Omron NX-AD3208 — 4-Ch Analog Input, 4-20 mA, 1/30000
SKU: NX-AD3208USD 442.00
Omron NX-AD3208 NX-series 4-ch analog current input, 4-20 mA differential, 1/30000, 10 us. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-AD3208 is the NX-series 4-ch high-resolution current analog input unit, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).
It sits on the NX I/O bus behind an NX-ECC201 EtherCAT Coupler or on the right of an NX102 / NX1P2 CPU and reads 4 differential current signals at 4 to 20 mA. Resolution 1/30000 full scale and 10 microseconds per point conversion time make it the right slice for high-speed process loops and synchronized motion feedback.
Selectable Synchronous or Free-Run refreshing in Sysmac Studio. Input impedance 250 Ohm, absolute maximum +/-30 mA, accuracy 0.1 percent at 25 C and 0.2 percent at 0 to 55 C. Transformer and digital isolator between input and NX bus; no isolation between inputs. 12 mm wide, 70 g, IP20. The lower-resolution sibling is NX-AD3204 (1/8000). The voltage-input sibling is NX-AD3608. The 8-ch current sibling is NX-AD4208.
Key Features
- NX-series 4-channel analog input unit, current type, 4 to 20 mA, differential input, input impedance 250 Ohm
- Resolution 1/30000 full scale; conversion time 10 microseconds per point; accuracy 0.1 percent at 25 C and 0.2 percent at 0 to 55 C
- Selectable Synchronous I/O refreshing or Free-Run refreshing in Sysmac Studio; input disconnection detection supported
- Screwless push-in 12-terminal connector, NX bus-powered, 12 (W) x 100 (H) x 71 (D) mm, 70 g, IP20
- SKU: NX-AD3208
- Series: NX-series Analog I/O Unit (NX-AD family) on NX I/O Bus
- I/O: 4 I/O
Best-Fit Applications
- High-speed press force monitoring where four strain-gauge amplifiers feed 4-20 mA signals sampled at 10 us per point into the NX1P2-1040DT
- Hydraulic cylinder position loop where four 4-20 mA pressure transducers feed the NX102-1200 motion controller at the EtherCAT cycle
- Spare replacement on a process skid where the original NX-AD3208 was lost and Sysmac Studio holds the I/O map and channel scaling
Buying Checklist
- Pick the NX-AD3208 when the cell needs 4 differential 4-20 mA inputs with 1/30000 resolution and 10 us conversion.
- Pick the NX-AD3204 instead when 4 differential 4-20 mA inputs at 1/8000 resolution and 250 us conversion are enough.
- Pick the NX-AD3608 instead when the field devices are -10 to +10 V voltage signals instead of 4-20 mA current loops.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | NX-series Analog I/O Unit (NX-AD family) on NX I/O Bus |
| Model / SKU | NX-AD3208 |
| Number of Points | 4 differential analog inputs |
| Input Range | 4 to 20 mA (input conversion range -5 to 105 percent of full scale) |
| Resolution / Conversion | 1/30000 (full scale); 10 microseconds per point; synchronous I/O refreshing selectable |
| Accuracy | 25 C +/-0.1 percent full scale; 0 to 55 C +/-0.2 percent full scale |
| Input Impedance / Max | 250 Ohm; absolute maximum +/-30 mA |
| Refreshing | Selectable Synchronous I/O refreshing or Free-Run refreshing |
| Isolation | Transformer (power) + digital isolator (signal) between input and NX bus; no isolation between inputs; dielectric 510 VAC for 1 minute |
| Connection / Power | Screwless push-in 12-terminal connector; NX unit power 1.30 W max on CPU / 0.95 W max on Coupler |
| Dimensions / Approvals | 12 (W) x 100 (H) x 71 (D) mm; 70 g; IP20; 0 to 55 C ambient; SIL None; CE, cULus, RCM, KC, Lloyd |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-AD3208
What is the Omron NX-AD3208 used for?
It is the NX-series 4-channel analog current input unit for 4 to 20 mA differential signals. Typical uses are high-speed press force monitoring, hydraulic cylinder position loops, and spare replacement on a process skid where Sysmac Studio holds the I/O map.
NX-AD3208 vs NX-AD3204 - what is the difference?
Both are NX-series 4-channel analog current input units at 4 to 20 mA differential. The AD3208 has 1/30000 resolution and 10 microsecond conversion with selectable Synchronous or Free-Run refreshing. The AD3204 has 1/8000 resolution and 250 microsecond conversion with Free-Run refreshing only. Pick the AD3208 for high-speed or high-resolution loops; pick the AD3204 for general-purpose current inputs.
Does the NX-AD3208 detect input disconnection?
Yes. The NX-AD3208 supports input disconnection detection per channel; the NX-AD3204 (1/8000, 250 us) does not. Use this feature to flag a broken transmitter wire before the loop goes below 4 mA and reads zero.
How is the NX-AD3208 wired to a 4-20 mA transmitter?
Connect the transmitter positive lead to the channel V+ terminal and the transmitter negative lead to the channel I- terminal on the screwless push-in 12-terminal connector. Provide 24 VDC loop power from a separate PSU or from the NX-PC0020 IOV power connection unit on the NX bus. No shield terminal on the slice; ground the cable shield at the panel ground bar.
