Omron NX-AD2203 — front view of the NX slice I/O module showing the Omron model label, the green TS indicator, the two analog input channels, the 8-terminal screwless push-in block and the NX bus connector on top

Omron NX-AD2203 — NX Analog Input, 2-ch, 4-20 mA

SKU: NX-AD2203

USD 120.00

Omron NX-AD2203 NX-series analog input, 2 channels, 4-20 mA, 1/8000, 12 mm wide. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-AD2203 is a 2-channel current-input analog module from the NX-series slice I/O family, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).

The module accepts two 4-20 mA signals on single-ended inputs at a 13-bit (1/8000) resolution. Conversion time is 250 microseconds per channel. The 8-terminal screwless push-in block accepts ferruled or solid wires without a screwdriver.

The unit is 12 mm wide, 100 mm tall, 71 mm deep and 70 g. Power is drawn from the NX bus, no external 24 VDC supply is needed. The module is mounted to the right of an NX102-1000 CPU on a DIN rail. For differential current inputs on the same 2-channel body, pick the NX-AD2204. For voltage inputs on a 4-channel body, pick the NX-AD3603.

Key Features

  • NX-series 2-channel analog input module, 4-20 mA single-ended
  • 13-bit (1/8000) resolution, 250 us per channel, free-run refresh
  • Screwless push-in terminal block with 8 terminals, no tools needed
  • 12 mm wide, NX-bus powered (1.25 W max), DIN-rail mounted
  • SKU: NX-AD2203
  • Series: Omron NX-series slice I/O analog input
  • Voltage: 24 VDC

Best-Fit Applications

  • Pressure transmitter readout on a hydraulic press where the 250 us update covers the cylinder profile
  • Flow meter scaling on a water treatment skid where the two channels read inlet and outlet 4-20 mA signals
  • Spare drop-in for an existing NX cell where the I/O tag mapping in Sysmac Studio is already in place

Buying Checklist

  • Pick the NX-AD2203 for a 2-channel 4-20 mA single-ended analog input on a 12 mm NX slice.
  • Pick the NX-AD2204 instead when the cabinet needs differential current inputs on the same 2-channel body.
  • Pick the NX-AD3603 instead when the panel needs voltage inputs (0 to 10 V or -10 to 10 V) on the same 4-channel form factor.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NX-series slice I/O analog input
Model / SKU NX-AD2203
Input Type Single-ended current loop
Input Range 4 to 20 mA (absolute max +/-30 mA)
Number of Channels 2
Resolution 13-bit (1/8000 full scale)
Conversion Time 250 us per channel; 0.5 ms per unit
Accuracy +/-0.2% FS at 25 degC; +/-0.4% FS at 0-55 degC
Terminal Block Screwless push-in, 8 terminals, removable
Power Supply Supplied from NX bus (24 VDC); 1.25 W max
Dimensions / Weight 12 (W) x 100 (H) x 71 (D) mm; 70 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-AD2203

Does the NX-AD2203 need an external 24 VDC supply?
No. The module draws all of its power from the NX bus through the adjacent NX CPU or communications coupler. Loop power for 2-wire 4-20 mA transmitters still needs an external 24 VDC distribution block.
Can the NX-AD2203 read voltage signals?
No. The NX-AD2203 is current input only at 4-20 mA. For voltage inputs (0 to 10 V, -10 to 10 V or 0 to 5 V), use the NX-AD2603 (2-channel single-ended voltage), the NX-AD2604 (2-channel differential voltage) or the NX-AD3603 (4-channel voltage).
What does the screwless push-in terminal accept?
Solid wire from 0.08 to 1.5 mm squared and stranded wire with a ferrule from 0.08 to 1.0 mm squared. Insert the wire directly; no screwdriver is needed. To release, push a flat-blade screwdriver into the orange slot next to the terminal.
