Omron NB3Q-TW00B — 3.5" TFT HMI, Serial Only
SKU: NB3Q-TW00BUSD 138.00
3.5-inch TFT color HMI with serial (RS-232C / RS-422 / RS-485) connectivity. For compact panels without Ethernet.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The NB3Q-TW00B is Omron's smallest NB-series HMI — a 3.5-inch TFT color touchscreen (320 x 240 pixels, 65,536 colors) that talks to a PLC over RS-232C or RS-422/485 serial only. It fits where panel space is tight and Ethernet isn't required: small packaging machines, lab / test stands, conveyor controllers, or any CJ1M / CJ2M / CP1L system where the only network is serial Host Link or Modbus RTU. Programming is done with NB-Designer (free Windows software).
When to pick this vs the other NB-series 3.5-inch and 5.7-inch HMIs
Pick NB3Q-TW00B (this SKU) when the panel cutout is small and you only need serial — the value-tier pick. Pick NB3Q-TW01B (already done) when you also need Ethernet (for NJ / NX controllers) or a USB Host port (for USB memory stick recipe transfer). Pick NB5Q-TW00B-V1 for a 5.7-inch screen on serial, or NB5Q-TW01B-V1 for 5.7-inch with Ethernet. Pick NB7W-TW01B-V1 for a 7-inch screen with Ethernet and USB Host.
Before ordering
The single COM port supports RS-232C, RS-422A, and RS-485 — selected by a DIP switch on the rear of the unit. Only one protocol is active at a time, so the HMI talks to one serial network (typically a single PLC). Project transfer from PC to HMI is via USB mini-B cable. Confirm your PLC protocol (Host Link for CP / CJ, FINS serial for CJ2, Modbus RTU for non-Omron PLCs) and set the COM port accordingly before commissioning.
Key Features
- 3.5-inch TFT color LCD, 320 x 240 pixels (QVGA), 65,536 colors
- Analog resistive touch panel
- RS-232C + RS-422A/485 on one COM port (DIP-switch selected)
- USB mini-B for project transfer
- No Ethernet, no USB Host (this SKU)
- IP65 front face (when properly mounted)
- 24 VDC powered, approx 5 W
- NB-Designer software (free, Windows)
- Up to 16 languages per project
- SKU: NB3Q-TW00B
- Series: NB3Q-TW00B
- Voltage: 24 VDC
Best-Fit Applications
- Small packaging machine or assembly cell with serial Host Link to a CJ2M-CPU11 / CPU12
- Test stand or laboratory measurement system with serial Modbus RTU
- Compact conveyor or batching controller with serial link to a CP1L PLC
- Replacement for legacy NT-series HMIs on existing CJ systems
- Building-automation sub-panel with serial link to a CJ1W-SCU21 SCU card
Buying Checklist
- Pick NB3Q-TW00B (this SKU) for 3.5" serial-only HMI
- Pick NB3Q-TW01B (already done) for 3.5" with Ethernet + USB Host
- Pick NB5Q-TW00B-V1 for 5.7" serial-only (more screen space)
- Pick NB5Q-TW01B-V1 (already done) for 5.7" with Ethernet
- Pick NB7W-TW01B-V1 for 7" with Ethernet and USB Host
- Pick NB10W-TW01B-V1 for 10.1" widescreen Ethernet HMI
Technical Specifications
| Model | NB3Q-TW00B |
|---|---|
| Display | 3.5" TFT, 320 x 240 (QVGA), 65,536 colors |
| Touch Panel | Analog resistive |
| Communication | 1 x COM1 (RS-232C / RS-422A / RS-485 via DIP switch) |
| USB | 1 x USB mini-B (programming) |
| Ethernet / USB Host | No |
| Supported Protocols | Omron Host Link, FINS, Modbus RTU, Mitsubishi MC, Siemens S7 MPI |
| Internal Memory | 128 MB flash |
| Power Supply | 24 VDC, approx 5 W |
| Front Face | IP65 (with gasket) |
| Operating Temperature | 0 to 50 °C |
| Dimensions | 128.8 x 102.0 x 52.8 mm; cutout 119.0 x 92.5 mm |
Resources & Downloads
FAQ for NB3Q-TW00B
What's the difference between NB3Q-TW00B and NB3Q-TW01B?
Same 3.5" screen and same NB-Designer software. TW00B (this SKU) is serial-only (RS-232C / RS-422 / RS-485 on one COM port) with USB mini-B for programming. TW01B (already done) adds an Ethernet port (for FINS / Host Link with NJ / NX controllers) and a USB Host port (for USB memory stick recipe transfer).
How do I connect the NB3Q-TW00B to a CJ2M-CPU11 or CJ2M-CPU12?
Connect the NB3Q's COM1 (DB9 female) to the CJ2M's built-in RS-232C port (DB9 female) using a DB9 cross-over / null-modem cable — Omron's XW2Z-200K (2 m) or XW2Z-500K (5 m) are pre-wired for this. Set the NB3Q's rear DIP switch to RS-232C, select Host Link in NB-Designer, and match the PLC unit number (default 0) and baud rate (default 9600).
Can the NB3Q-TW00B communicate with NJ-series controllers?
Only over serial — this SKU has no Ethernet port. To talk to NJ / NX controllers over Ethernet (FINS / EtherNet/IP), use the NB3Q-TW01B (already done) or any larger NB HMI with Ethernet. The NB3Q-TW00B still works with CJ-series CPUs (CJ1M, CJ2M, CJ2H) over serial Host Link, plus Modbus RTU and other serial protocols for non-Omron PLCs.
How do I transfer a project from NB-Designer to the HMI?
Connect a USB mini-B cable (standard USB-A to mini-B, like a digital camera) between your PC and the NB3Q's rear USB port. Build the project in NB-Designer, then use Transfer > Download to HMI. The NB3Q appears as a USB mass-storage device. For Ethernet-enabled HMIs, projects can also transfer over Ethernet.
Is the NB3Q-TW00B discontinued?
No — it's in active production as of 2024 and supported through at least 2030. The NB3Q-TW00B-V1 (V1 hardware revision) is the current variant with identical functionality. For new installations, plan to migrate to the V1 version or to NB3Q-TW01B-V1 if Ethernet is required.
