Omron NX-AD4203 — 8-Ch 4-20 mA Analog Input, 1/8000
SKU: NX-AD4203USD 202.00
Omron NX-AD4203 NX-series 8-point analog input, 4-20 mA single-ended, 1/8000 (13-bit), 250 us. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-AD4203 is the NX-series 8-channel analog input unit for 4 to 20 mA current loops, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).
It sits on the NX I/O bus behind an NX-ECC201 EtherCAT Coupler or on the right of an NX102 / NX1P2 CPU and reads eight 4-20 mA signals as single-ended inputs. Resolution 1/8000 of full scale (13-bit), conversion time 250 us per point, Free-Run refreshing only.
Input impedance 85 Ohm, absolute maximum +/-30 mA, accuracy 25 C +/-0.2 percent FS. Screwless push-in 16-terminal connector, NX-bus powered at 1.40 W max on CPU and 1.05 W on Coupler. Input disconnection detection is supported. The 4-channel sibling is NX-AD3203. For differential inputs use NX-AD4204; for higher resolution use NX-AD4208 (1/30000).
Key Features
- NX-series 8-channel analog input unit, 4 to 20 mA, single-ended input, input impedance 85 Ohm
- Resolution 1/8000 of full scale (13-bit), conversion time 250 us per point, Free-Run refreshing only
- Screwless push-in 16-terminal connector, NX bus-powered, 1.40 W max on CPU, 1.05 W max on Coupler
- Input disconnection detection supported, transformer + digital isolator between input and NX bus
- SKU: NX-AD4203
- Series: NX-series Analog Input Unit (NX-AD family) on NX I/O Bus
- I/O: 8 I/O
Best-Fit Applications
- Bottling-line flow loop where eight 4-20 mA magnetic flowmeters feed an NX102-1200 with the NX-AD4203 sampling Free-Run at 250 us per point
- Process-skid pressure skid where eight 4-20 mA pressure transmitters land on a single 12 mm slice to save rack space behind the NX-ECC201
- Spare replacement on a wastewater cell where the original NX-AD4203 was lost and Sysmac Studio holds the channel scaling and disconnection alarms
Buying Checklist
- Pick the NX-AD4203 when the cell needs eight 4-20 mA single-ended inputs at 1/8000 resolution and 250 us conversion on a 12 mm slice.
- Pick the NX-AD4204 instead when the transmitters are to 8 in differential mode at the same 1/8000 resolution and 250 us conversion.
- Pick the NX-AD4208 instead when the application needs 1/30000 high resolution and 10 us conversion with selectable Synchronous or Free-Run refreshing.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | NX-series Analog Input Unit (NX-AD family) on NX I/O Bus |
| Model / SKU | NX-AD4203 |
| Number of Points | 8 analog inputs, single-ended |
| Input Range | 4 to 20 mA (input conversion range -5 to 105 percent of full scale) |
| Resolution / Conversion | 1/8000 of full scale (13-bit); 250 us per point; Free-Run refreshing |
| Accuracy | 25 C +/-0.2 percent full scale; 0 to 55 C +/-0.4 percent full scale |
| Input Impedance / Max | 85 Ohm; absolute maximum +/-30 mA |
| Connection / Power | Screwless clamping terminal block (16 terminals); NX bus-powered; no external I/O supply |
| NX Unit Power | 1.40 W max on CPU or Communication Control Unit; 1.05 W max on Coupler |
| Isolation | Transformer (power) + digital isolator (signal) between input and NX bus; no isolation between inputs; dielectric 510 VAC for 1 minute |
| Dimensions / Approvals | 12 (W) x 100 (H) x 71 (D) mm; 70 g; IP20; 0 to 55 C ambient; SIL None; CE, cULus, RCM, KC, Lloyd, NK |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-AD4203
What is the Omron NX-AD4203 used for?
It is the NX-series 8-channel analog input unit for 4-20 mA single-ended current loops at 1/8000 (13-bit) resolution and 250 us per point conversion. Typical uses are bottling-line flow loops, process-skid pressure transmitters, and spare replacement on wastewater cells where Sysmac Studio holds the channel scaling.
NX-AD4203 vs NX-AD4204 - what is the difference?
Both are NX-series 8-channel 4-20 mA analog input units at 1/8000 (13-bit) resolution and 250 us per point on a 12 mm slice. The AD4203 is single-ended; the AD4204 is differential. Pick the AD4203 when the transmitters share a common ground at the panel; pick the AD4204 when the transmitters are isolated or run long cable runs in noisy environments.
Does the NX-AD4203 need an external 24 VDC power supply?
No external I/O supply. The slice draws 1.40 W from the NX bus when mounted on a CPU or Communication Control Unit, and 1.05 W when mounted on an NX-ECC201 / ECC202 / ECC203 EtherCAT Coupler. There is no I/O current consumption, and no IOV terminals on the connector - just the eight 4-20 mA signal pairs.
What is the difference between NX-AD4203 and NX-AD4208?
Both are 8-channel 4-20 mA analog input units on a 12 mm slice. The AD4203 has 1/8000 resolution and 250 us conversion in Free-Run mode only. The AD4208 has 1/30000 resolution and 10 us conversion with selectable Synchronous or Free-Run refreshing. Pick the AD4203 for general-purpose 4-20 mA loops; pick the AD4208 for high-resolution or motion-synchronized loops.
How do I wire a 4-20 mA transmitter to the NX-AD4203?
Land the transmitter positive on channel V+ and the transmitter negative on channel I- on the 16-terminal screwless connector. The slice is single-ended, so share the panel-ground return across all eight channels. The NX-AD4203 itself does not supply loop power - provide 24 VDC loop power from a separate PSU or from an NX-PC0020 power connection unit on the NX bus.
