Omron AIG02GQ02D — Panasonic AIG02GQ02D — GT02 3.8-inch
SKU: AIG02GQ02DUSD 86.00
Panasonic AIG02GQ02D GT02-series 3.8-inch monochrome HMI, 240 x 96 LCD, RS-232C, 24 VDC, IP67 front face. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron AIG02GQ02D is the Panasonic AIG02GQ02D is a 3.8-inch monochrome touch HMI from the GT02-series, manufactured by Panasonic Industry (formerly Sunx). It is manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the NB-Designer project file on a USB drive included.
Note: this SKU is a Panasonic product, not Omron. The display is a 3.8-inch STN monochrome LCD (changed to TFT from February 2017 production) at 240 x 96 dots with a 3-colour green/orange/red LED backlight.
Pair it with a small Omron CP-series PLC such as the CP1L-EM30DT-D over RS-232C for a compact cell that needs a 3.8-inch screen. Key specs: Display 3.8-inch STN monochrome LCD (240 x 96), 3-colour LED backlight; Touch Resistive analogue touch, free layout (8 dot minimum); Supply Voltage 24 VDC; Power Consumption 1.9 W max; Serial Port RS-232C (8-pin connector terminal base); Programming Port USB mini-B (USB 1.1); Memory 2 MB F-ROM plus SD/SDHC card slot up to 32 GB; Protection / Temperature Front face IP67; 0 to +50 degC operating.
Key Features
- Panasonic GT02-series 3.8-inch monochrome HMI with resistive touch
- 240 x 96 STN LCD (TFT from Feb 2017 production), 3-colour LED backlight
- 24 VDC supply, 1.9 W max, RS-232C port, USB mini-B programming, SD card slot
- Front face IP67 when panel-mounted, 112 x 74 x 27 mm, around 250 screens
- SKU: AIG02GQ02D
- Series: Panasonic GT02-series compact monochrome HMI
- Voltage: 24 VDC
Best-Fit Applications
- Compact machine where a 3.8-inch monochrome screen is enough to show run state and a few setpoints next to a CP1L-EM30DT-D
- Spare HMI drop-in for a small packaging line where the previous AIG02GQ02D failed and the field PLC is an FP-series or CP1-series
- OEM panel builder standardising on the Panasonic GTWIN software tool who needs a low-cost 24 VDC HMI with SD card recipe backup
Buying Checklist
- Pick the AIG02GQ02D for a 3.8-inch monochrome HMI with RS-232C and a low panel cutout.
- Pick the NB3Q-TW00B instead when the cabinet needs an Omron NB-series 3.5-inch TFT HMI with Ethernet.
- Pick the NS5-SQ10B-V2 instead when a larger 5.7-inch QVGA screen with dual serial is required.
Technical Specifications
| Manufacturer | Panasonic Industry Co., Ltd. (formerly Sunx) |
|---|---|
| Series | Panasonic GT02-series compact monochrome HMI |
| Model / SKU | AIG02GQ02D |
| Display | 3.8-inch STN monochrome LCD (240 x 96), 3-colour LED backlight |
| Touch | Resistive analogue touch, free layout (8 dot minimum) |
| Supply Voltage | 24 VDC |
| Power Consumption | 1.9 W max |
| Serial Port | RS-232C (8-pin connector terminal base) |
| Programming Port | USB mini-B (USB 1.1) |
| Memory | 2 MB F-ROM plus SD/SDHC card slot up to 32 GB |
| Protection / Temperature | Front face IP67; 0 to +50 degC operating |
| Dimensions / Weight | 112 (W) x 74 (H) x 27 (D) mm; approx. 170 g |
FAQ for AIG02GQ02D
Is the AIG02GQ02D an Omron product?
No. The AIG02GQ02D is a Panasonic GT02-series HMI. It is sold by Hengyixin because customers ask for it alongside Omron PLCs. For Omron-branded HMIs in the same size class, look at the NB3Q-TW00B (3.5-inch).
Which software programs the AIG02GQ02D?
Panasonic GTWIN, running on Windows 2000, XP, Vista or 7. The project transfers via the USB mini-B port on the rear of the HMI. The programming cable is the USB2.0-AMB10 or a standard USB-A to USB mini-B lead.
Does the AIG02GQ02D have Ethernet?
No. The G suffix on the GT02 family means RS-232C only. For Ethernet on the GT02, pick the GT02F variants (F suffix). For a Panasonic HMI with Ethernet in this size class, move up to the GT12 or GT32 series.
