Omron C200HW-PA209R — 45 W PLC Power Supply, RUN
SKU: C200HW-PA209RUSD 205.00
45 W backplane supply for C200H and CS1 CPU racks. 100-120 / 200-240 VAC, 5 VDC at 9 A and 26 VDC at 1.3 A, RUN output.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron C200HW-PA209R is a high-capacity AC power supply module for C200H and CS1-series PLC CPU racks. It provides 5 VDC at 9 A and 26 VDC at 1.3 A from a single-phase 100-120 or 200-240 VAC feed, for a combined 45 W output. The supply sits in the dedicated power-supply slot of a C200H CPU or expansion backplane and feeds every I/O and communication module on the rack through the backplane bus. It also includes a SPST-NO RUN output contact that closes while the CPU is in RUN mode, useful for a remote run light, interlock, or higher-level PLC input.
When the extra capacity is worth it
Use this model when a C200HW-PA204 or PA204S has run out of headroom for a growing rack. The 9 A main output leaves room for larger I/O counts, several special-function units, or a communication card that the smaller 4.6 A supply cannot feed. If the project uses any 24 VDC input modules, the PA204S-style auxiliary 24 V output is not part of the PA209R, so plan to add a separate 24 VDC supply for those.
Watch the backplane and input voltage
C200HW-PA209R requires a -V1 or newer CPU backplane. Older C200HW-BCxx1 backplanes cannot be used with the high-power supply. The supply accepts either 100-120 or 200-240 VAC, but the choice is fixed at installation; there is no internal voltage selector. Match the wiring, breaker, and upstream protection to the chosen input range.
Before ordering
Confirm that the planned 5 VDC load, including the CPU and every planned module, fits within 9 A. The 1.3 A 26 VDC output is intended for the backplane; it is not a general-purpose 24 VDC service supply. Leave at least 80 mm of clearance above and below the supply and use the M4 self-raising terminals with the recommended wire size. Plan for the 30 A inrush at 100 VAC (40 A at 200 VAC) when sizing the branch breaker.
Key Features
- 45 W output for C200H and CS1 CPU racks
- 5 VDC at 9 A main output
- 26 VDC at 1.3 A backplane output
- 100-120 or 200-240 VAC input
- SPST-NO RUN output contact
- Backplane mounting with screw terminals
- Compatible with -V1 and later CPU backplanes
- SKU: C200HW-PA209R
- Series: C200HW / CS1
- Voltage: 200-240 VAC
- I/O: 100 I/O
Best-Fit Applications
- Main supply for C200H or CS1 CPU racks with many I/O and special-function modules
- Replacement for C200HW-PA204 when 5 VDC load exceeds 4.6 A
- Higher-power spare for C200H-series process and machine-control panels
- Retrofit work for C200HX/HG/HE CPU racks using a -V1 backplane
- Service stock for legacy C200H lines still in production
Buying Checklist
- Confirm the rack backplane is a -V1 or later before ordering this high-power supply.
- Check the planned 5 VDC load against the 9 A limit; include all special I/O and communication modules.
- Choose the input voltage range (100-120 or 200-240 VAC) before wiring; the supply is fixed-range.
- Confirm the 26 VDC output is for the backplane only; add a separate supply for 24 VDC input modules.
- Allow for 80 mm of clearance above and below the supply for airflow.
- Check the 30-40 A inrush current when sizing the branch breaker.
Technical Specifications
| Series | C200HW / CS1 |
|---|---|
| Mounting | C200H / CS1 CPU or expansion backplane |
| Input Voltage | 100-120 / 200-240 VAC, 50/60 Hz |
| Power Consumption | 180 VA max. |
| Inrush Current | 30 A at 100 VAC; 40 A at 200 VAC |
| Output (Main) | 5 VDC, 9 A |
| Output (Auxiliary) | 26 VDC, 1.3 A |
| Total Output Power | 45 W |
| RUN Output | SPST-NO relay, 250 VAC 2 A resistive / 24 VDC 2 A resistive |
| Compatible Backplane | C200HW-BCxx1-V1 or later CPU / expansion backplane |
| Operating Temperature | 0 to 55 °C |
Resources & Downloads
FAQ for C200HW-PA209R
What is the difference between C200HW-PA209R and C200HW-PA204S?
The PA204S gives 5 VDC at 4.6 A plus a 24 VDC service output at 0.8 A for 30 W total. The PA209R raises the 5 VDC output to 9 A, drops the auxiliary to 26 VDC at 1.3 A, and adds a RUN relay. Use the PA209R when the rack needs more 5 V current; the PA204S fits 24 VDC input modules better.
Does the C200HW-PA209R include a 24 VDC service output?
No. The auxiliary output is 26 VDC at 1.3 A and feeds the backplane. It is not rated for general 24 VDC loads. Add a separate DIN-rail power supply if 24 VDC input modules are present on the rack.
Can a C200HW-PA209R be used as a direct replacement for a C200HW-PA204?
Yes, when the backplane is a -V1 or later version. Older C200HW-BCxx1 backplanes cannot host the high-power supply. Check the backplane suffix, confirm the planned 5 VDC load fits the 9 A rating, and run a short commissioning test before placing the rack in service.
