracy is 25 C plus or minus 0.1 percent of full scale, 0 to 55 C plus or minus 0.2 percent. The screwless 8-position push-in terminal block (NX-TBA082) accepts two 4-20 mA loops without tools. Wire-break detection is built in for the 4-20 mA range.
Refresh mode is selectable per project: synchronous with the EtherCAT cycle, or Free-Run for stand-alone EtherNet/IP drops. The unit draws 1.25 W max from the NX bus and mounts on any NX-series coupler, including the NX-ECC202 for EtherCAT or the NX-EIC202 for EtherNet/IP. The matching 4-20 mA output is the NX-DA2205. The lower-cost 1/8000 single-ended sibling is the NX-AD2203.
Key Features
- NX-series 2-channel differential 4-20 mA analog input, 1/30000 full-scale resolution, 10 us/point conversion time
- Selectable synchronous I/O refreshing (matched to the EtherCAT cycle) or Free-Run refreshing for EtherNet/IP drops
- Wire-break detection on the 4-20 mA range, overall accuracy +/-0.1 percent at 25 C, +/-0.2 percent at 0 to 55 C
- Screwless 8-position push-in terminal block (NX-TBA082), 12 mm wide housing, 90 g, IP20
- SKU: NX-AD2208
- Series: Omron NX-series I/O platform (NX-AD analog input family)
- I/O: 2 I/O
Best-Fit Applications
- Load-cell conditioning on a packaging line where two 4-20 mA strain-gauge bridges feed the NX-AD2208 over differential pairs and the EtherCAT cycle timestamps each scan
- Flow-meter monitoring in a brewery where two magnetic flow transmitters land on one NX-AD2208 next to an NX-DA2205 that drives the control valve
- Spare replacement on a mixing tank where the previous NX-AD2204 (1/8000) is swapped for the 1/30000 NX-AD2208 to read low-velocity dosing pumps more accurately
Buying Checklist
- Pick the NX-AD2208 for a 2-channel NX-series 4-20 mA differential input at 1/30000 resolution and 10 us/point conversion.
- Pick the NX-AD2204 instead when the cabinet only needs 1/8000 resolution at 250 us/point and Free-Run refreshing is enough.
- Pick the NX-AD2203 instead when the loops share a common ground and single-ended wiring is acceptable on the same 12 mm wide housing.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NX-series I/O platform (NX-AD analog input family) |
| Model / SKU | NX-AD2208 |
| Number of Points | 2 analog inputs, differential input method, screwless push-in terminal block (8 terminals) |
| Input Range | 4 to 20 mA (input conversion range -5 to 105 percent of full scale, absolute maximum +/-30 mA) |
| Resolution | 1/30000 of full scale (15-bit effective), 250 ohm input impedance |
| Conversion Time | 10 us per point, selectable synchronous I/O refreshing or Free-Run refreshing |
| Overall Accuracy | +/-0.1 percent of full scale at 25 C, +/-0.2 percent of full scale at 0 to 55 C |
| Wire-Break Detection | Built-in on the 4-20 mA range; flag below 2 mA |
| Isolation | Between input and NX bus: power = transformer, signal = digital isolator; no isolation between the two input channels |
| Power Consumption | 1.25 W max from NX bus when connected to a CPU or Communication Control Unit, 0.90 W max via a Communications Coupler Unit |
| Dimensions / Weight | 12 (W) x 100 (H) x 71 (D) mm, 90 g, IP20, 0 to 55 C operating, cULus / CE / KC / RCM listed |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-AD2208
What is the Omron NX-AD2208 used for?
It is the NX-series 2-channel differential 4-20 mA analog input unit. It mounts on an NX-series coupler (NX-ECC202 for EtherCAT, NX-EIC202 for EtherNet/IP) and reads two 4-20 mA loops at 1/30000 full-scale resolution and 10 us per point. Typical uses are strain-gauge / load-cell conditioning, flow and pressure transmitters, and any high-speed 4-20 mA loop where differential wiring is needed to reject common-mode noise.
NX-AD2208 vs NX-AD2204 - what is the difference?
Both share the same 2-channel 4-20 mA differential body, 12 mm wide housing, and screwless push-in terminal block. The -2208 is the 1/30000 resolution, 10 us/point, synchronous-or-Free-Run variant. The -2204 is the 1/8000 resolution, 250 us/point, Free-Run-only variant. Pick the -2208 when the loop needs 15-bit effective resolution or must move in step with the EtherCAT cycle; pick the -2204 for general-purpose 4-20 mA monitoring.
Does the NX-AD2208 support synchronous I/O refreshing?
Yes. The NX-AD2208 supports both synchronous I/O refreshing (matched to the EtherCAT cycle of the host NJ / NX CPU) and Free-Run refreshing (for stand-alone EtherNet/IP drops). Set the refreshing mode in the Sysmac Studio I/O Map for the unit. Synchronous is the typical choice when the analog sample must align with the servo cycle.
What NX coupler works with the NX-AD2208?
Any of the NX-series communication couplers. For EtherCAT, use the NX-ECC202 (standard) or NX-ECC203 (high-speed, lower cycle). For EtherNet/IP, use the NX-EIC202. The NX-AD2208 is compatible with Sysmac Studio 1.05 or later; older Sysmac Studio versions may need a unit-version update.
Does the NX-AD2208 need a separate 24 VDC supply?
No. The NX-AD2208 has no I/O power supply terminals and draws all operating power from the NX bus. The 4-20 mA loops must be powered from an external 24 VDC transmitter supply (typical 2-wire loop) or from a 4-wire active transmitter. Power consumption is 1.25 W max when connected to a CPU and 0.90 W max when connected via a coupler.
