Omron NX-DA3203 — 4-Ch 4-20 mA Output Unit

SKU: NX-DA3203

USD 190.00

NX-series 4-point analog current output, 4-20 mA, 1/8000 resolution, 250 us conversion, 1.80 W from NX bus, free-run refresh.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-DA3203 is a 4-channel analog current-output unit for the NX-series modular I/O system. Each of the 4 outputs drives an independent 4-20 mA current loop to control proportional valves, variable-speed drives, chart recorders, or heater controllers. With a 1/8000 full-scale resolution and 250 us per-point conversion time, the unit handles most process loop update cycles and machine speed references without adding a step to the system update budget. It draws 1.80 W from the NX bus, with no separate 24 VDC loop supply. Pick the NX-DA3203 when a NJ / NX1P / NX102 controller needs 4 current-only outputs at standard resolution.

Where it fits in the NX-DA family

The NX-DA analog output family is split by channel count, signal type, and resolution. NX-DA2205 is the 2-point 4-20 mA model at 1/30000 resolution. NX-DA3203 is the 4-point 4-20 mA model at 1/8000 resolution. NX-DA2603 / NX-DA3603 are the 2 / 4-point voltage output siblings (-10 to +10 V). Pick the NX-DA3203 when the loads are 4-20 mA current loops at standard process resolution.

Using the NX-DA3203 with the right coupler

The NX-DA3203 is a slave I/O unit that connects to an NX-series CPU over the NX bus, or to a CJ PLC through an NX-EIC202 unit, or to any EtherCAT master through an NX-ECC201 / NX-ECC202 / NX-ECC203 EtherCAT coupler. Pick the EtherCAT coupler (NX-ECC201) for an NJ/NX1P/NX102 system, the NX-ECC202 for redundant ring topologies, or the NX-ECC203 for the slide-in NX-CIF series bus systems.

Before ordering

Confirm the load wiring is current-loop, not voltage - mixing 4-20 mA outputs with a device expecting 0-10 V will burn out the receiver. Check the loop load resistance: the unit can drive up to 600 ohm loops from a 24 VDC loop supply through to the receiving device. Wire shielded twisted pair to the spring-loaded push-in terminal block (max 1.5 mm^2 / AWG 16). Configure each channel in the Sysmac Studio I/O map with the correct scale factors before commissioning.

Key Features

  • NX-series analog current output unit (NX-DA family)
  • 4 channels, each 4-20 mA output (current sink)
  • 1/8000 full-scale resolution (output setpoint -4000 to +4000)
  • +/- 0.3 percent full-scale accuracy at 25 degC
  • 250 us per-point digital-to-analog conversion time
  • Free-run I/O refresh (250 us cycle)
  • 1.80 W max NX-bus current consumption
  • Spring-loaded push-in terminal block
  • Standard UL / CE / KC approvals
  • Plugs into NX-series EtherCAT coupler (NX-ECC201 / 202 / 203)
  • SKU: NX-DA3203
  • Series: NX-DA analog output unit
  • I/O: 4 I/O

Best-Fit Applications

  • Sending drive speed references to a variable-frequency drive
  • Driving proportional hydraulic or pneumatic valves from an NX controller
  • Setpoint output to a remote temperature or humidity controller
  • Strip-chart or paperless recorder signal feed at the panel end
  • Process loop output on a packaging or batching machine skid

Buying Checklist

  • Confirm the loads accept 4-20 mA current loops, not 0-10 V voltage (use NX-DA3603 for voltage outputs).
  • Choose NX-DA2205 for the high-resolution 2-channel 4-20 mA body when a 4-channel slot is not needed.
  • Choose NX-DA2205 (high resolution) over the 4-channel DA3203 for low-channel applications.
  • Choose NX-DA2603 or NX-DA3603 when voltage output (-10 to +10 V) is required.
  • Verify the loop load resistance stays under 600 ohm from the 24 VDC loop supply.
  • Confirm the NX coupler slot: NX-DA3203 fits NX-ECC201 / 202 / 203 or NX-EIC202.

Technical Specifications

Series NX-DA analog output unit
Output Channels 4 (current, independent)
Output Range 4 to 20 mA
Resolution 1/8000 full scale (setpoint -4000 to +4000)
Overall Accuracy +/- 0.3 percent FS at 25 degC
Conversion Time 250 us per point
I/O Refresh Free-run only
Load Resistance 600 ohm max (at 24 VDC loop supply)
Terminal Block Screwless push-in (captive screw terminal optional)
Current Draw 1.80 W max from NX bus
Standards UC1, CE, KC
Compatible Couplers NX-ECC201 / ECC202 / ECC203 EtherCAT, NX-EIC202 to CJ

FAQ for NX-DA3203

What is the difference between NX-DA3203 and NX-DA3205?
Both are 4-point 4-20 mA current-output units for the NX series. The NX-DA3203 is the standard-resolution model (1/8000, +/- 0.3 percent FS, 250 us conversion, free-run refresh). The NX-DA3205 is the high-resolution sibling (1/30000, +/- 0.1 percent FS, 10 us per-point conversion, with selectable synchronous or free-run refresh). For servo or tension control, use the DA3205; for general process loops, use the DA3203.
Does the NX-DA3203 need an external 24 VDC loop supply?
The unit drives the current on its own - no separate loop supply is needed for the output stage. The device that receives the 4-20 mA signal must be powered from somewhere, but that supply is on the receiving side. The NX-DA3203 itself draws 1.80 W from the NX bus; it does not pull from a 24 VDC rail.
Which NX coupler or CPU does the NX-DA3203 require?
Use an NX-series CPU (NX102 / NX502 / NX701 / NX1P2) with a built-in NX bus, or pair the unit with one of the standard NX couplers - NX-ECC201 for a standard EtherCAT topology, NX-ECC202 for redundant ring, or NX-ECC203 for the slide-in NX-CIF bus adapter. For a CJ-series PLC, use the NX-EIC202 I/O interface unit to bridge from the CJ rack to the NX-DA3203.
