Omron NX-RS1201 — NX Load Cell Input, 24-bit
SKU: NX-RS1201USD 195.00
Omron NX-RS1201 NX-series load cell input unit, -5 to +5 mV/V, 24-bit, 125 us. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-RS1201 is the NX-series 1-channel load cell input unit, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
It reads a single load cell at -5.0 to +5.0 mV/V into a 24-bit A/D at 125 us conversion. The unit supplies 5 VDC excitation at 60 mA to power the load cell. Both 4-wire and 6-wire load-cell connections are supported. Accuracy is +/- 0.01 percent F.S. nonlinearity and +/- 0.1 uV/degree C zero drift.
NX Unit power is 2.05 W max on a CPU Unit or Communication Control Unit, 1.70 W max on a Communications Coupler Unit. No I/O power supply is consumed. Isolation is transformer (power) and digital isolator (signal) between input and NX bus. The 12 x 100 x 71 mm housing weighs 70 g. The unit supports Free-Run, synchronous or task period prioritized I/O refresh. For RTD or thermocouple input pick the NX-TS3101 or NX-TS3201.
Key Features
- NX-series 1-channel load cell input unit, -5.0 to 5.0 mV/V, 24-bit A/D, 125 us conversion cycle
- 5 VDC +/- 10 percent load cell excitation at 60 mA max, supports 4-wire and 6-wire load-cell wiring
- Nonlinearity +/- 0.01 percent F.S., zero drift +/- 0.1 uV/degree C RTI, gain drift +/- 10 ppm/degree C
- Transformer and digital isolator between input and NX bus, 12 mm wide, 70 g, IP20, no I/O power consumed
- SKU: NX-RS1201
- Series: NX-series machine automation I/O, load cell input family (NX-RS)
Best-Fit Applications
- Tank weighing on a batching skid where the NX-RS1201 reads one load cell at 125 us and the NJ501 closes the fill valve at weight
- Force measurement on a press-fit station where the NX-RS1201 captures peak force per cycle for SPC trending
- Spare replacement on an NX-ECC201 rack where the original load-cell slice was damaged and needs re-insertion on the same slot
Buying Checklist
- Pick the NX-RS1201 when a single load cell needs to be read into the NX bus at 24-bit resolution and 125 us conversion.
- Pick the NX-TS3101 instead when the panel needs 4 thermocouple inputs at 0.1 C for thermal profiling rather than load-cell weighing.
- Pick the NX-TS3201 instead when the panel needs 4 Pt100/Pt1000 RTD inputs rather than load-cell weighing.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | NX-series machine automation I/O, load cell input family (NX-RS) |
| Model / SKU | NX-RS1201 |
| Number of Channels | 1 load cell input, differential |
| Input Range | -5.0 to 5.0 mV/V; input conversion range -5.5 to 5.5 mV/V; zero/gain adjustment -5.0 to 5.0 mV/V |
| Excitation | 5 VDC +/- 10 percent, output current 60 mA max |
| Resolution / Accuracy | 24-bit A/D; 125 us conversion; nonlinearity +/- 0.01 percent F.S.; zero drift +/- 0.1 uV/degree C RTI; gain drift +/- 10 ppm/degree C |
| I/O Refresh | Free-Run refreshing, synchronous I/O refreshing, or task period prioritized refreshing |
| Power | NX Unit power 2.05 W max on CPU, 1.70 W max on Communications Coupler Unit; no I/O power supply consumed |
| Isolation | Transformer (power) and digital isolator (signal) between input and NX bus; insulation 20 MOhm min at 100 VDC; dielectric 510 VAC for 1 minute at 5 mA max |
| Warm-up / Wiring | Warm-up 30 minutes; screwless clamping terminal block, 16 terminals; 6-wire and 4-wire load-cell wiring diagrams in user manual W565 |
| Environment / Wiring | 0 to 55 C operating, 10 to 95 percent humidity; 12 (W) x 100 (H) x 71 (D) mm; 70 g; DIN 35 mm rail mount; IP20; KC, RCM, NK, EN 61131-2, cULus, ANSI/ISA 12.12.01 approvals |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-RS1201
What is the Omron NX-RS1201 used for?
It is the NX-series 1-channel load cell input unit. It reads a single load cell at -5.0 to 5.0 mV/V into a 24-bit A/D at 125 us conversion. Typical uses are tank weighing on batching skids, force measurement on press-fit stations, and spare replacement on a damaged NX-ECC201 rack slice.
Does the NX-RS1201 work with 4-wire and 6-wire load cells?
Yes. The NX-RS1201 supports both 4-wire and 6-wire load-cell wiring diagrams in the NX-series Load Cell Input Unit User's Manual (W565). 6-wire is preferred for long cable runs because it adds sense lines that compensate for cable resistance. The screwless 16-terminal block carries excitation plus, excitation minus, sense plus, sense minus, signal plus and signal minus.
What is the resolution of the NX-RS1201?
24-bit A/D converter. Conversion cycle is 125 us per Unit. Accuracy is specified as +/- 0.01 percent F.S. nonlinearity, +/- 0.1 uV/degree C RTI zero drift and +/- 10 ppm/degree C gain drift. Warm-up period is 30 minutes before the rated accuracy applies.
NX-RS1201 vs NX-TS3101 - what is the difference?
The NX-RS1201 is a 1-channel load cell input unit (-5 to 5 mV/V, 24-bit, 125 us). The NX-TS3101 is a 4-channel thermocouple temperature input unit (0.1 C resolution, 250 ms per Unit). Pick the NX-RS1201 for force or weight measurements from a load cell. Pick the NX-TS3101 when the panel needs 4 thermocouple inputs for thermal profiling.
