Omron R88M-1M75030H-S2 — Drive
SKU: R88M-1M75030H-S2USD 158.00
Accurax 1S-series AC servo motor, 750 W at 3000 rpm, 2.39 Nm rated / 8.4 Nm peak torque, 200 V class single-phase, 23-bit incremental encoder, straight keyed shaft, no brake, pairs with R88D-1SN08H-ECT EtherCAT drive.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The R88M-1M75030H-S2 is the 750 W member of Omron's Accurax 1S servo-motor family, the next-generation platform that succeeds the G5 series with a more compact body, higher encoder resolution, and battery-free multi-turn absolute encoder option. It delivers 2.39 Nm of rated torque at 3000 rpm with a peak torque of 8.4 Nm (350 % of rated) for fast acceleration and deceleration profiles — more headroom than the G5 family at the equivalent power. The 23-bit incremental encoder (H in the part number) gives 8,388,608 pulses per revolution, the highest resolution in Omron's 1S range, suitable for applications demanding sub-micron positioning accuracy such as semiconductor handling, precision assembly, and high-end packaging.
1S series vs G5 series
The Accurax 1S series (R88M-1) is the current-generation servo motor that supersedes the G5 series (R88M-K) for new designs. Compared to the equivalent G5 motor, the 1S has higher peak torque (350 % vs 300 %), higher encoder resolution (23-bit vs 20-bit), smaller body length for the same power, and battery-free multi-turn absolute encoder option. The 1S also adds Safe Torque Off (STO) integrated into the R88D-1SN drive as standard, simplifying safety wiring for new installations. Pick R88M-1M75030H-S2 (1S, this SKU) for new Sysmac-platform designs with NJ501, NX102, or NX1P controllers.
Mechanical integration and applications
The R88M-1M75030H-S2 has an 80 × 80 mm flange (LC dimension) and uses a 70 mm pilot diameter, the standard for 750 W class servo motors. Total length is approximately 124 mm without brake and weight is around 2.5 kg — compact for a 750 W axis. The shaft is 19 mm diameter with a keyway and a tapped M6 × 12 hole on the end for coupling attachment — use a flexible jaw coupling (Omron R88A-CSK series) or a zero-backlash servo coupling.
Key Features
- 750 W rated output at 3000 rpm, 2.39 Nm rated torque
- Peak torque 8.4 Nm for high-acceleration moves
- 23-bit incremental encoder, 8,388,608 pulses per revolution
- 200 V class drive, single-phase 230 VAC compatible
- Straight shaft with keyway and M6 tapped hole for coupling
- Pairs with R88D-1SN08H-ECT EtherCAT drive
- Compatible with NJ501-1300 / NJ501-1400 / NX102-1000 controllers via EtherCAT
- 80 × 80 mm flange, 124 mm length, ~2.5 kg
- SKU: R88M-1M75030H-S2
- Series: Accurax 1S (R88M-1)
- Voltage: 230 V
- I/O: 750 I/O
Best-Fit Applications
- Registration axis on a packaging line requiring sub-mm accuracy at line speed
- Index drum on a small labelling machine with 23-bit position feedback
- Small slide on a precision dispenser with high-resolution positioning
- Rotary table on a small assembly cell with battery-free multi-turn absolute
Buying Checklist
- Pick R88M-1M75030H-S2 for 750 W 200 V 1S-series axis with 23-bit incremental encoder and no brake
- Pick R88M-1M75030H-BS2 if the axis is vertical and needs a 24 VDC holding brake
- Pick R88M-1M75030T-S2 if you need absolute position retention through power cycles
- Pick R88M-1M75030F-S2 if your drive bus is 400 V three-phase
- Pick R88M-K75030H-S2 only for compatibility with existing G5 wiring and drives
- Order the R88A-CSK19S flexible coupling matched to the 19 mm shaft
Technical Specifications
| Model | R88M-1M75030H-S2 |
|---|---|
| Series | Accurax 1S (R88M-1) |
| Type | AC servo motor |
| Rated Output | 750 W |
| Rated Speed | 3000 rpm |
| Rated Torque | 2.39 Nm |
| Peak Torque | 8.4 Nm |
| Rated Current | 4.1 A rms |
| Instantaneous Max Current | 17.4 A rms |
| Drive Supply Voltage | 230 V single phase |
| Encoder Resolution | 8,388,608 pulses/rev |
| Series Suffix | H = 200 V + 23-bit incremental; T = 200 V + battery-free absolute |
Resources & Downloads
FAQ for R88M-1M75030H-S2
What drive pairs with the R88M-1M75030H-S2?
The 1S-series drive R88D-1SN08H-ECT (EtherCAT) for new installations. For 400 V three-phase panels, use the R88D-1SN08F-ECT. Do not pair the 1S motor with a G5-series drive (R88D-KN08H-ECT) — the motor parameter sets and encoder feedback protocols differ.
What is the difference between R88M-1M75030H-S2 and R88M-K75030H-S2?
Same 750 W power, same 3000 rpm speed, same 200 V drive, same S2 (no brake) shaft. The 1S (R88M-1) is the current-generation with 23-bit encoder (8,388,608 pulses/rev) and 350 % peak torque; the G5 (R88M-K) is the previous generation with 20-bit encoder and 300 % peak torque. Pick 1S for new designs with NJ501 / NX102 / NX1P; pick G5 for compatibility with existing G5 systems.
Does the R88M-1M75030H-S2 have a battery?
No — the H suffix means 23-bit incremental encoder, which does not need a battery. If you need absolute position retention through power cycles, order the R88M-1M75030T-S2 (T suffix = 17-bit battery-free absolute encoder) or the R88M-1M75030T-BS2 (with brake). The 1S multi-turn absolute encoder uses an electronic counter that does not require a backup battery, unlike the G5 absolute encoder which did.
What controller pairs with the R88M-1M75030H-S2 over EtherCAT?
Any Sysmac controller: NJ501-1300, NJ501-1400, NJ501-1500, NX102-1000, NX102-1100, NX102-1200, or NX1P2-1040DT. Connect the R88D-1SN08H-ECT drive to the controller's EtherCAT port, scan the network in Sysmac Studio, and the axis configuration populates automatically. The 1S-series electronic data sheet (EDS) is included in Sysmac Studio 1.20 or later.
