Part of the Omron CJ-Series PLCs series — see the full model table, lifecycle status and replacement parts.

Omron CJ2H-CPU64 — front view of the CJ2H CPU unit showing the Omron model label, the RS-232C DB9 port, the USB Type-B programming port, the CJ1W-BAT01 battery holder, the seven RUN / PWR / ERR / BKUP / COMM LED indicators and the top-mounted terminal block cover

Omron CJ2H-CPU64 — CJ2H CPU, 50K Steps, RS-232C+USB

SKU: CJ2H-CPU64

USD 570.00

Omron CJ2H-CPU64 CJ2H CPU, 50K steps, 160K words data, RS-232C + USB. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CJ2H-CPU64 is the base CJ2H-series CPU unit from the SYSMAC CJ platform, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The unit holds 50K steps of program memory and 160K words of data memory (32K DM plus 32K words across 4 EM banks). Logic execution is 0.016 microseconds per LD instruction. The CPU supports 2560 local I/O points and up to 40 expansion units across 3 expansion racks.

Built-in ports are RS-232C and USB. Supply is 5 V at 0.42 A from a CJ1W-PA202 or CJ1W-PD022 power supply on the same rack. The CPU is 48.8 x 90 x 74.5 mm (W x H x D), 190 g, DIN-rail mounted. For built-in EtherNet/IP, move up to the CJ2H-CPU64-EIP. For 100K steps and 160K words DM, pick the CJ2H-CPU66-EIP.

Key Features

  • CJ2H flagship CPU with 50K steps program memory and 160K words data
  • 32K words DM plus 32K words across 4 EM banks, 2560 local I/O points
  • LD execution 0.016 us, up to 40 expansion units across 3 expansion racks
  • Built-in RS-232C + USB, 5 V 0.42 A from a CJ1W-PA202 or CJ1W-PD022 PSU
  • SKU: CJ2H-CPU64
  • Series: Omron CJ2H-series SYSMAC CJ CPU unit
  • I/O: 2560 I/O

Best-Fit Applications

  • Mid-size packaging line where 2560 I/O covers a 3-rack build and the 50K-step program fits the recipe logic
  • Existing CJ2H cell spare CPU drop-in where the previous CJ2H-CPU64 failed and the ladder project is already in CX-Programmer
  • Migration from a CJ1M-CPU21 cell where the extra memory and the 3 expansion racks give room for the next retrofit

Buying Checklist

  • Pick the CJ2H-CPU64 for a 50K-step CJ2H CPU with RS-232C + USB and no built-in EtherNet/IP.
  • Pick the CJ2H-CPU64-EIP instead when the cabinet needs built-in EtherNet/IP on the same 50K steps.
  • Pick the CJ2H-CPU66-EIP instead when the program needs 100K steps and the cabinet needs built-in EtherNet/IP.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CJ2H-series SYSMAC CJ CPU unit
Model / SKU CJ2H-CPU64
Program Capacity 50K steps
Data Memory 160K words (32K DM + 32K words x 4 banks EM)
LD Execution Time 0.016 us per basic instruction
I/O Capacity 2560 local points; 40 units across 3 expansion racks
Built-in Ports RS-232C (DB9); USB 2.0 programming
Current Consumption 5 VDC 0.42 A (from rack PSU)
Weight 190 g
Dimensions 48.8 (W) x 90 (H) x 74.5 (D) mm; panel-mount
Compatible PSU CJ1W-PA202 (AC) or CJ1W-PD022 (DC)

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for CJ2H-CPU64

Does the CJ2H-CPU64 have built-in EtherNet/IP?
No. The CJ2H-CPU64 base model has RS-232C and USB only. For built-in EtherNet/IP on the same 50K steps, pick the CJ2H-CPU64-EIP. Production of the -EIP variant is planned to end on 2027-03-31.
How much expansion can the CJ2H-CPU64 host?
Up to 40 units across 3 expansion racks for a maximum of 2560 local I/O points. Use the CJ1W-IC101 I/O control unit on the CPU rack and CJ1W-II101 I/O interface units on each expansion rack with CS1W-CN223 or CS1W-CN713 connecting cables.
What power supply does the CJ2H-CPU64 need?
A CJ1W-PA202 (100-240 VAC, 14 W) for an AC cabinet, or a CJ1W-PD022 (24 VDC, 19.6 W) for a DC cabinet. The CPU draws 5 V at 0.42 A from the rack.
Can the CJ2H-CPU64 replace a CJ1M-CPU21?
Yes. The CJ2H-CPU64 accepts CJ1M I/O and Special I/O units on the same rack with a CJ1W-IC101 adapter, and existing CX-Programmer projects convert with no code changes. The CJ2H adds faster LD execution and a much larger program and data memory.
