Omron NX-TC3405 — 4-Loop Temperature Control
SKU: NX-TC3405USD 120.00
Omron NX-TC3405 NX temperature control, 4 loops, thermocouple + Pt100, 4 CT inputs. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-TC3405 is a temperature control unit from the NX-series I/O family, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The unit drives 4 PID loops with one multi-input thermocouple / RTD input per loop. Sensors include types B, C, E, J, K, L, N, P (PL II), R, S, T, U, plus Pt100, Pt1000, and resistance. Each loop has one PNP transistor output for SSR drive (24 VDC, 21 mA per point, PWM 5 to 50 ms) and one CT input for heater burnout detection from 0.0 to 50.0 A.
Conversion time is 50 ms across all 4 channels. The NX-TC3405 mounts on an NX102 CPU, NX1P2 CPU, or NX-ECC EtherCAT coupler. For 2-loop control, pick the NX-TC2405. To drop the CT inputs, the NX-TC3406 is the same loop count without heater burnout. Programming is in Sysmac Studio.
Key Features
- NX-series temperature control unit, 4 loops, multi-input thermocouple / Pt100 / Pt1000 / mV / resistance
- 4 PNP transistor outputs for SSR drive, 24 VDC at 21 mA per point, PWM cycle 5 to 50 ms
- 4 CT inputs for heater burnout detection from 0.0 to 50.0 A, 0.1 A resolution
- 50 ms conversion time per Unit, free-run refreshing, Push-in Plus terminal blocks, IP20
- SKU: NX-TC3405
- Series: Omron NX-series temperature control unit
Best-Fit Applications
- Four-zone extrusion line where each PID loop holds a barrel heater to within +/-1 C using SSR drive and CT-input heater burnout alarm
- Multi-zone reflow oven where one NX-TC3405 drives four heater zones while the host NX102 runs the conveyor and cooling profile
- Spare replacement on a plastic-injection molding machine where the previous 2-loop controller has been upgraded to 4 loops for one manifold
Buying Checklist
- Pick the NX-TC3405 for a 4-loop NX temperature control unit with heater burnout detection on each loop.
- Pick the NX-TC2405 instead when the cell needs 2 loops in the same NX-TC body.
- Pick the NX-TC3406 instead when heater burnout detection is not required and the cabinet needs the same 4 loops at lower cost.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NX-series temperature control unit |
| Model / SKU | NX-TC3405 |
| Number of Channels | 4 loops with 1 temperature input + 1 CT input + 1 control output per loop |
| Sensor Inputs | Thermocouple B / C / E / J / K / L / N / P (PL II) / R / S / T / U, Pt100, Pt1000, resistance |
| Control Outputs | 4 PNP transistor outputs, 24 VDC, 21 mA per point, PWM 5 to 50 ms cycle |
| CT Inputs | 4 current transformer inputs, 0.0 to 50.0 A, 0.1 A resolution, heater burnout detection |
| Control Mode | Standard control with autotuning at power-up, 2-PID with set point profile |
| Conversion Time | 50 ms per Unit (all 4 channels) |
| I/O Refreshing | Free-run refreshing on coupler |
| Connection / Environment | Two 16-terminal Push-in Plus connectors, IP20, 24 VDC supply (20.4 to 28.8 VDC), 24 (W) x 100 (H) x 71 (D) mm, 140 g |
| Power Consumption | 0.95 W max from CPU, 20 mA max from I/O supply |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-TC3405
What sensors does the NX-TC3405 accept?
Thermocouple types B, C, E, J, K, L, N, P (PL II), R, S, T, U, plus Pt100, Pt1000 RTD and direct resistance. Up to 4 sensors of any supported type, one per loop.
Does the NX-TC3405 have heater burnout detection?
Yes. Each loop has a current transformer (CT) input that monitors the heater current from 0.0 to 50.0 A and raises an alarm when the current falls below the configured band.
NX-TC3405 vs NX-TC2405 - what is the difference?
The NX-TC3405 is the 4-loop variant. The NX-TC2405 is the 2-loop variant in the same housing. Both support the same thermocouple / RTD inputs and PNP transistor outputs.
