Omron 3G3MX2-A4007-V2 — MX2 Inverter, 0.75 kW, 400 V
SKU: 3G3MX2-A4007-V2USD 175.00
MX2 V2 inverter, 3-phase 400 V input, 0.75 kW heavy-duty / 1.5 kW light-duty, sensorless vector control.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron 3G3MX2-A4007-V2 is a compact variable-frequency drive in the MX2 series, rated at 0.75 kW heavy-duty (1.5 kW light-duty) on a 3-phase 400 V supply. The 'A4' in the model code marks 3-phase 400 V, '007' marks the 0.75 kW power class, and 'V2' marks the second-generation MX2 with a built-in option slot for EtherCAT, CompoNet, or DeviceNet communication cards. It runs sensorless vector control with 200 % starting torque at 0.5 Hz, includes a built-in EMC filter, and supports Safe Torque Off (STO) to EN ISO 13849-1 PLd. It is the standard pick for small conveyors, fans, pumps, and mixers on a 400 V three-phase supply.
Why the V2 variant
The MX2 line replaced the older MX and 3G3MV drives, and the V2 generation added a slot for the 3G3AX-MX2-ECT (EtherCAT), 3G3AX-MX2-CRT (CompoNet), or 3G3AX-MX2-DRT (DeviceNet) communication option cards. The bare inverter without the option card still supports RS-485 Modbus and the CX-Drive programming tool. Pick the V2 when you plan to add a fieldbus option later; pick the non-V2 MX2-A4007 if you do not need the option slot.
Heavy-duty vs light-duty
The 3G3MX2-A4007-V2 is rated 0.75 kW heavy-duty (150 % overload for 60 s) or 1.5 kW light-duty (120 % overload for 60 s). Heavy-duty is the default for conveyors, mixers, and extruders; light-duty is for fans, pumps, and other variable-torque loads. Switch the drive between HD and LD modes with parameter C0-01 in CX-Drive.
Before ordering
Confirm the supply is 3-phase 380-480 V at 50/60 Hz; for single-phase 200 V supply, pick the 3G3MX2-AB007-V2 instead. Confirm the motor is rated for the same voltage and current as the drive. Fit a line reactor on the input side when the supply impedance is low or the cable run to the drive is long. Order the 3G3AX-MX2-ECT option card if you need EtherCAT connectivity to an NJ / NX controller.
Key Features
- MX2 V2 inverter, 3-phase 380-480 V supply
- 0.75 kW heavy-duty / 1.5 kW light-duty rating
- Sensorless vector control, 200 % torque at 0.5 Hz
- Built-in EMC filter and Safe Torque Off (STO) input
- Option slot for EtherCAT / CompoNet / DeviceNet card
- RS-485 Modbus built-in, CX-Drive programming
- Output frequency up to 580 Hz
- SKU: 3G3MX2-A4007-V2
- Series: MX2 V2 inverter (3G3MX2)
- Voltage: 380-480 VAC
- I/O: 3 I/O
Best-Fit Applications
- Small conveyor drives on a packaging line at 0.75 kW
- Mixer and agitator motors on a food or chemical skid
- Pump and fan control with light-duty variable torque
- Process machine spindle or rotary table at low speed and high torque
- Building services fans on a 400 V three-phase HVAC supply
Buying Checklist
- Choose 3G3MX2-A4007-V2 for 3-phase 400 V, 0.75 kW with the option slot.
- Choose 3G3MX2-AB007-V2 for single-phase 200 V at the same power.
- Choose 3G3MX2-A4015-V2 for the next size up at 1.5 kW HD / 2.2 kW LD.
- Choose 3G3MX2-A4007 (non-V2) if no fieldbus option card is needed.
- Choose 3G3AX-MX2-ECT to add EtherCAT to an NJ / NX controller.
- Confirm the supply is 3-phase 380-480 V before ordering.
Technical Specifications
| Series | MX2 V2 inverter (3G3MX2) |
|---|---|
| Supply Voltage | 3-phase 380-480 VAC, 50/60 Hz |
| Heavy-Duty Rating | 0.75 kW (1 HP), 2.1 A |
| Light-Duty Rating | 1.5 kW (2 HP), 3.0 A |
| Output Voltage | 3-phase 380-480 VAC (matches input) |
| Output Frequency | 0.1 to 580 Hz |
| Control Method | Sensorless vector control, V/f |
| Starting Torque | 200 % at 0.5 Hz (vector) |
| Communication | RS-485 Modbus built-in |
| Option Slot | 3G3AX-MX2-ECT / -CRT / -DRT |
| Safety | STO to EN ISO 13849-1 PLd (Cat. 3) |
| Protection Rating | IP20 (panel mount) |
Resources & Downloads
FAQ for 3G3MX2-A4007-V2
What is the difference between V2 and non-V2 MX2 drives?
The V2 is the second-generation MX2 with a built-in slot for an EtherCAT, CompoNet, or DeviceNet option card (3G3AX-MX2-xxx). The non-V2 MX2 drives do not have the option slot and rely only on built-in RS-485 Modbus. Pick V2 when you plan to add a fieldbus connection to an NJ / NX controller; pick non-V2 when you do not.
Can this drive run a single-phase 200 V motor?
No. The 3G3MX2-A4007-V2 needs a 3-phase 380-480 V supply; it cannot run from single-phase 200 V. For single-phase 200 V supply, pick the 3G3MX2-AB007-V2 instead. For 3-phase 200 V, use the 3G3MX2-A2007-V2. Confirm the supply voltage and phase count before ordering the drive.
What option card adds EtherCAT to this drive?
The 3G3AX-MX2-ECT EtherCAT option card drops into the option slot on the V2 inverter and exposes the drive as a standard CiA402 slave on an EtherCAT network. Pair it with the 3G3MX2-A4007-V2 and an NJ501-1300 / NX102-9000 controller for a typical machine-control loop.
