Omron CJ2M-CPU13 — front view of the CJ2M CPU showing the Omron model label, the green PWR LED, the green RUN LED, the red ERR LED, the USB mini-B programming port and the RS-232C DB9 serial port

Omron CJ2M-CPU13 — CJ2M PLC CPU, 20K Steps, USB

SKU: CJ2M-CPU13

USD 150.00

Omron CJ2M-CPU13 CJ2M CPU, 20K steps program, USB + RS-232C, no Ethernet. 2560 I/O max. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CJ2M-CPU13 is a CJ2M-series PLC CPU, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The CPU runs a 20K-step program and 64K words of data memory (32K words DM plus 32K words EM in one bank). LD instruction execution is 0.04 microseconds. Built-in ports are USB 2.0 for programming and an RS-232C serial port. The CPU does not have an EtherNet/IP port -- for Ethernet on a CJ2M use the CJ2M-CPU3x or CJ2M-CPU1x with the CJ1W-ETN21 module.

Up to 40 I/O units across 3 expansion racks give 2,560 local I/O points. Battery backup uses the CJ1W-BAT01. The pulse I/O add-on module is the CJ2M-MD211, and the three expansion racks link via the CJ1W-IC101 plus CJ1W-II101 cable chain to a CJ1W backplane. Programming runs in CX-Programmer on the CX-One suite on a Windows laptop over the front USB port.

Key Features

  • CJ2M-series CPU, 20K steps program, 64K words data memory, 0.04 us LD execution
  • Built-in USB 2.0 programming port plus RS-232C serial, no EtherNet/IP
  • Up to 2,560 I/O points across 40 units on 3 expansion racks
  • Battery backup with CJ1W-BAT01, pairs with CJ2M-MD211 pulse I/O module
  • SKU: CJ2M-CPU13
  • Series: Omron CJ2M-series PLC CPU (CJ2M-CPU1x)
  • I/O: 2 I/O

Best-Fit Applications

  • Mid-size packaging machine where 20K steps covers the recipe logic and the USB port lets a tech program without the CX-One serial cable
  • Spare replacement on a CJ2M-CPU11 retrofitted cabinet where the original 5K-step program keeps running and the 20K headroom adds a new HMI screen
  • Standalone filling line controlled by a CJ2M-CPU13 with a CJ1W-IC101 expansion interface driving three CJ1W-ID211 input cards and one CJ1W-OD212 output card

Buying Checklist

  • Pick the CJ2M-CPU13 for a CJ2M CPU with 20K steps, USB programming, and no Ethernet on the body.
  • Pick the CJ2M-CPU35 instead when the program needs 60K steps and the line runs through an EtherNet/IP scanner.
  • Pick the CJ1W-CPU42 instead when the cabinet already runs an older CJ1M and the migration budget does not cover a CJ2M swap.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CJ2M-series PLC CPU (CJ2M-CPU1x)
Model / SKU CJ2M-CPU13
Program Capacity 20K steps
Data Memory 64K words (DM 32K + EM 32K x 1 bank)
LD Execution Time 0.04 microseconds
Built-in Ports USB 2.0 programming + RS-232C serial
EtherNet/IP Not built-in (use CJ1W-ETN21 module)
Max I/O Points 2,560 local, 40 units, 3 expansion racks
Current Consumption 5 VDC 0.5 A (without option board)
Dimensions 90 (H) x 31 (W) x 75 (D) mm, 130 g
Operating Temperature 0 to 55 degC, DIN rail mount

FAQ for CJ2M-CPU13

Does the CJ2M-CPU13 have EtherNet/IP?
No. The CJ2M-CPU1x line only has USB and RS-232C on the body. Add EtherNet/IP through the CJ1W-ETN21 module on the CPU rack, or switch to a CJ2M-CPU3x for built-in Ethernet.
How much program memory does the CJ2M-CPU13 have?
20K steps of program and 64K words of data (32K words DM plus 32K words EM in one bank). For 30K steps pick the CJ2M-CPU14, for 60K steps pick the CJ2M-CPU15.
Can the CJ2M-CPU13 use a CJ1W expansion rack?
Yes -- up to 3 expansion racks via CJ1W-IC101 on the right of the CPU and CJ1W-II101 on the left end of each rack. Standard CJ1W I/O and special I/O units drop in unchanged.
What software programs the CJ2M-CPU13?
CX-Programmer from the CX-One suite. Connect over the front USB port for online edit and download, or over RS-232C for legacy serial cables.
