Omron CP1W-20EDT1 — CP1W I/O Expansion, 12-in / 8-out PNP

SKU: CP1W-20EDT1

USD 53.00

CP1W 20-point I/O expansion, 12 DC inputs + 8 PNP transistor outputs, 0.3 A. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1W-20EDT1 is a 20-point I/O expansion unit for the CP1E, CP1L and CP1H PLC families It is manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's CP-series I/O Unit documentation.

The unit adds 12 24 VDC inputs and 8 PNP (sourcing) transistor outputs to a CP1-series CPU. Inputs are 24 VDC +10/-15 percent with 5 mA typical input current.

For a 20-point expansion with NPN (sinking) outputs instead, pick the CP1W-20EDT. Key specs: I/O Points 20 points total: 12 inputs + 8 outputs; Input Voltage / Current 24 VDC +10/-15%; 5 mA typical; Input ON / OFF Delay 0 to 32 ms (default 8 ms); Output Type PNP (sourcing) transistor, 4.5-30 VDC; Output Rating 0.3 A per point, 0.9 A per common; Output ON / OFF Delay 0.1 ms max ON / 1 ms max OFF; Connector Fixed screw terminal block (not removable), M3 screws - Omron's CP-series catalogue specifies a fixed block for this unit; Compatible CPUs CP1E N30/N40/N60/NA20, CP1L, CP1H, CP2E.

Key Features

  • CP1W 20-point I/O expansion: 12 24 VDC inputs + 8 PNP (sourcing) transistor outputs
  • Outputs 4.5 to 30 VDC at 0.3 A per point, 0.9 A per common, 0.1 ms ON delay
  • Screw terminal block, 5 V supplied from the backplane bus, 86 x 90 x 50 mm, 300 g
  • Compatible with CP1E N30 / N40 / N60 / NA20, CP1L, CP1H and CP2E CPUs
  • SKU: CP1W-20EDT1
  • Series: Omron CP1W-series Expansion I/O Unit
  • Voltage: 24 VDC
  • I/O: 20 points

Best-Fit Applications

  • Mid-size packaging line where the CP1L CPU is wired to PNP sensors and needs 12 inputs plus 8 sourcing outputs
  • European-style cabinet where the field wiring is PNP and the existing expansion is CP1W-20EDT, ready to swap to PNP
  • Conveyor control panel using a CP1W-20EDT1 plus a CP1W-8ET1 output unit for the diverter solenoids

Buying Checklist

  • Pick the CP1W-20EDT1 for a 20-point CP1W expansion with PNP (sourcing) transistor outputs.
  • Pick the CP1W-20EDT instead when the cabinet calls for NPN (sinking) outputs to match an NPN sensor field.
  • Pick the CP1W-20EDR1 instead when the load is a relay coil or a small solenoid and contact outputs are wanted.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP1W-series Expansion I/O Unit
Model / SKU CP1W-20EDT1
I/O Points 20 points total: 12 inputs + 8 outputs
Input Voltage / Current 24 VDC +10/-15%; 5 mA typical
Input ON / OFF Delay 0 to 32 ms (default 8 ms)
Output Type PNP (sourcing) transistor, 4.5-30 VDC
Output Rating 0.3 A per point, 0.9 A per common
Output ON / OFF Delay 0.1 ms max ON / 1 ms max OFF
Connector Fixed screw terminal block (not removable), M3 screws - Omron's CP-series catalogue specifies a fixed block for this unit
Compatible CPUs CP1E N30/N40/N60/NA20, CP1L, CP1H, CP2E
Dimensions (W x H x D) 86 × 90 × 50 mm; 300 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for CP1W-20EDT1

What is the difference between CP1W-20EDT1 and CP1W-20EDT?
The CP1W-20EDT1 has PNP (sourcing) outputs and the CP1W-20EDT has NPN (sinking) outputs. Both have 12 24 VDC inputs and 8 0.3 A outputs. Pick the output polarity that matches the field wiring.
How many CP1W-20EDT1 units can a CP1L CPU host?
Up to three CP1W expansion units in total on a CP1L CPU. The CP1L CPU also allows one CJ-series Special I/O or CPU Bus Unit through the CP1W-EXT01 adapter.
Does the CP1W-20EDT1 need a separate 24 VDC supply?
Inputs and outputs share the field 24 VDC. The unit's 5 V logic comes from the CP1-series backplane; the unit does not draw 24 V from the bus.
