Omron 3G3MX2-AB004-V2 — 0.4kW MX2 Inverter, 230V
SKU: 3G3MX2-AB004-V2USD 155.00
Omron 3G3MX2-AB004-V2 MX2 inverter drives 0.4kW (0.5HP) motors from single-phase 230V supply — ideal for small conveyors, fans, and pumps in OEM skids and light-commercial retrofits.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The 3G3MX2-AB004-V2 is the 0.4 kW step in the MX2 V2 single-phase 200V class — sitting between the 0.2 kW AB002 and the 0.75 kW AB007. The 'AB' suffix identifies single-phase 200V input; the 'A2' suffix is three-phase 200V, and the 'A4' suffix is three-phase 400V. Mixing these up is a common procurement error: the AB models can only accept single-phase input. The 0.4 kW / 0.5 HP rating covers a lot of OEM machinery: small conveyors, dosing pumps, peristaltic pumps, agitators, small fans, and metering skids. The single-phase 200-240V input is the practical sweet spot for light-commercial and small industrial environments in the EU, UK, Australia, and most of Asia — anywhere you only have 230V single-phase available, not three-phase. On the input side, the drive accepts 1-phase 200-240V at 50/60 Hz. It then rectifies to DC internally and synthesises a 3-phase output to drive a standard 3-phase induction motor. This is the standard 'single-phase to 3-phase VFD' topology. The drive can NOT power a single-phase motor — only 3-phase induction motors work with VFDs in this configuration. Sensorless vector control gives the same benefits as on larger MX2 models: better low-speed torque, more stable speed under load changes. The V2 firmware adds improved auto-tune that handles most small motors without manual parameter entry. Common use: OEM packaging machine retrofit where the line was originally fixed-speed and the customer wants speed control. The AB004 replaces a contactor + thermal overload setup and gives the operator a 0-60Hz potentiometer knob on the front of the cabinet, with no need to pull in a three-phase supply.
Key Features
- 0.4kW inverter class for compact motor control applications
- 230V input class for common single-machine integrations
- Supports variable speed operation for process optimization
- Suitable for conveyors, pumps, and auxiliary drive tasks
- Improves energy efficiency and motor control flexibility
- Practical MX2 family platform for OEM standardization
- SKU: 3G3MX2-AB004-V2
- Series: 3G3MX2 (MX2)
- Voltage: 200-240VAC
- I/O: 0 I/O
Best-Fit Applications
- Variable-speed control of small conveyors in pharmaceutical blister packaging lines
- Speed control of peristaltic dosing pumps in laboratory water treatment skids
- Driving 0.4kW small industrial fans in commercial kitchen ventilation
- Retrofit of fixed-speed packaging line with operator-adjustable speed via front panel potentiometer
Buying Checklist
- 0.4kW continuous / 0.55kW light-duty dual rating covers most small OEM machine motors
- Single-phase 200-240V input is the most common supply available in light industrial settings
- Standard 3-phase motor output means no special motor needed — reuse existing 3-phase induction motors
- V2 firmware auto-tunes most motors in under a minute without external equipment
- IP20 panel-mount with the same hole pattern as the AB002, AB007 for easy upgrades
Technical Specifications
| Model | 3G3MX2-AB004-V2 |
|---|---|
| Series | 3G3MX2 (MX2) |
| Rated Output | 0.4kW (0.5 HP) |
| Input Voltage | Single/Three-phase 200-240VAC |
| Output Current | 2.5A (ND), 2A (HD) |
| Control Method | V/f, Sensorless Vector |
| Built-in EMC Filter | Yes |
| Communication | Modbus RTU |
| Operating Temperature | -10 to +50°C |
| Mounting | DIN rail or panel |
Resources & Downloads
FAQ for 3G3MX2-AB004-V2
Can I run a 3-phase motor from single-phase 230V with the AB004-V2?
Yes — that's the AB004-V2's main job. It takes single-phase 200-240V in and synthesises 3-phase output to drive a standard 3-phase induction motor. The motor must be 3-phase; you cannot run a single-phase motor from a VFD.
What's the difference between AB004-V2 and AB004 (non-V2)?
V2 is the 2024 firmware revision. Improvements include faster auto-tune, better low-speed torque stability, and updated Modbus register mapping. The hardware is mechanically identical. New installations should use V2; if you have a non-V2 in the field, you can usually replace it with V2 and reuse the parameter file.
Do I need a braking resistor with the AB004-V2?
For most 0.4kW loads, no — the inertia is low and the built-in brake transistor handles typical decel rates. For high-inertia loads or fast-stop applications, add an external 3G3AX-RB1500 or equivalent resistor (the same one used on the A4110-V2).
What size motor can the AB004-V2 drive?
0.4kW (0.5HP) in normal duty, 0.55kW in light duty. The drive can supply a 0.5HP motor at constant torque or a 0.75HP motor at variable torque (centrifugal pump or fan). Don't run a 1HP motor on this drive — the current limit will trip the drive within seconds.
