Omron WL-3A100(WLCAL4-2 LEVER) — WL-3A100 — Lever Limit
SKU: WL-3A100(WLCAL4-2 LEVER)USD 8.50
WL-series side-rotary adjustable rod lever limit switch, SPDT, 10 A at 250 VAC, IP67 stainless steel body. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron WL-3A100 is a two-circuit lever-actuated limit switch with an adjustable rod lever It is manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box. Specs verified against the Omron product page at industrial.omron.eu/en/products/WL-3A100(WLCAL4-2 LEVER).
The switch signals a position or travel limit to a PLC or contactor coil. The WLCAL4-2 side-rotary rod lever rotates 90 degrees when a cam strikes it.
Use a 1.25 mm lead wire with M4 insulated crimp terminals on the screw block. Key specs: Actuator WLCAL4-2 side-rotary adjustable rod lever (packed separately); Contact Form SPDT (1 NO + 1 NC), snap-action, gold-clad crossbar contacts; Rated Load 10 A at 250 VAC / 6 A at 30 VDC (resistive); Mechanical Life 30 million operations minimum; Electrical Life 750,000 operations minimum at rated load; Operating Force 13.34 N maximum; Travel Specs Pretravel 15 degrees +/-5, overtravel 30 degrees min, differential 12 degrees max; Housing Stainless steel, IP67 sealed, G1/2 conduit entry.
Key Features
- 10 A at 250 VAC / 6 A at 30 VDC rated load
- IP67 stainless steel housing, G1/2 conduit entry
- 30 million mechanical operations, 750,000 electrical operations
- SPDT (1 NO + 1 NC) snap-action contact
- SKU: WL-3A100(WLCAL4-2 LEVER)
- Series: WL / WLM-series two-circuit limit switch
Best-Fit Applications
- Replacing an older WLCA2 or WL01CA2 limit switch on a retrofit without rewiring.
- Signaling the home position of a pneumatic slide when a cam strikes the lever.
- Detecting the open / closed position of a hinged guard door on a packaging machine.
Buying Checklist
- Choose WL-3A200 if you need DPDT double-pole switching instead of SPDT.
- Choose WLCA12-LD-N if you want a built-in neon indicator lamp on the same WLCA body.
- Verify the conduit is G1/2 - the WL series uses G1/2 (PF1/2 legacy) cable entry.
Technical Specifications
| Series | WL / WLM-series two-circuit limit switch |
|---|---|
| Actuator | WLCAL4-2 side-rotary adjustable rod lever (packed separately) |
| Contact Form | SPDT (1 NO + 1 NC), snap-action, gold-clad crossbar contacts |
| Rated Load | 10 A at 250 VAC / 6 A at 30 VDC (resistive) |
| Mechanical Life | 30 million operations minimum |
| Electrical Life | 750,000 operations minimum at rated load |
| Operating Force | 13.34 N maximum |
| Travel Specs | Pretravel 15 degrees +/-5, overtravel 30 degrees min, differential 12 degrees max |
| Housing | Stainless steel, IP67 sealed, G1/2 conduit entry |
| Connection | Screw terminals, M4 cover and ground screws |
| Operating Temperature | -10 to +80 degrees C |
| Approvals | CE, UL, CSA, CCC, TUV, IEC/EN 60947-5-1 |
Resources & Downloads
FAQ for WL-3A100(WLCAL4-2 LEVER)
What is the difference between WL-3A100 and WLCA12-2N-N?
Both are WL-series SPDT limit switches. WL-3A100 is the long-life body rated for 30 million mechanical operations and ships with the WLCAL4-2 adjustable rod lever. WLCA12-2N-N is a standard-body SPDT switch with a different lever (roller or rod) and 15 million mechanical operations. For the longest service life in high-cycle applications, pick the WLM long-life WL-3A100.
Can the WL-3A100 directly switch a motor contactor coil?
Yes - the SPDT contacts handle 10 A at 250 VAC, which covers most small contactor coils (typically 5-15 VA pull-in, 1-3 VA sealed). For motors above 1 HP, drive the contactor coil from the WL contacts and let the contactor switch the motor directly.
How do I adjust the lever on the WL-3A100?
Loosen the M5 Allen-head bolt on the lever hub, set the rod length (25-140 mm), and re-tighten to 4.9-5.88 N.m. The lever can be mounted in any of four directions by loosening the four head screws and rotating the head. Make sure the cam hits the lever across the central 90 degree arc, not the end stops.
