Omron NX-TC3406 — front face of the NX-series 4-loop temperature control unit showing the 24 mm wide housing with the green TS indicator on the upper left, two 16-pin screwless push-in terminal blocks side by side with the channel A/B/C/D markings, the OUT LEDs for each of the four loops and the NX-TC3405 model label on the lower right

Omron NX-TC3406 — 4-Loop Temperature Controller

SKU: NX-TC3406

USD 120.00

NX-series 4-loop temperature controller, thermocouple and Pt100 input, PNP SSR-drive output. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-TC3406 is the NX-series 4-loop temperature control unit It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. It accepts 4 inputs from thermocouple K, J, T, E, L, U, N, R, S, B, C/W or PLII types, or from Pt100, JPt100 or Pt1000 RTDs on 3-wire. Each loop runs a voltage control output (for SSR drive) on a PNP common at 21 mA per point and 84 mA per unit, with load short-circuit protection. NX Unit power is 1.70 W max on a CPU, 1.25 W max on a Communications Coupler. Key specs: Number of Loops 4 control loops; 1 temperature input per loop, 1 control output per loop; Input Sensors Thermocouple K, J, T, E, L, U, N, R, S, B, C/W, PLII; Pt100 (3-wire), JPt100 (3-wire), Pt1000 (3-wire); Resolution / Accuracy 0.1 C max resolution; input conversion range +/-20 C of input range; cold junction compensation error +/-1.2 C; Control Output Voltage output for SSR drive, 1 point per loop, PNP common; 21 mA per point, 84 mA per.

Key Features

  • NX-series 4-loop temperature control unit with one input and one SSR-drive output per loop
  • Thermocouple K, J, T, E, L, U, N, R, S, B, C/W, PLII and Pt100, JPt100, Pt1000 RTD inputs
  • PNP voltage output (SSR drive) at 21 mA per point, 84 mA per unit, load short-circuit protection
  • 50 ms conversion time per unit, 0.1 C resolution, control period 0.1 to 99 s, Heat or Cool
  • SKU: NX-TC3406
  • Series: NX-series machine automation I/O, temperature control family (NX-TC)

Best-Fit Applications

  • Injection-molding barrel zone control where the NX-TC3406 reads 4 thermocouples and drives 4 SSRs at 50 ms per loop and 1 s control period
  • Multi-zone oven control on a packaging sealer where the NX-TC3406 holds 4 Pt100 RTDs at setpoint and outputs SSR drive pulses to 4 heaters
  • Spare replacement on a legacy E5CC panel where the NX-TC3406 adds EtherCAT visibility to 4 temperature loops on a Sysmac NJ501 without field wiring changes

Buying Checklist

  • Pick the NX-TC3406 for 4 loops of temperature control with TC or RTD sensors and PNP SSR-drive outputs on the 24 mm wide NX body.
  • Pick the NX-TC3405 instead when the same 4 loops need CT inputs for heater burnout detection (NX-TC3405 has the CT inputs and the NX-TC3406 does not).
  • Pick the NX-TS3201 instead when the panel only needs 4 RTD temperature inputs without closed-loop control (read-only, no control outputs).

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series NX-series machine automation I/O, temperature control family (NX-TC)
Model / SKU NX-TC3406
Number of Loops 4 control loops; 1 temperature input per loop, 1 control output per loop
Input Sensors Thermocouple K, J, T, E, L, U, N, R, S, B, C/W, PLII; Pt100 (3-wire), JPt100 (3-wire), Pt1000 (3-wire)
Resolution / Accuracy 0.1 C max resolution; input conversion range +/-20 C of input range; cold junction compensation error +/-1.2 C
Control Output Voltage output for SSR drive, 1 point per loop, PNP common; 21 mA per point, 84 mA per unit; max inrush 0.3 A/point for 10 ms; load short-circuit protection
Control Performance Control period 0.1, 0.2, 0.5, 1 to 99 s; manipulated variable -5 to +105 percent; conversion time 50 ms per unit
Control Function Heat or Cool (standard control); Free-Run I/O refresh; no heater burnout detection (add NX-HB3201)
Power NX Unit power 1.70 W max on CPU, 1.25 W max on Communications Coupler Unit; I/O supply current 20 mA max
Isolation Transformer (power) and digital isolator (signal) between sensor input and internal circuit and between sensor inputs; photocoupler between control output and internal circuit; non-insulated between control outputs
Environment / Wiring 0 to 55 C operating; 24 (W) x 100 (H) x 71 (D) mm; 140 g; 2 x 16-position screwless push-in terminal block; IP20; warm-up 30 minutes

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-TC3406

What is the Omron NX-TC3406 used for?
It is the NX-series 4-loop temperature control unit. Each of the four loops reads a thermocouple or Pt100/JPt100/Pt1000 RTD sensor and outputs a PNP voltage pulse for SSR drive. Typical uses are injection-molding barrel zones, multi-zone oven sealers, and any Sysmac NJ/NX panel where four loops of closed-loop temperature control need to live on a single 24 mm wide slice.
NX-TC3406 vs NX-TC3405 - what is the difference?
Both are NX-series 4-loop temperature control units with the same footprint, conversion time, and PNP voltage outputs. The NX-TC3405 includes 4 CT inputs for heater burnout detection; the NX-TC3406 does not. Pick the -3405 when each heating element needs current monitoring for heater failure detection; pick the -3406 when the panel only needs temperature control.
What sensors work with the NX-TC3406?
Thermocouples K, J, T, E, L, U, N, R, S, B, C/W and PLII on the thermocouple side; Pt100, JPt100 and Pt1000 on 3-wire RTD. Input impedance is 20 kOhm min and absolute maximum rating is +/-130 mV. Input conversion range is +/-20 C of the input range. Resolution is 0.1 C max. Cold junction compensation error is +/-1.2 C.
Can the NX-TC3406 do PID and ON/OFF control?
Yes. The control function is Heat or Cool with selectable control period from 0.1, 0.2, 0.5 and 1 to 99 s. PID autotuning is supported in Sysmac Studio and runs at 50 ms per unit. ON/OFF control is selectable per loop through the control period and manipulated variable -5 to +105 percent configuration.
