Omron NX-AD4204 — front face of the 8-channel 4 to 20 mA differential analog input unit showing the screwless push-in 16-terminal block, the TS indicator and the NX-AD4204 type label

Omron NX-AD4204 — 8-Ch 4-20 mA Analog Input

SKU: NX-AD4204

USD 200.00

NX 8-ch 4 to 20 mA differential analog input, 1:8000, 250 us/ch, 12 mm wide. In stock, China.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-AD4204 is an NX-series 8-channel 4 to 20 mA differential analog input unit with a 1/8000 resolution It is manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).

Each of the eight channels accepts a 4 to 20 mA signal in differential mode and converts it to a 13-bit value at 250 us per channel. Absolute maximum rating is +/-30 mA.

Mount on any NX-ECC201 / ECC202 / ECC203 EtherCAT Coupler. Key specs: Number of Inputs 8 channels; Input Type 4 to 20 mA differential; Input Conversion Range -5 to 105 percent of full scale; Absolute Maximum Rating +/-30 mA; Input Impedance 85 ohm; Resolution / Accuracy 1/8000 (13-bit); +/-0.2 percent FS at 25 degC, +/-0.4 percent FS at 0 to 55 degC; Conversion Time / Refreshing 250 us per channel (2 ms per unit); Free-Run only; per-channel disconnection detection; 1.05 W NX-bus max; External Connection Screwless push-in 16-terminal block (removable).

Key Features

  • NX-series 8-channel 4 to 20 mA differential analog input
  • 1/8000 (13-bit) resolution, 250 us per channel conversion, Free-Run refreshing only
  • Absolute maximum +/-30 mA, 85 ohm input impedance, disconnection detection per channel
  • Screwless push-in 16-terminal block, 12 x 100 x 80 mm, 70 g, IP20, 1.05 W NX-bus max
  • SKU: NX-AD4204
  • Series: NX-series Analog Input Unit (current)

Best-Fit Applications

  • Spare replacement where the existing NX-AD4203 single-ended wiring is replaced with differential for better noise rejection on long cable runs
  • Reading eight 4-20 mA pressure transducer loops on a hydraulic press and scaling them to bar in the NJ501 PLC every cycle
  • Monitoring tank level from eight loop-powered ultrasonic level probes on a CIP cleaning line in a beverage plant

Buying Checklist

  • Choose the NX-AD4208 instead when 1/30000 resolution or Synchronous I/O refreshing is required for higher-precision weighing.
  • Choose the NX-AD4204 when the eight 4-20 mA inputs are differential and Free-Run refreshing is enough at 2 ms per unit.
  • Choose the NX-AD4203 instead when the sensors share a common ground and single-ended wiring is acceptable on the same 12 mm body.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series NX-series Analog Input Unit (current)
Model / SKU NX-AD4204
Number of Inputs 8 channels
Input Type 4 to 20 mA differential
Input Conversion Range -5 to 105 percent of full scale
Absolute Maximum Rating +/-30 mA
Input Impedance 85 ohm
Resolution / Accuracy 1/8000 (13-bit); +/-0.2 percent FS at 25 degC, +/-0.4 percent FS at 0 to 55 degC
Conversion Time / Refreshing 250 us per channel (2 ms per unit); Free-Run only; per-channel disconnection detection; 1.05 W NX-bus max
External Connection Screwless push-in 16-terminal block (removable)
Dimensions / Approvals 12 (W) x 100 (H) x 80 (D) mm; 70 g; IP20; cULus, CE, RCM

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-AD4204

What is the difference between NX-AD4203 and NX-AD4204?
Both are 8-channel 4 to 20 mA current inputs on the same 12 mm slice. The AD4203 is single-ended and provides the I/O power supply from the NX bus to drive 2-wire transmitters. The AD4204 is differential and gives better common-mode noise rejection in noisy industrial cabinets. Both use the screwless push-in 16-terminal block on the back of the unit.
Does the NX-AD4204 support Synchronous I/O refreshing?
No. The NX-AD4204 supports Free-Run refreshing only at the 1/8000 resolution. For Synchronous I/O at higher resolution, pick the NX-AD4208 (1/30000, Synchronous I/O selectable) on the same 12 mm slice at a different price point today.
Does the NX-AD4204 detect a disconnected sensor?
Yes. The NX-AD4204 supports per-channel disconnection detection. When a 4-20 mA loop is broken, the input reads below 4 mA and the disconnection flag is set in Sysmac Studio. The PLC program can read the flag and trigger an alarm or stop the process immediately.
Can the NX-AD4204 mount on an EtherCAT coupler?
Yes. The NX-AD4204 mounts on the NX-ECC201, ECC202 or ECC203 EtherCAT Coupler, on the NX-EIC202 EtherNet/IP Coupler, or directly on the NX102 modular CPU bus. The 12 mm width keeps eight slices under 100 mm of DIN rail space.
