Omron R88D-KN15F-ECT-Z — G5 Servo Drive, 1.5 kW, 400 V
SKU: R88D-KN15F-ECT-ZUSD 475.00
Accurax G5 servo drive, 1.5 kW, 3-phase 400 VAC, EtherCAT, STO, Z suffix = country of origin, China. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron R88D-KN15F-ECT-Z is a 1.5 kW Accurax G5 servo drive with EtherCAT control It is manufactured by Omron Corporation. Hengyixin Automation ships this drive from Xiamen with the matching motor or PSU pairing recommended in the related products row below.
The drive runs on 3-phase 380 to 480 VAC and delivers 1.5 kW continuous output at 4.7 A. Control modes are position, speed and torque over EtherCAT (CoE).
For a 2 kW motor that pairs with this drive, use the R88M-K2K030H-S2-Z. Key specs: Rated Output 1.5 kW; Supply Voltage 3-phase 380 to 480 VAC (400 V class); Continuous Output Current 4.7 A; Control Method EtherCAT (CoE), position / speed / torque; Encoder Feedback 23-bit absolute encoder; Frequency Response 2 kHz; Safety Function STO (Safe Torque Off), PLe per ISO 13849-1, SIL 3 per IEC 61508; Operating Temperature 0 to 55 degC.
Key Features
- Accurax G5 EtherCAT servo drive, 1.5 kW rated output
- 3-phase 380 to 480 VAC supply, 4.7 A continuous output current
- Position / speed / torque control, 23-bit absolute encoder feedback
- Built-in STO (Safe Torque Off), PLe / SIL 3, 2 kHz response
- SKU: R88D-KN15F-ECT-Z
- Series: Omron Accurax G5-series servo drive (EtherCAT type)
- Voltage: 380 TO 480 VAC
Best-Fit Applications
- Indexing table on a bottling line where the 1.5 kW matches the turntable load and EtherCAT keeps the table in sync with the filler
- Robot transfer axis on a packaging cell where the STO function ties into the cell's safety relay without extra wiring
- Spare drop-in on a G5 retrofit where the existing Sysmac Studio project loads over EtherCAT and the motor encoder map carries over
Buying Checklist
- Pick the R88D-KN15F-ECT-Z for a 1.5 kW 400 V G5 EtherCAT drive with STO.
- Pick the R88D-KN02H-ECT-Z instead when the cabinet runs on 200 V single / 3-phase at 200 W output.
- Pick the R88D-KN15H-ECT-Z instead when the -Z suffix is not the variant you need.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron Accurax G5-series servo drive (EtherCAT type) |
| Model / SKU | R88D-KN15F-ECT-Z |
| Rated Output | 1.5 kW |
| Supply Voltage | 3-phase 380 to 480 VAC (400 V class) |
| Continuous Output Current | 4.7 A |
| Control Method | EtherCAT (CoE), position / speed / torque |
| Encoder Feedback | 23-bit absolute encoder |
| Frequency Response | 2 kHz |
| Safety Function | STO (Safe Torque Off), PLe per ISO 13849-1, SIL 3 per IEC 61508 |
| Operating Temperature | 0 to 55 degC |
| Dimensions / Weight | ~150 (H) x 175 (W) x 130 (D) mm; ~1.9 kg |
FAQ for R88D-KN15F-ECT-Z
What does the -Z suffix mean on the R88D-KN15F-ECT?
Z is the country-of-origin code (China). It does not change the safety functions. Consult the drive manual before fitting or removing any STO bypass jumper.
Which G5 motor pairs with the R88D-KN15F-ECT-Z?
Any R88M-K series G5 servo motor up to 1.5 kW. Common matches are the R88M-K1K030C-S2 (1 kW) and the R88M-K2K030H-S2-Z (2 kW) for slightly higher loads.
Does the R88D-KN15F-ECT-Z work with a CJ2 PLC?
Yes, through an NX-ECC201 or NX-ECC202 EtherCAT coupler. The drive then appears as an EtherCAT slave on the CJ2 / NJ controller's bus.
How is STO wired on the R88D-KN15F-ECT-Z?
STO uses two pairs of safety inputs on the drive's CN8 connector. Wire them to the safety relay or safety controller through the matching cable R88A-CNK02S. STO behaviour depends on how the CN8 safety connector is wired — check the manual.
