Omron R88M-1M20030H-S2 1S servo motor — front 60 mm flange face with shaft and M5 mounting holes on 70 mm BCD

Omron R88M-1M20030H-S2 — 200 W 1S Servo Motor, Hi-I

SKU: R88M-1M20030H-S2

USD 145.00

1S-series high-inertia 200 W AC servo motor, 230 VAC single-phase, 3000 rpm, 0.637 Nm rated / 2.2 Nm peak, 23-bit incremental encoder, EtherCAT — pairs with R88D-1SN02H-ECT drive.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The R88M-1M20030H-S2 is the 200 W high-inertia member of Omron's 1S-series servo family — a 60 mm flange-face, 11 mm shaft, 23-bit incremental encoder servo motor purpose-built for belt-driven conveyors, ball-screw stages, and other loads with significant reflected inertia. The 'H' suffix in R88M-1M20030H vs 'T' suffix in R88M-1M20030T distinguishes high-inertia from low-inertia: this SKU (H) carries roughly 2× the rotor inertia, which smooths out step-and-direction motion and provides better rejection of low-frequency load disturbances. The encoder is a 23-bit (8,388,608 pulse/rev) optical incremental unit — a battery-less absolute version would have a 'C' suffix (R88M-1M20030C-S2). The 'S2' suffix means the motor has no brake and no oil seal.

When to pick high inertia vs low inertia

The H/T split is one of the most important choices in the 1S family. High inertia (H, this SKU) is best for: belt-driven conveyors, ball-screw stages with ballscrew inertia, large-diameter rotary tables, and any application where the load inertia exceeds the motor's rotor inertia. The additional rotor mass on the H variant acts as a mechanical low-pass filter on torque ripple, giving smoother motion at low speeds. Low inertia (T, R88M-1M20030T-S2) is best for: chip-mount machines (pick-and-place), small direct-drive stages, and rapid short-stroke cycling where peak acceleration matters more than steady-state smoothness.

1S-series advantages vs G5 predecessor

The 1S (R88M-1M) family replaced the G5 (R88M-K) family in 2021 as the workhorse compact servo line.

Key Features

  • 200 W rated output, 230 VAC single-phase supply
  • 0.637 Nm rated torque, 2.2 Nm peak torque
  • 3 000 rpm rated speed, 5 000 rpm maximum mechanical speed
  • 23-bit incremental encoder on this SKU
  • High-inertia rotor — ideal for belt-driven conveyors and ball-screw loads
  • 60 mm flange face, 11 mm shaft diameter, with keyway option
  • Pairs with R88D-1SN02H-ECT 1S-series EtherCAT drive
  • STO PL d via FSoE when paired with the 1S EtherCAT drive
  • SKU: R88M-1M20030H-S2
  • Series: R88M-1M (1S-series servo motor family)
  • Voltage: 230 V
  • I/O: 200 I/O

Best-Fit Applications

  • Belt-driven conveyor tracking — high-inertia rotor smooths indexing motion at 1–2 kg load inertia
  • Ball-screw staging on small-format CNC lathes where load inertia is comparable to rotor inertia
  • Pick-and-place Z-axis on chip mounters where short-stroke peak acceleration is needed and a holding brake is required
  • Inline labeler drive for product orientation and feed-roller positioning on packaging lines

Buying Checklist

  • Pick the R88M-1M20030H-S2 when the load inertia is comparable to or greater than the motor rotor inertia — the high-inertia rotor smooths step-and-direction motion
  • Pick the R88M-1M20030T-S2 when the load inertia is low and peak acceleration is the bottleneck
  • Pick the R88M-1M20030C-S2 when the application needs absolute multi-turn position
  • Pick the R88M-1M20030H-BS2 for any vertical axis where the load must not free-fall on power removal
  • Pick the R88M-1M20030H-S2-Z for Simulink-compatible drive profiles
  • Pick the R88M-1L1K030H-S2 if the application needs 1 kW instead of 200 W

Technical Specifications

Model R88M-1M20030H-S2
Series R88M-1M (1S-series servo motor family)
Type AC rotary servo motor, permanent-magnet brushless
Rated Output 200 W (0.2 kW)
Drive Supply Voltage 230 V single-phase / 3-phase
Rated Speed 3 000 r/min
Maximum Speed 5 000 r/min
Rated Torque 0.637 Nm
Encoder Type 23-bit incremental optical encoder (8 388 608 pulses/rev)
Mounting Front flange-mount via 4 × M5 holes on 70 mm BCD
Operating Temperature 0 to +40 °C (no icing), derate above
Storage Temperature -20 to +65 °C
Certifications UL, CSA, CE, RoHS

FAQ for R88M-1M20030H-S2

What's the difference between the R88M-1M20030H-S2 and the T-suffix variant?
Both are 200 W EtherCAT 1S servo motors, but the rotor inertia differs — the H (high inertia) variant has roughly 2× the rotor inertia of the T (low inertia) variant. The H variant smooths step-and-direction motion and reduces low-frequency load-disturbance amplification — best for belt-driven conveyors, ball-screw stages, and any application where load inertia approaches rotor inertia. The T variant accelerates faster from standstill and reverses faster — best for chip mount and short-stroke machine axes.
What drive does this motor pair with?
The R88D-1SN02H-ECT — 1S-series 200 W EtherCAT drive, single-phase 230 VAC input. The drive handles the motor's 0.637 Nm continuous torque and 2.2 Nm peak torque at 3000 rpm. For servo systems that need Simulink-compatible drive profiles for model-based design, use the R88D-1SN02H-ECT-Z variant (-Z suffix = Simulink profile). For STO safety, the drive supports FSoE STO PL d via EtherCAT when wired through an NX-SL5500 safety controller.
What cables do I need to order with the motor?
Two cables are mandatory: (1) the power cable — R88A-CRGB001-5-E1R for 1 m, or longer for longer distances. (2) the encoder cable — R88A-CRGBE001-5-E1R for 1 m, or longer. The bare motor (this SKU) does not include cables — Omron sells the cable separately to avoid useless stocking of wrong-length cables. For the brake option -BS2 you also need the R88A-CRGB-RA-LEP brake lead. For washdown / oil-mist environments upgrade to the -5B1 (IP67 robot cable) version of each cable.
Can I use this motor with an Accurax G5 drive instead of a 1S drive?
No — the 1S (R88M-1M) and G5 (R88M-K) servo motors use different encoder protocols and different winding designs. The 1S requires an R88D-1S or R88D-1S@-ECT drive; pairing a 1S motor with a G5 drive will not synchronise the encoder and the drive will report a 'motor type mismatch' fault at commissioning. Similarly, do not pair a G5 motor (e.g. R88M-K20030H-S2) with a 1S drive.
