Part of the Omron CJ-Series PLCs series — see the full model table, lifecycle status and replacement parts.

Omron CJ2M-CPU32 — front view of the CJ2M CPU3x showing the Omron model label, the RUN / ERROR / INH LED indicators, the seven-segment display, the USB Type-B programming port and the EtherNet/IP RJ45 port along the lower face

Omron CJ2M-CPU32 — CJ2M CPU, 10K Steps, EtherNet/IP

SKU: CJ2M-CPU32

USD 320.00

Omron CJ2M-CPU32 CJ2M CPU with built-in EtherNet/IP, 10K-step program, 64K data memory, option board slot. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CJ2M-CPU32 is the second step in the CJ2M CPU3x lineup, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

Program capacity is 10K steps plus 20K steps of function-block memory. Data memory is 64K words, split as 32K words DM plus 32K words EM in one bank. The CPU addresses up to 2560 local I/O across 40 mountable units and three expansion racks. Basic LD instruction execution is 0.04 microseconds. Built-in ports are EtherNet/IP and USB, plus an option board slot for CP1W-CIF01 (RS-232C) or CP1W-CIF11 / CP1W-CIF12-V1 (RS-422A/485).

Current draw is 5 V at 0.7 A. The unit is 90 x 62 x 84.5 mm and weighs 190 g. Programming runs in CX-Programmer. For the same 10K steps without EtherNet/IP, pick the CJ2M-CPU12. For more program, pick the CJ2M-CPU33 (20K steps) or CJ2M-CPU34 (30K steps). Add a CJ2M-MD211 for high-speed counter and pulse outputs.

Key Features

  • CJ2M CPU3x with 10K-step program plus 20K-step function-block memory
  • 64K-word data memory (DM 32K + EM 32K x 1 bank), 0.04 us LD instruction execution
  • Built-in EtherNet/IP and USB ports; option board slot for CP1W-CIF01 / CIF11 / CIF12-V1
  • 2560 I/O points across 40 units and 3 expansion racks, 5 V 0.7 A, 90 x 62 x 84.5 mm, 190 g
  • SKU: CJ2M-CPU32
  • Series: Omron CJ2M-series CPU Unit (CPU3x line, built-in EtherNet/IP)
  • I/O: 2560 points

Best-Fit Applications

  • Mid-size packaging line where the program grew past 5K and the cabinet needs EtherNet/IP for the new HMI
  • Spare CPU drop-in for a CJ2M-CPU31 cell where the original 5K program has filled and the slot is open for a CP1W-CIF11
  • Material handling cell with a CJ1W-PA202 power supply, several CJ1W-ID211 input units, and a CJ1W-OD212 output unit on the rack

Buying Checklist

  • Pick the CJ2M-CPU32 for the second step in the CJ2M CPU3x line with 10K steps of program and built-in EtherNet/IP.
  • Pick the CJ2M-CPU31 instead when 5K steps is enough and the rest of the spec is the same.
  • Pick the CJ2M-CPU34 instead when 30K steps of program is needed and the rest of the spec is the same.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CJ2M-series CPU Unit (CPU3x line, built-in EtherNet/IP)
Model / SKU CJ2M-CPU32
Program Capacity 10K steps + 20K steps function-block memory
Data Memory 64K words (DM 32K words + EM 32K words x 1 bank)
LD Execution Time 0.04 us (basic instruction)
Local I/O / Mountable Units 2560 points / 40 units / 3 expansion racks
Built-in Communication EtherNet/IP (RJ45) + USB; option board slot for CP1W-CIF01 / CIF11 / CIF12-V1
Current Consumption 5 VDC, 0.7 A
Compatible I/O Family CJ1W-series Basic I/O, Special I/O, and CPU Bus Units
Programming Software CX-Programmer (CX-One suite)
Dimensions / Weight 90 (H) x 62 (W) x 84.5 (D) mm; 190 g

FAQ for CJ2M-CPU32

What is the difference between CJ2M-CPU32 and CJ2M-CPU12?
Both have 10K steps of program. The CPU32 is on the CPU3x line with built-in EtherNet/IP and an option board slot. The CPU12 is on the CPU1x line with RS-232C + USB only and no option board slot.
How much program memory does the CJ2M-CPU32 have?
10K steps of program plus 20K steps of function-block memory for a total of 30K steps. The data memory side is 64K words.
Can the CJ2M-CPU32 replace a CJ1M CPU?
Yes. CX-Programmer imports the CJ1M project and the CJ2M CPU runs it with the same I/O addresses. I/O wiring does not need to change.
