Omron CP1L-M40DR-A — 40 I/O PLC, Relay Output, AC
SKU: CP1L-M40DR-AUSD 167.00
CP1L-M compact PLC with 40 I/O points (24 inputs, 16 relay outputs), 100-240 VAC power supply, USB programming port. 10K steps program / 32K words data memory. Legacy product discontinued 2027-06-30; replacement CP1L-EM40DR-D (DC power).
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The CP1L-M40DR-A is the 40-point variant of Omron's CP1L-M compact PLC family, with 24 × 24 VDC inputs, 16 × mechanical relay outputs rated 2 A / 250 VAC / 24 VDC per point, and 100-240 VAC power supply.
CP1L-M vs CP1L-L vs CP1L-J vs CP1L-EM family
The CP1L family has four sub-lines: CP1L-L (low-end, 5K steps, no HSC, no pulse output — limited I/O count of 14/20/30), CP1L-J (low-end equivalent, RS-232 instead of USB — discontinued), CP1L-M (medium, 10K steps, HSC up to 100 kHz on inputs, pulse-output up to 100 kHz on transistor models — discontinued 2027-06-30 — see replacement), and CP1L-EM (medium with EtherNet/IP, 10K steps, HSC, pulse output, built-in Ethernet — current production). The CP1L-M (this SKU) is the workhorse compact PLC for 2010-2025 machine designs that did not need Ethernet; CP1L-EM is the recommended replacement for new designs (since 2024).
CP1L-M40DR-A vs CP1L-M40DT1-D sibling (relay output vs transistor sinking output)
The CP1L-M40DR-A (this SKU) uses mechanical relay outputs rated 2 A per point, 250 VAC / 30 VDC max, with an expected mechanical life of 10 million operations and an electrical life of 100,000 operations at full rated load. The CP1L-M40DT1-D sibling uses 24 VDC transistor sinking (NPN) outputs rated 0.5 A per point, 24 VDC max, with no moving parts and a near-infinite electrical life.
USB port, programming, and CX-One / CX-Programmer
The CP1L-M (and CP1L-EM) ship with a USB 1.1 / 2.0 device port on the top of the CPU (Type-B mini-USB socket), capable of 12 Mbps programming and runtime upload/download via CX-Programmer 9.x and CX-One 4.x. The USB port presents as a standard serial port — no driver installation required on Windows 10 / 11 (Windows Update installs the CP1L USB driver automatically when the USB cable is plugged in). For 32-bit CX-Programmer v9.6x or v9.7x, the CP1L-M40DR-A appears in the device list under CP1L / CP1L-M / M40DR-A.
Key Features
- CP1L-M-series compact PLC with 40 I/O points
- 24 inputs: 24 VDC, PNP/NPN, 3 mA min ON / 1 mA max OFF
- 16 outputs: mechanical relay, 2 A per point, 250 VAC / 24 VDC switchable
- Power supply: 100-240 VAC
- 10K steps program capacity
- 32K words data memory
- Logic execution 0.55 µs per basic instruction
- USB 1.1 / 2.0 device port on top of CPU
- SKU: CP1L-M40DR-A
- Series: CP1L-M (medium-feature CP1L sub-line, discontinued 2027-06-30)
- Voltage: 100-240 VAC
- I/O: 24 I/O
Best-Fit Applications
- Stand-alone conveyor control in a small parts-washing station — 24 VDC sensor inputs on 0.00-0.07, 16 relay outputs driving motor.
- Air-handler unit controller on a building automation retrofit — 24 VDC inputs from thermostats, smoke detectors, duct-pressure switches; relay outputs.
- Smaller injection-molding machine controller — pressure-switch and limit-switch inputs on the 24 VDC side; relay outputs controlling mold-close / mold-open.
- Bag-filling machine controller in food packaging — relay outputs switching the bag-clamp solenoid valve, fill-spout, heat-seal bar, vacuum pump; 24.
Buying Checklist
- Pick CP1L-M40DR-A for a 40 I/O relay-output PLC on AC 100-240 VAC power — for spares replenishment of running systems
- Pick CP1L-EM40DR-D for new designs requiring 40 I/O + relay output — same form factor, same instruction set, DC 24 VDC power, built-in EtherNet/IP
- Pick CP1L-M40DT1-D for 40 I/O with transistor NPN sinking output — faster output switching for pulse-output applications up to 100 kHz
- Pick CP1L-EM40DT1-D for 40 I/O + transistor NPN output + built-in EtherNet/IP — recommended for new 2025+ designs with network connectivity
- Pick CP1L-L20DR-A for 20 I/O + relay output + AC power — compact low-end 14-input / 10-output PLC with 5K steps
- Pick CP1E-N60DT1-D for 60 I/O + transistor output + DC power — cheaper than CP1L-M for cost-sensitive applications
Technical Specifications
| Model | CP1L-M40DR-A |
|---|---|
| Series | CP1L-M (medium-feature CP1L sub-line, discontinued 2027-06-30) |
| Type | Compact PLC, 40 I/O points, relay output, AC power supply |
| Supply Voltage | 100-240 VAC (auto-ranging, 85-264 VAC operating range, 47-63 Hz) |
| Power Consumption | 60 VA max (at 100 VAC, with all outputs ON) |
| Number of Inputs | 24 inputs, 24 VDC |
| Input Voltage Range | 20.4 to 26.4 VDC |
| Input Current | 7 mA per point typical at 24 VDC |
| ON Voltage / Current | 14.4 VDC min / 3 mA min |
| OFF Voltage / Current | 5.0 VDC max / 1 mA max |
| Input Response Time | 8 ms max (configurable 0-32 ms in PLC Setup) |
| HSC Inputs | 4 high-speed counter inputs at 100 kHz single-phase / 50 kHz two-phase (input points 0.00-0.03) |
| Number of Outputs | 16 outputs, mechanical relay |
| Output Rating | 2 A per point at 250 VAC / 24 VDC, 5 A common, 8 A total |
| Output Life (Mechanical) | 10 million operations min |
Resources & Downloads
FAQ for CP1L-M40DR-A
When was the CP1L-M40DR-A discontinued?
The CP1L-M40DR-A (along with the entire CP1L-L, CP1L-J, CP1L-M, CP1E-10, and CP1E-NA sub-lines) was placed on Omron's Discontinuation Notice in 2023, with the last production date scheduled for 2027-06-30. For spare-parts replenishment of running CP1L-M systems beyond that date, Omron has spare stocks, but new CP1L-M production is not available after the discontinuation date. The recommended replacement is the CP1L-EM40DR-D — 40 I/O with 24 VDC power supply and built-in EtherNet/IP.
What's the difference between CP1L-M40DR-A (relay) and CP1L-M40DT1-D (transistor)?
The CP1L-M40DR-A (this SKU) uses mechanical relay outputs rated 2 A per point at 250 VAC / 24 VDC — capable of switching AC or DC loads, with galvanic isolation between the PLC and the load, with built-in RC snubbers on each output for inductive loads, but limited to about 1 kHz switching speed and 100,000-operation electrical life at rated load.
Can the CP1L-M40DR-A connect to a modern EtherNet/IP network?
No, the CP1L-M40DR-A does NOT have built-in EtherNet/IP — only the CP1L-EM sub-line has Ethernet. For EtherNet/IP connectivity on a CP1L-M, you must add an external Ethernet option unit (CJ1W-EIP21 / CS1W-EIP21 EtherNet/IP unit) mounted in a CJ-series expansion rack on the CP1L's peripheral port. This is technically possible but rare — when Ethernet was needed for CP1L projects, the typical upgrade was to swap the CP1L-M40DR-A for a CP1L-EM40DR-D.
Can I program the CP1L-M40DR-A with a USB cable?
Yes — the CP1L-M (and CP1L-EM) have a built-in USB 1.1 / 2.0 device port on the top of the CPU (Type-B mini-USB socket). The USB cable (standard USB-A to USB mini-B) connects directly to a PC with CX-Programmer 9.x installed. On Windows 10 / 11, the CP1L USB driver installs automatically via Windows Update when the cable is plugged in — no manual driver download is required.
