Omron NX-DA2205 — 2-Pt 4-20mA Analog Output, High-Speed
SKU: NX-DA2205USD 302.00
NX-series 2-point analog current output slice with 4-20 mA output, 1/30000 resolution (15-bit equivalent), 10 us/point conversion time. Screwless push-in 8-terminal connector, 12 mm wide. Selectable Synchronous or Free-Run I/O refresh. For high-speed proportional valve and drive reference.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The NX-DA2205 is Omron's high-speed 2-point analog current output slice for the NX-series modular I/O platform — providing 4-20 mA output with 1/30000 resolution and 10 us/point conversion time for proportional-valve control, variable-speed drive reference, and other high-speed analog control loops. The 1/30000 resolution is roughly 4x finer than the basic NX-DA2203 (1/8000), and the 10 us update is 25x faster than the basic 250 us/ch — together enabling servo-class analog control on hydraulic proportional valves, spindle speed reference, and tension-control loops where the basic slice's 250 us update would introduce a perceptible lag.
Decoding NX-DA2205 within the NX-DA family
The NX-DA@@@@ model code has four positional digits that encode point count, output type, and resolution: __22_ = 2-point current output (vs __26_ = 2-pt voltage, __32_ = 4-pt current, __36_ = 4-pt voltage); __2_05 = 1/30000 high-speed 10 us (vs __2203 = 1/8000 basic 250 us). The NX-DA2205 codepoint thus decodes as 2-point current output with high-speed 1/30000 resolution.
Synchronous vs Free-Run I/O refresh — when to choose which
The NX-DA2205 supports two I/O refresh modes selected in Sysmac Studio: (a) Synchronous I/O refreshing — the output updates at the EtherCAT cycle (typically 250 us to 4 ms, depending on the cycle time set on the NX-ECC@@@ coupler). The output value is read from the EtherCAT process data at each cycle boundary, so the analog output is in lockstep with the rest of the I/O and the NJ/NX CPU's program execution.
Application context: hydraulic press proportional valve control
A typical application for the NX-DA2205 is hydraulic press proportional valve control for a forming or forging press. The press has 2 proportional valves (one for the ram, one for the die cushion), each valve accepting a 4-20 mA command signal where 4 mA = closed, 12 mA = 50% flow, 20 mA = 100% flow. The 1/30000 resolution gives ~0.5 uA per step, providing smooth proportional control across the valve's full stroke range. The 10 us update rate gives the valve's closed-loop position controller fresh commands every 10 us, ensuring the cylinder position tracks the commanded profile without lag.
Key Features
- NX-series 2-point analog current output slice
- Output range: 4 to 20 mA
- Resolution: 1/30000
- Conversion time: 10 us/point
- Selectable I/O refresh: Synchronous I/O refreshing or Free-Run refreshing
- Output conversion range: -5 to 105% of full scale
- Output accuracy: +/-0.1% of full scale at 25 C, +/-0.3% at 0-55 C
- External connection: Screwless clamping terminal block
- SKU: NX-DA2205
- Series: NX-series Analog Output Units
- Voltage: 24 VDC
- I/O: 4 I/O
Best-Fit Applications
- Hydraulic press proportional valve control - 2 proportional valves on a forming/forging press, each accepting 4-20 mA command signal; the.
- Spindle speed reference on a CNC lathe - NX-DA2205 outputs 4-20 mA to the spindle drive's speed-reference input, with the.
- Tension control on a wire-winding machine - NX-DA2205 outputs 4-20 mA to a dancer-position-controlled tension brake, with the NJ501 reading.
- Variable-speed drive reference for multiple inverters - 4-20 mA reference signal to two 3G3MX2-A4075-V2 VFDs on a conveyor system, where.
Buying Checklist
- Pick NX-DA2205 for 2-pt 4-20 mA analog output, high-speed 1/30000 10 us - servo-class proportional valve or drive reference
- Pick NX-DA2203 for 2-pt 4-20 mA analog output, basic 1/8000 250 us - process loops at 100 ms update, half the cost
- Pick NX-DA2605 for 2-pt -10 to +10 V analog output, high-speed - voltage-output valve positioners or drive references
- Pick NX-DA2603 for 2-pt -10 to +10 V analog output, basic - voltage process loops at 100 ms update
- Pick NX-DA3205 for 4-pt 4-20 mA analog output, high-speed - 4-axis proportional valve control
- Pick NX-DA3203 for 4-pt 4-20 mA analog output, basic - 4-axis process loops at 100 ms update
Technical Specifications
| Model | NX-DA2205 |
|---|---|
| Series | NX-series Analog Output Units |
| Type | 2-point analog current output slice, high-speed |
| Number of Points | 2 points |
| Output Range | 4 to 20 mA |
| Output Conversion Range | -5 to 105% of full scale (3.2 to 21 mA drive) |
| Resolution | 1/30000 (15-bit equivalent) |
| Output Setting Value (Decimal) | 0 to 30000 (for 0-100% of full scale) |
| Absolute Maximum Output Current | 30 mA (short-circuit protection triggers above) |
| Current Consumption from I/O Power Supply | 10 mA max (for 24 VDC I/O supply) |
| Mounting | NX-series 35 mm DIN-rail mount, occupies one slice (12 mm wide) |
| Dimensions (W x H x D) | 12 x 100 x 71 mm |
| Operating Temperature | 0 to +55 C |
| Storage Temperature | -25 to +85 C |
| Certifications | CE, cULus listed (Class I Div 2), UL 508, KC, Lloyd's Register |
Resources & Downloads
FAQ for NX-DA2205
What's the difference between NX-DA2205 and NX-DA2203?
Both are NX-series 2-point 4-20 mA analog current output slices with the same 12 mm width, same load impedance, same external connection terminal block, and same NX bus compatibility. The differences: (a) Resolution - NX-DA2203 is 1/8000 (13-bit equivalent), NX-DA2205 (this SKU) is 1/30000 (15-bit equivalent). The 2205 gives 3.75x finer output resolution, useful for smooth proportional-valve control across the full stroke range.
Can the NX-DA2205 be used with both EtherCAT and EtherNet/IP networks?
Yes - the NX-DA2205 works with both EtherCAT and EtherNet/IP network masters when paired with the appropriate NX-series coupler: (a) NX-ECC201 / NX-ECC202 / NX-ECC203 - EtherCAT couplers (ECC201 already done). When one of these is used, the NX-DA2205 is on the EtherCAT network, communicating at the EtherCAT cycle (typically 250 us to 4 ms). (b) NX-EIC202 - EtherNet/IP coupler. When this is used, the NX-DA2205 is on the EtherNet/IP network, communicating via CIP message or tag-data-link.
How does the screwless push-in terminal block work on the NX-DA2205?
The NX-DA2205 has an 8-terminal screwless clamping terminal block on the front face for the analog output wiring (4-20 mA loop). The terminal block uses push-in spring-cage technology - to wire, strip 8 mm of insulation from a ferrule-terminated wire (or solid wire 0.25-1.5 mm^2 / stranded with ferrule 0.25-1.0 mm^2), insert into the terminal, and the internal spring clamp engages automatically.
What is the difference between Synchronous and Free-Run I/O refresh on the NX-DA2205?
The NX-DA2205 supports two I/O refresh modes selectable in Sysmac Studio: (a) Synchronous I/O refreshing - the analog output updates at the EtherCAT cycle boundary. The NJ/NX CPU writes the desired output value to the EtherCAT process data; at each EtherCAT cycle (typically 250 us to 4 ms), the NX-DA2205 reads the value and updates the analog output.
