Part of the Omron CP-Series Compact PLCs series — see the full model table, lifecycle status and replacement parts.

Omron CP1E-E20SDR-A — front view of the E-type CPU showing the Omron model label, the 12 input terminals on the left, the 8 relay output terminals on the right, the RUN / PWR / ERR LED indicators and the USB Type-B programming port on the lower face

Omron CP1E-E20SDR-A — CP1E CPU, 20 I/O, Relay, AC

SKU: CP1E-E20SDR-A

USD 69.90

Omron CP1E-E20SDR-A CP1E basic CPU, 12 in / 8 relay out, 100-240 VAC, 2K steps, USB only. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1E-E20SDR-A is an E-type basic CPU unit from the CP1E compact PLC family, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The unit ships with 12 digital inputs (24 VDC, PNP or NPN) and 8 relay outputs (2 A) on a 20-point terminal block. Program capacity is 2K steps and data memory is 2K words. Logic execution is 1.19 microseconds per LD instruction. The only built-in communication port is USB (B-type) for programming.

Supply is 100 to 240 VAC at 50/60 Hz. The CPU does not take option boards (CP1W-CIF01/11/12-V1/41 do not fit) and does not expand with CP1W expansion units; for expansion, move up to the CP1L-L line. The body is 86 x 90 x 79 mm, DIN-rail mounted, IP20. For 30K-step program and serial ports, pick the CP1L-EM30DT-D.

Key Features

  • CP1E E-type basic CPU with 12 digital inputs and 8 relay outputs (2 A)
  • 2K steps program memory, 2K words data memory, 1.19 us LD execution
  • Built-in USB port for programming; no option-board slot, no expansion
  • 100 to 240 VAC supply, 86 x 90 x 79 mm DIN-rail body, IP20
  • SKU: CP1E-E20SDR-A
  • Series: Omron CP1E-series E-type basic compact PLC
  • Voltage: 100 TO 240 VAC

Best-Fit Applications

  • Standalone conveyor starter panel where the 8 relay outputs drive small contactors and the 12 inputs land on E-stop and limit switches
  • Spare CPU drop-in for an existing E20 cell where the previous CP1E failed and the panel is wired for AC supply and relay outputs
  • Small packaging-machine retrofit where the program stays under 2K steps and USB programming from a laptop is enough

Buying Checklist

  • Pick the CP1E-E20SDR-A for a low-cost CP1E CPU with 20 I/O and built-in USB.
  • Pick the CP1L-L20DR-A instead when the program is closer to 5K steps and the cabinet needs an option-board slot for RS-232C or RS-485.
  • Pick the CP1E-N40DR-A instead when the panel needs 40 I/O on the same E-type platform.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP1E-series E-type basic compact PLC
Model / SKU CP1E-E20SDR-A
Supply Voltage 100 to 240 VAC, 50/60 Hz
Digital Inputs 12 x 24 VDC (PNP or NPN), shared common
Digital Outputs 8 x relay, 250 VAC 2 A resistive
Program Capacity 2K steps
Data Memory 2K words
LD Execution Time 1.19 us per basic instruction
Communication Port USB 2.0 B-type (programming only)
Expansion None (CP1W expansion units and option boards not supported)
Dimensions / Weight 86 (W) x 90 (H) x 79 (D) mm; approx. 370 g

FAQ for CP1E-E20SDR-A

Does the CP1E-E20SDR-A have RS-232C or RS-485?
No. The E-type CPU has USB only for programming. For RS-232C, RS-422A/485 or Ethernet, move up to the CP1L-L or CP1L-M line, which takes a CP1W-CIF01, CP1W-CIF11, CP1W-CIF12-V1 or CP1W-CIF41 option board in the option slot.
Can the CP1E-E20SDR-A expand with CP1W I/O units?
No. The E-type CP1E cannot take CP1W expansion units. The N-type and NA-type CPUs support up to three CP1W expansion units; the L-type CP1L supports one expansion unit up to 60 I/O total.
How is the CP1E-E20SDR-A programmed?
Through the built-in USB port using CX-Programmer from the CX-One suite. Connect a USB-A to USB-B cable from the PC to the CPU and CX-Programmer auto-detects the CPU on the CX-One USB driver.
What is the maximum program size?
2K steps of ladder logic and 2K words of data memory. For larger programs, the CP1E-N30/40/60 supports 8K steps, the CP1L-M supports 10K to 60K steps, and the CP2E supports 8K or 16K steps.
