Omron NX-EC0132 — front face of the Omron retail carton showing the NX-EC0132 label, the Incremental Encoder Input 1CH Line receiver markings, the screwless clamp terminal block diagram, and the blue Omron brand strip

Omron NX-EC0132 — NX 1-Ch Encoder Input, RS-422

SKU: NX-EC0132

USD 132.00

Omron NX-EC0132 NX-series 1-channel incremental encoder input with RS-422 line receiver, NPN, 4 MHz A/B phases. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-EC0132 is the NX-series 1-channel incremental encoder input unit with line receiver (RS-422) input, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series Position Interface Unit datasheet.

It sits on the NX I/O bus behind an NX-ECC201 EtherCAT Coupler, NX102, or NX1P2 CPU and reads one incremental encoder. Phases A and B accept single-phase pulses at 4 MHz, or 1 MHz in 4x phase-difference mode; phase Z accepts 1 MHz. The 32-bit counter covers +/-2,147,483,647 pulses in linear or ring mode, with two external and one internal latch inputs.

Three external 24 VDC NPN inputs (1 microsecond ON/OFF response) handle gate, reset, and presets. The slice supplies 5 VDC at 500 mA to the encoder from a built-in isolated supply. It is 24 mm wide, 100 x 71 mm, 130 g, with two 12-terminal screwless push-in connectors. For a PNP line-receiver version pick NX-EC0142. SIL None.

Key Features

  • NX-series 1-channel incremental encoder input with RS-422 line receiver (RS-422) input, NPN internal I/O common
  • Phases A and B 4 MHz single-phase / 1 MHz x4 phase-difference, phase Z 1 MHz, 32-bit counter range plus ring/linear mode
  • 3 external 24 VDC NPN gate/reset inputs with 1 microsecond response, 5 VDC +/-5% 500 mA max encoder supply (non-isolated supply; A/B/Z signals digitally isolated)
  • Screwless push-in 12-terminal x 2 connector, 12 x 100 x 71 mm, 130 g, Free-Run / Synchronous / Task Period Prioritized refreshing
  • SKU: NX-EC0132
  • Series: NX-series Position Interface Unit (NX-EC family) on NX I/O Bus and EtherCAT Coupler

Best-Fit Applications

  • Spindle-position feedback on a five-axis CNC where an NX102-1200 polls the 4 MHz A/B signal over EtherCAT at the primary task period
  • Cut-to-length registration on a packaging machine where the NX-EC0132 reads a 600 P/R encoder on the draw roll and gates on a prox sensor
  • Spare replacement on a labeling line where the original NX-EC0132 was lost and the Sysmac Studio tag database points at the same I/O map

Buying Checklist

  • Pick the NX-EC0132 when the project needs one RS-422 line-receiver encoder channel with NPN external inputs on a 24 mm wide NX slice.
  • Pick the NX-EC0142 instead when the external inputs need PNP (sourcing) instead of NPN (sinking) on the same 1-channel line receiver.
  • Pick the NX-EC0112 instead when the encoder outputs 24 VDC voltage instead of RS-422 differential and the inputs are NPN.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series NX-series Position Interface Unit (NX-EC family) on NX I/O Bus and EtherCAT Coupler
Model / SKU NX-EC0132
Number of Channels 1 encoder channel
Input Signal Line receiver (RS-422); phases A and B 4 MHz single-phase / 1 MHz x4 phase-difference; phase Z 1 MHz
Counter Range -2,147,483,648 to +2,147,483,647 pulses (32-bit); ring or linear counter
External Inputs 3 points NPN, 24 VDC +20%/-15%, 1 microsecond ON/OFF response, 3.5 mA typical at 24 VDC
Encoder Supply 5 VDC +/-5%, 500 mA max output from a non-isolated supply; A/B/Z signals use a digital isolator
Input Modes Phase difference x2 / x4, pulse + direction, up/down pulse
Refreshing Free-Run, Synchronous, or Task Period Prioritized refreshing
Connection / Power Screwless push-in 12-terminal x 2; NX unit power 1.25 W max on CPU, 0.95 W max on Communications Coupler; 24 VDC supply via NX bus
Dimensions / Approvals 12 (W) x 100 (H) x 71 (D) mm; 130 g; IP20; SIL None (not for safety); CE, cULus, RCM, KC, EAC

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-EC0132

What is the Omron NX-EC0132 used for?
It is the NX-series 1-channel incremental encoder input unit for RS-422 line-receiver signals. Typical uses are spindle-position feedback on a five-axis CNC, cut-to-length registration on a packaging machine, and replacement of an NX-EC0132 on a labeling line where the Sysmac Studio tag database points at the same I/O map.
NX-EC0132 vs NX-EC0142 - what is the difference?
Both are NX-series 1-channel incremental encoder inputs with RS-422 line-receiver input. The NX-EC0132 has 3 NPN external inputs; the NX-EC0142 has 3 PNP external inputs. Maximum encoder input frequency (4 MHz on A/B, 1 MHz on Z), 5 VDC 500 mA encoder supply, and 24 x 100 x 71 mm body are the same on both. Pick the NX-EC0132 for NPN field devices; pick the NX-EC0142 for PNP field devices.
What is the maximum encoder frequency for the NX-EC0132?
4 MHz on phases A and B in single-phase mode, 1 MHz in 4x phase-difference mode, and 1 MHz on phase Z. The 32-bit counter covers +/-2,147,483,647 pulses in ring or linear mode with two external latch inputs plus one internal latch. Refresh mode can be Free-Run, Synchronous, or Task Period Prioritized in Sysmac Studio.
Can the NX-EC0132 supply power to the encoder?
Yes. The slice supplies 5 VDC at 500 mA from an isolated output. This covers most 5 VDC line-driver encoders on the market. For a 24 VDC encoder or a heavy-load encoder, power the encoder from a separate 24 VDC supply and wire only the A, B, Z signals to the NX-EC0132 screwless terminal.
Is the NX-EC0132 suitable for safety functions?
No. The NX-EC0132 is marked SIL None and is not for safety functions. For an encoder on a safety-controlled axis (SIL 2 / PL d), use the NX-EC0132 only for the standard (non-safety) position loop, and put the safety encoder on an NX-SL3300 or NX-SL3500 safety controller.
