Omron CJ2M-CPU11 — 5K Steps CPU, RS-232C, No EtherNet/IP
SKU: CJ2M-CPU11USD 112.00
CJ2M-series 5K-step CPU Unit with built-in RS-232C and USB programming port. 64K words data memory, 2,560 I/O max, 3 expansion racks, option-board slot, supports up to 2 CJ2M-MD211/MD212 Pulse I/O Modules. The no-EtherNet/IP sibling of CJ2M-CPU33.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The CJ2M-CPU11 is Omron's entry-level CJ2M CPU Unit — 5K steps of program memory, 64K words of data memory, and built-in RS-232C + USB programming ports — designed for compact machines where EtherNet/IP is not required. It is the smallest of the ten CJ2M CPU variants and the value-tier pick when the engineer is building a CJ-series rack with CJ1W expansion I/O (CJ1W-ID211, CJ1W-OD212, CJ1W-MAD42, CJ1W-NC233) and only needs serial Host Link for programming and HMI/SCADA networking. The CPU1x variant (no EtherNet/IP) saves roughly $300-500 over the equivalent CPU3x (with EtherNet/IP) — for applications where the network is Modbus RTU, Host Link, or a CJ1W-ETN21 Ethernet unit, the CPU11 is the right pick.
Decoding CJ2M-CPU11 within the CJ2M-CPU1@ / CPU3@ family
The CJ2M-CPU@@ model code has two positional digits that encode both program capacity and EtherNet/IP presence. The second digit (1, 2, 3, 4, 5) maps to program capacity (5K, 10K, 20K, 30K, 60K steps respectively, identical for both CPU1x and CPU3x). The first digit (1 vs 3) encodes EtherNet/IP: 1 = no EtherNet/IP, 3 = built-in EtherNet/IP with 2-port switch. The CJ2M-CPU11 codepoint thus decodes as 5K steps, no EtherNet/IP.
Built-in communications: RS-232C, USB, and the option-board slot
The CJ2M-CPU11 has three built-in communication interfaces: (a) RS-232C serial port (D-Sub 9-pin female connector, included) — supports Host Link (command-based serial from SCADA/HMI), 1:N NT Link (to Omron NS/NB HMIs), No-protocol mode (free-form ASCII to a barcode reader or scale), Serial PLC Link (CJ2M-to-CJ2M peer-to-peer without a master), Serial Gateway (CompoWay/F master converting Host Link to CompoWay/F), and Tool Bus (CX-Programmer connection). (b) USB 2.0 mini-B programming port — for CX-Programmer (CX-One or Sysmac Studio) connection at 12 Mbps full-speed, hot-pluggable.
Pulse I/O Module support — adding 4-axis positioning without an NC unit
The CJ2M-CPU11 supports up to two CJ2M-MD211 (NPN open-collector) or CJ2M-MD212 (PNP) Pulse I/O Modules mounted on the left side of the CPU. Each module adds: 4 high-speed counter inputs (100 kHz line-driver / 50 kHz open-collector), 4 interrupt inputs, 4 pulse outputs (100 kHz pulse train + PWM), and 20-input / 12-output I/O area allocated at CIO 2960-2963. With two modules, the CPU11 can do 4-axis positioning at 100 kHz without buying a separate CJ1W-NC233 (2-axis position control) or CJ1W-NC413 (4-axis open-collector). The Pulse I/O Module is the right pick for stepper-driven indexing tables, encoder-based cut-to-length, or registration-mark tracking on packaging lines.
Key Features
- CJ2M series CPU Unit without built-in EtherNet/IP
- 5K steps of program memory
- 64K words of data memory
- LD instruction execution time 0.04 us
- Floating point trigonometric operations under 1 us
- 2,560 I/O bits max via CJ-series expansion racks
- 40 CJ1W units max per CPU across 3 expansion racks
- Built-in RS-232C serial port
- SKU: CJ2M-CPU11
- Series: CJ2M CPU Units (CJ-series modular PLC platform)
- I/O: 2 I/O
Best-Fit Applications
- Small packaging machine - CPU11 with CJ1W-ID211 + CJ1W-OD212 + CJ1W-OC211 + CJ1W-MAD42 for valve control, sensor aggregation, and analog.
- Conveyor controller with multiple zones - CPU11 + 4 x CJ1W-ID211 for photocell and proximity-sensor aggregation; CJ1W-OD212 for VFD enable.
- Small assembly cell - CPU11 + CJ2M-MD211 Pulse I/O Module for 4-axis stepper control of pick-and-place gantry + CJ1W-ID211/OD212 for.
- Batching system controller - CPU11 + CJ1W-MAD42 for flow-meter inputs and control-valve outputs; RS-232C to a weigh-scale indicator
Buying Checklist
- Pick CJ2M-CPU11 for 5K-step CJ2M CPU without EtherNet/IP - smallest CPU11 entry point
- Pick CJ2M-CPU12 for 10K-step no-EIP - slightly larger programs
- Pick CJ2M-CPU13 for 20K-step no-EIP - medium programs without EtherNet/IP
- Pick CJ2M-CPU14 for 30K-step no-EIP - larger programs
- Pick CJ2M-CPU15 for 60K-step no-EIP - largest no-EIP program capacity
- Pick CJ2M-CPU31 for 5K-step w/ EtherNet/IP - same memory but with built-in Ethernet
Technical Specifications
| Model | CJ2M-CPU11 |
|---|---|
| Series | CJ2M CPU Units (CJ-series modular PLC platform) |
| Type | 5K-step CPU Unit without built-in EtherNet/IP |
| Program Capacity | 5K steps (5,120 steps) |
| Data Memory Capacity | 64K words (DM: 32K words, EM: 32K words x 1 bank) |
| LD Instruction Execution Time | 0.04 us (40 ns) |
| I/O Bits | 2,560 bits max |
| Mountable Units | 40 CJ1W units max per CPU (CPU rack + 3 expansion racks) |
| Built-in Communication Ports | RS-232C (D-Sub 9-pin female) + USB 2.0 mini-B (programming) |
| Pulse Output (via Pulse I/O Module) | 4 outputs at 100 kHz pulse train + PWM (per module) |
| Interrupt Inputs (via Pulse I/O Module) | 4 inputs (per module) |
| Current Consumption (5 VDC) | 0.5 A from CJ bus (CPU1x) |
| Current Consumption (24 VDC) | 0 A (no external 24 V required) |
| Communication Protocols (RS-232C) | Host Link, 1:N NT Link, No-protocol, Serial PLC Link Slave/Master, Serial Gateway (CompoWay/F), Tool Bus |
| Dimensions (W x H x D) | 60 x 90 x 65 mm (CPU unit only) |
Resources & Downloads
FAQ for CJ2M-CPU11
What's the difference between CJ2M-CPU11 and CJ2M-CPU31?
Both are CJ2M CPUs with the same 5K-step program capacity, same 64K-word data memory, same LD execution time (0.04 us), and same RS-232C + USB + option board + Pulse I/O Module support. The only difference is the built-in EtherNet/IP port: CJ2M-CPU31 (this SKU's EIP sibling) has a 2-port EtherNet/IP switch on the front face supporting tag-data-link communication to NJ-series controllers, EtherNet/IP scanners, and remote I/O; CJ2M-CPU11 (this SKU) has no built-in EtherNet/IP.
Can the CJ2M-CPU11 communicate with NJ-series controllers over EtherNet/IP?
The CJ2M-CPU11 cannot be an EtherNet/IP scanner or adapter directly - it has no built-in EtherNet/IP port and the CP1W-ME05M option board only supports FINS/Host Link communication over Ethernet (not EtherNet/IP CIP routing). For EtherNet/IP communication with NJ-series controllers, use a CJ2M-CPU3@ (CPU31, CPU32, CPU33, CPU34, CPU35) which has the built-in EtherNet/IP port and supports tag-data-link (cyclic) communication plus explicit (message) communication.
Can I add a Pulse I/O Module to the CJ2M-CPU11 for positioning?
Yes - the CJ2M-CPU11 supports up to 2 CJ2M-MD211 (NPN open-collector) or CJ2M-MD212 (PNP) Pulse I/O Modules mounted on the left side of the CPU. Each module provides 4 high-speed counter inputs (100 kHz line-driver or 50 kHz open-collector), 4 interrupt inputs, and 4 pulse outputs (100 kHz pulse train + PWM). With 2 modules, the CPU11 can do 4-axis positioning at 100 kHz for stepper-driven indexing tables, encoder-based cut-to-length, or registration-mark tracking.
What option board fits in the CJ2M-CPU11 option slot?
The CJ2M-CPU11 option slot accepts 4 types of CP1W option boards: (a) CP1W-CIF01 RS-232C Option Board - adds a second RS-232C port with the same D-Sub 9-pin connector as the built-in port (15 m max cable). Adds 5 mA at 5 V. (b) CP1W-CIF11 RS-422A/485 Option Board (non-isolated) - adds an RS-422A or RS-485 port on a 5-terminal screw block (50 m max cable). Adds 30 mA at 5 V.
