Omron CP1W-20EDT — front view of the 20-point expansion unit showing the screw terminal block, the 24 VDC power indicator, the Omron CP1W-Series model label, the 12 input channel LEDs and the 8 NPN output channel LEDs along the top edge

Omron CP1W-20EDT — CP1W I/O Expansion, 12-in / 8-out NPN

SKU: CP1W-20EDT

USD 53.00

CP1W 20-point I/O expansion, 12 DC inputs + 8 NPN transistor outputs, 0.3 A. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1W-20EDT is a 20-point I/O expansion unit for the CP1E, CP1L and CP1H PLC families It is manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's CP-series I/O Unit documentation.

The unit adds 12 24 VDC inputs and 8 NPN (sinking) transistor outputs to a CP1-series CPU. Inputs are 24 VDC with 5 mA typical current and 0 to 32 ms ON/OFF delay.

Up to three CP1W expansion units can sit on a CP1E N30 / N40 / N60 or NA20 CPU. Key specs: I/O Points 20 points total: 12 inputs + 8 outputs; Input Voltage / Current 24 VDC +10/-15%; 5 mA typical; Input ON / OFF Delay 0 to 32 ms (default 8 ms); Output Type NPN (sinking) transistor, 4.5-30 VDC; Output Rating 0.3 A per point, 0.9 A per common; Output ON / OFF Delay 0.1 ms max ON / 1 ms max OFF; Connector Screw terminal block (removable); Compatible CPUs CP1E N30/N40/N60/NA20, CP1L, CP1H, CP2E.

Key Features

  • CP1W 20-point I/O expansion: 12 24 VDC inputs + 8 NPN (sinking) transistor outputs
  • Outputs 4.5 to 30 VDC at 0.3 A per point, 0.9 A per common, 0.1 ms ON delay
  • Screw terminal block, 5 V supplied from the backplane bus, 86 x 90 x 50 mm, 300 g
  • Compatible with CP1E N30 / N40 / N60 / NA20, CP1L, CP1H and CP2E CPUs
  • SKU: CP1W-20EDT
  • Series: Omron CP1W-series Expansion I/O Unit
  • Voltage: 24 VDC
  • I/O: 20 points

Best-Fit Applications

  • Mid-size packaging line where the CP1L-M40DR-A needs more 24 VDC inputs and NPN outputs than the 40 built-in points
  • Spare I/O drop-in for a CP1W expansion rack where the previous unit failed and the wiring is NPN (sinking)
  • Conveyor control panel using a CP1W-20EDT plus a CP1W-8ER relay output unit for the diverter solenoids

Buying Checklist

  • Pick the CP1W-20EDT for a 20-point CP1W expansion with NPN (sinking) transistor outputs.
  • Pick the CP1W-20EDT1 instead when the cabinet calls for PNP (sourcing) outputs to match a PNP sensor field.
  • Pick the CP1W-20EDR1 instead when the load is a relay coil or a small solenoid and contact outputs are wanted.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP1W-series Expansion I/O Unit
Model / SKU CP1W-20EDT
I/O Points 20 points total: 12 inputs + 8 outputs
Input Voltage / Current 24 VDC +10/-15%; 5 mA typical
Input ON / OFF Delay 0.1 to 1 ms per the Omron product page; some CP1W literature quotes a 0-32 ms settable range with an 8 ms default, so confirm against the CP Series datasheet for your CPU configuration
Output Type NPN (sinking) transistor, 4.5-30 VDC
Output Rating 0.3 A per point, 0.9 A per common
Output ON / OFF Delay 0.1 ms max ON / 1 ms max OFF
Connector Fixed screw terminal block (not removable)
Compatible CPUs CP1E N30/N40/N60/NA20, CP1L, CP1H, CP2E
Dimensions (W x H x D) 86 × 90 × 50 mm; 300 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for CP1W-20EDT

What is the difference between CP1W-20EDT and CP1W-20EDT1?
The CP1W-20EDT has NPN (sinking) outputs and the CP1W-20EDT1 has PNP (sourcing) outputs. Both have 12 24 VDC inputs and 8 0.3 A outputs. Pick the output polarity that matches the field wiring.
How many CP1W-20EDT units can a CP1L CPU host?
Up to three CP1W expansion units in total on a CP1L CPU (mix of I/O, analog and temperature units). The CP1L CPU also allows one CJ-series Special I/O or CPU Bus Unit through the CP1W-EXT01 adapter.
Does the CP1W-20EDT need a separate 24 VDC supply?
Inputs are powered from the field 24 VDC; outputs are powered from the same field 24 VDC. The unit's 5 V logic comes from the CP1-series backplane.
What is the input filter on the CP1W-20EDT?
0 to 32 ms ON/OFF delay, default 8 ms. Adjust in the PLC Setup to 0, 0.5, 1, 2, 4, 8, 16 or 32 ms depending on the noise in the panel.
