Omron 3G3MX2-AB015-V2 — 1.5 kW Single-Phase Inverter

SKU: 3G3MX2-AB015-V2

USD 180.00

MX2 V2 inverter, 1.5 kW HD / 2.2 kW LD on single-phase 200-240 V input, three-phase 200-240 V output. EtherCAT option slot, STO Cat 3 PLd.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron 3G3MX2-AB015-V2 sits in the middle of the AB single-phase 200 V family. It takes single-phase 200-240 VAC from a domestic-style supply and puts out three-phase 200 to 240 VAC to drive a standard induction or PM motor up to 1.5 kW on heavy-duty (constant torque / CT) duty or 2.2 kW on light-duty (variable torque / VT) duty. The V2 in the part code adds the EtherCAT option slot on top of the standard Modbus RTU + USB on board.

Where it fits

Pick the AB015 when a 1.5 kW machine is fed from a single-phase 230 VAC cabinet supply (common in retrofit machinery, packaging cells, small pumps, and fans that were wired from a single-phase service line). Smaller AB002 / AB004 / AB007 models cover 0.1 to 0.75 kW. The AB022 covers 2.2 kW. For 400 V three-phase cabinets pick the A4 family instead -- 3G3MX2-A4015 for 1.5 kW three-phase 400 V. Single-phase AB drives stop at 2.2 kW.

Why the V2 suffix matters

The base 3G3MX2-AB015 (V1) carries Modbus RTU on the RJ-45 plus a USB CX-Drive port -- enough for any Modbus-driven machine but not for a Sysmac or PC-based high-speed network. The -V2 version adds a front card slot for EtherCAT / CompoNet / DeviceNet / MECHATROLINK-II / PROFINET, so the same inverter ships to a Modbus cabinet AND to an EtherCAT machine by adding one option card. The card installs on the front without opening the inverter, and CX-Drive configures it on the same CX-One / Sysmac Studio.

Before ordering

Confirm the supply is single-phase 200-240 VAC. Three-phase 200 V supply requires an A2 drive, not AB. Decide whether the load is constant-torque (1.5 kW, 150% overload 60 s) or variable-torque (2.2 kW, 120% overload 60 s); the CT/VT selector changes both the rating and the safe operating area. Add a brake resistor on the B1 / B2 terminals for any overhauling load (vertical axis, inertial fan, fast-stop duty).

Key Features

  • 3G3MX2 V2 compact multi-function inverter, V2 = EtherCAT option slot
  • Single-phase 200-240 VAC input at +/- 10%, 50/60 Hz (AB family)
  • Three-phase 200-240 VAC output to standard induction or PM motor
  • 1.5 kW HD (constant torque / CT) or 2.2 kW LD (variable torque / VT)
  • 8 A output current at HD rating
  • 0.1 to 580 Hz output frequency (V/f mode); 0.1 to 1000 Hz in high-frequency mode
  • Sensorless vector control with 200% starting torque at 0.5 Hz
  • Built-in RS-485 Modbus RTU + USB CX-Drive programming port
  • V2 option slot for EtherCAT / CompoNet / DeviceNet / MECHATROLINK-II / PROFINET cards
  • Safe Torque Off per ISO 13849-1 PLd / Cat 3, dual-channel + EDM feedback
  • Built-in brake transistor (brake resistor B1 / B2 connection)
  • IP20 open-type, self-cooling (no fan on this power level)
  • -10 to +50 deg C operating
  • Approximate 2.3 kg shipping weight per Omron box label
  • SKU: 3G3MX2-AB015-V2
  • Series: 3G3MX2-AB015-V2
  • Voltage: 200-240 VAC
  • I/O: 200 I/O

Best-Fit Applications

  • Single-phase 230 V retrofit machines driving a 1.5 kW conveyor / mixer / pump motor
  • Packaging and small bottling lines fed from a single-phase domestic-style service panel
  • OEM machines that need the same drive to ship as Modbus and as EtherCAT (V2 option slot)
  • Vertical or fast-stop loads with an external brake resistor on B1 / B2
  • Fan and blower control on variable-torque (VT) loads up to 2.2 kW

Buying Checklist

  • Pick 3G3MX2-AB015-V2 for 1.5 kW on single-phase 200-240 V with the EtherCAT option slot open.
  • Pick 3G3MX2-AB007-V2 for 0.75 kW on the same single-phase 200 V supply when 1.5 kW is more than the load needs.
  • Pick 3G3MX2-AB022-V2 when the load is up to 2.2 kW on the same single-phase supply.
  • Pick 3G3MX2-A4015-V2 when the cabinet is three-phase 400 V instead of single-phase 200 V.
  • Pick the 3G3MX2-AB015 (V1) when the cabinet only uses Modbus RTU and the EtherCAT slot is unnecessary.
  • Add the 3G3AX-MX2-ECT EtherCAT option card to the V2 slot to expose the drive as an ETG.102 slave.
  • Pair the inverter with a brake resistor (sold separately) for any overhauling load.

Technical Specifications

Power Class 1.5 kW HD (CT) / 2.2 kW LD (VT)
Input Voltage Single-phase 200-240 VAC, +/- 10%, 50/60 Hz
Output Voltage Three-phase 200-240 VAC (matched to input)
Output Current 8 A at HD rating
Output Frequency 0.1 to 580 Hz (V/f); 0.1 to 1000 Hz high-frequency mode
Control Method Sensorless vector (default) / V/f / PM motor control
Starting Torque 200% at 0.5 Hz
Communication Built-in RS-485 Modbus RTU + USB CX-Drive port
Option Cards EtherCAT / CompoNet / DeviceNet / MECHATROLINK-II / PROFINET (V2 slot)
Safety Safe Torque Off per ISO 13849-1 PLd / Cat 3 (dual-channel + EDM)
Brake Circuit Built-in brake transistor (resistor sold separately)
Operating Temperature -10 to +50 deg C

FAQ for 3G3MX2-AB015-V2

Can the 3G3MX2-AB015-V2 run on three-phase 200 V?
No. The AB family is single-phase 200-240 VAC input only. Three-phase 200 V is the A2 family (3G3MX2-A2015, A2022, etc.). When the cabinet is three-phase, pick the A2 or A4 model -- wiring an AB drive to three-phase input will damage the rectifier.
What does the V2 in 3G3MX2-AB015-V2 add over the V1?
The V2 adds a front option-card slot for EtherCAT, CompoNet, DeviceNet, MECHATROLINK-II, or PROFINET communication cards. The base Modbus RTU + USB CX-Drive port are present on both V1 and V2. Pick V2 when the drive needs to live on a high-speed fieldbus (an EtherCAT NJ machine, a CompoNet cable, a DeviceNet panel) and add the matching 3G3AX-MX2 option card at order or in the field.
How much starting torque does the AB015 deliver?
200% of rated torque at 0.5 Hz in sensorless vector mode. That covers most conveyor / mixer / fan starting under load without needing an encoder on the motor. For closed-loop torque or position control with an encoder, step up to the Accurax G5 servo (R88D-KN / R88M-K) instead -- the MX2 is an inverter, not a servo.
Does the inverter include a brake resistor?
No. The AB015 includes the brake transistor on B1 / B2 inside the inverter; the resistor itself is sold separately (Omron's 3G3AX-RBC series). Without the resistor the drive still runs, but it cannot decelerate an overhauling load -- a vertical axis or a fast-stop duty must have the resistor fitted to B1 / B2 and to P/+.
