Omron NX-ECC203 — front face of the NX EtherCAT Coupler showing the two shielded RJ45 EtherCAT ports, the TS and RUN indicator LEDs, the rotary node-address switch and the unit version label

Omron NX-ECC203 — EtherCAT Coupler, 63 NX Units

SKU: NX-ECC203

USD 105.00

EtherCAT Coupler for NX I/O, 2 RJ45 ports, 125 us cycle, 63 NX units, 10 A I/O. In stock, China.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-ECC203 is an NX-series EtherCAT Coupler Unit that attaches up to 63 NX I/O slices to an EtherCAT master It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series EtherCAT Coupler Unit datasheet.

Two shielded RJ45 ports carry the EtherCAT IN and OUT lines at 100 Mbps, and from unit Ver. 1.5 the NX-ECC203 supports ring topology for cable-redundant cabinets. Cycle time is 125 to 10,000 us in DC mode, and the unit supports Free-Run, Synchronous I/O, Time-stamp, and Task-period prioritized refreshing for motion and high-speed applications.

Body size is 46 x 100 x 71 mm at 170 g. Key specs: Number of Connectable NX Units 63 NX units maximum; PDO Data Size 1,024 bytes each, input and output; Communications Cycle (DC Mode) 125 to 10,000 us; I/O Jitter 1 us input, 1 us output; Node Address Range 1-192 via the rotary switch, 1-192 via Sysmac Studio; Refreshing Methods Free-Run, Synchronous I/O, Time-stamp, Task-period prioritized; Topology Support Line, daisy-chain; ring from Ver. 1.5; Unit Power Supply 24 VDC (20.4-28.8 VDC), up to 10 W.

Key Features

  • NX-series EtherCAT Coupler with 2 shielded RJ45 ports, 100 Mbps
  • 125 to 10,000 us cycle in DC mode, 1,024 bytes PDO input and output
  • Supports ring topology from unit Ver. 1.5, plus line and daisy-chain
  • 10 W unit power, 10 A I/O power, 46 x 100 x 71 mm, 170 g
  • SKU: NX-ECC203
  • Series: NX-series EtherCAT Coupler Unit
  • Voltage: 24 VDC
  • I/O: 5 I/O

Best-Fit Applications

  • Ring-topology EtherCAT cabinet linking two NX-ECC203 couplers over a redundant trunk for a press-shop press line.
  • Distributed motion cell pairing the NX-ECC203 with NX-EC0132 encoder inputs and R88D-KN drives on a single EtherCAT trunk.
  • Modular machine retrofit where NX-IO units migrate from a legacy CJ1W to a Sysmac NJ5 without rewiring the field devices.

Buying Checklist

  • Choose the NX-ECC203 when the cabinet needs ring-topology EtherCAT redundancy or a 125 us minimum cycle.
  • Choose the NX-ECC201 instead when the cycle stays above 250 us and no ring topology is required.
  • Choose the NX-ECC202 instead when the standard 4 A I/O current is enough and you want lower cost.

Technical Specifications

Series NX-series EtherCAT Coupler Unit
Number of Connectable NX Units 63 NX units maximum
PDO Data Size 1,024 bytes each, input and output
Communications Cycle (DC Mode) 125 to 10,000 us
I/O Jitter 1 us input, 1 us output
Node Address Range 1-192 via the rotary switch, 1-192 via Sysmac Studio
Refreshing Methods Free-Run, Synchronous I/O, Time-stamp, Task-period prioritized
Topology Support Line, daisy-chain; ring from Ver. 1.5
Unit Power Supply 24 VDC (20.4-28.8 VDC), up to 10 W
I/O Power Supply 5-24 VDC (4.5-28.8 VDC), up to 10 A
NX Unit Power Consumption 1.25 W max
Dimensions 46 x 100 x 71 mm, 170 g, IP20

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-ECC203

Does the NX-ECC203 support ring topology?
Yes, from unit Ver. 1.5 and later the NX-ECC203 supports ring topology for cable-redundant EtherCAT cabinets. The Ver. 1.0 release supports line and daisy-chain only. Check the unit-version sticker on the front of the coupler to confirm the build version.
How many NX I/O units can the NX-ECC203 connect?
Up to 63 NX I/O slices per coupler. The cyclic PDO size is 1,024 bytes for input and 1,024 bytes for output. For cabinets larger than 63 slices, split across multiple NX-ECC203 couplers and connect them to the same EtherCAT master.
What is the difference between NX-ECC201, NX-ECC202 and NX-ECC203?
The 201 is the original unit at 250 to 4,000 us cycle and 4 A I/O power. The 202 extends the cycle down to 125 us. The 203 adds ring topology from Ver. 1.5 and raises the I/O current to 10 A. For most new Sysmac cabinets, pick the 203 unless the application needs no ring topology.
Can the NX-ECC203 host NX safety I/O over FSoE?
Yes - the NX-ECC203 supports FSoE when an NX-SL3300 or NX-SL3500 Safety CPU is mounted on the same rack. Safety I/O units like NX-SID800 and NX-SOD400 mount alongside standard NX I/O on the same EtherCAT sub-node. Verify Sysmac Studio V1.10 or later for full FSoE configuration.
