Part of the Omron CP-Series Compact PLCs series — see the full model table, lifecycle status and replacement parts.

Omron CP1W-8ET1 — front view of the 8-point output expansion showing the Omron model label, the eight green output LEDs, the screw terminal block and the CP1W bus connector on the right

Omron CP1W-8ET1 — CP Output Expansion, 8 PNP, 0.3 A

SKU: CP1W-8ET1

USD 35.00

Omron CP1W-8ET1 8-point PNP sourcing transistor output expansion, 0.3 A per point, 4.5-30 VDC. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1W-8ET1 is an 8-point PNP (sourcing) transistor output expansion unit for CP-series PLCs, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

Each output handles 0.3 A across a 4.5 to 30 VDC permitted output voltage. OFF/ON delay is 0.1 to 1 ms. The unit pulls 0.075 A from the CP bus at 5 VDC and draws nothing from the 24 V side. There are no inputs on this body.

The 66 x 110 x 50 mm DIN-rail block weighs 250 g and uses screw terminals. It is compatible with any CP1E, CP1L, CP1H or CP2E CPU that accepts CP1W expansion I/O. The non-1 suffix (CP1W-8ET) is the NPN (sinking) sibling for panels wired with the opposite polarity. For a 16-output body on the same wiring scheme, use the CP1W-16ER relay-output unit.

Key Features

  • CP1W 8-point PNP sourcing transistor output expansion unit
  • 0.3 A per point, 4.5 to 30 VDC permitted output voltage
  • OFF/ON delay 0.1 to 1 ms, 0.075 A at 5 VDC, no 24 V consumption
  • 66 x 110 x 50 mm, 250 g, screw terminal, DIN-rail mount
  • SKU: CP1W-8ET1
  • Series: Omron CP1W-series I/O expansion unit
  • Voltage: 4.5 TO 30 VDC

Best-Fit Applications

  • PNP solenoid bank on a packaging line where the 8 sourcing outputs wire directly to 24 VDC valves without an interposing stage
  • Tower-light stack on a conveyor where the 8 PNP outputs drive red / amber / green / buzzer segments without extra relays
  • Spare drop-in for a CP1L rack that lost a PNP output block and the new CP1W-8ET1 fits the same bracket and wiring

Buying Checklist

  • Pick the CP1W-8ET1 for a CP1W 8-point PNP sourcing transistor output expansion unit on a CP-series PLC.
  • Pick the CP1W-8ET instead when the panel is wired for NPN (sinking) on the same CP1W body.
  • Pick the CP1W-16ER instead when 16 relay outputs cover the cabinet on the same CP1W bus.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP1W-series I/O expansion unit
Model / SKU CP1W-8ET1
Function Digital output expansion, 8-point PNP (sourcing) transistor
Output Voltage Range 4.5 to 30 VDC
Output Current 0.3 A per point
OFF/ON Delay 0.1 to 1 ms
Current Consumption 0.075 A at 5 VDC, 0 A at 24 V
Compatible CPUs CP1E, CP1L, CP1H, CP2E (CP1W expansion bus)
Connection Screw terminal block
Mounting DIN-rail, 35 mm track
Dimensions (W x H x D) 66 × 110 × 50 mm; 250 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for CP1W-8ET1

Does the CP1W-8ET1 have any inputs?
No. It is output-only. For 8 inputs on the same body, use the CP1W-8ER (relay) or CP1W-8ET (NPN output) plus a separate CP1W input expansion unit such as the CP1W-8ED or CP1W-16ED.
What CPUs accept the CP1W-8ET1?
Any CP1E, CP1L, CP1H or CP2E CPU that has the CP1W expansion port. CP1L-L10 / L14 / L20 do not accept expansion I/O. Up to three CP1W expansion units per CP1L-M / CP1L-EM rack.
Does the CP1W-8ET1 need a 24 V supply?
No. The unit pulls all its power from the 5 VDC CP bus. The 24 VDC load supply comes from the terminal screws on the front of the unit and is wired directly to the loads.
What is the difference between CP1W-8ET and CP1W-8ET1?
CP1W-8ET is the NPN (sinking) version. CP1W-8ET1 is the PNP (sourcing) version. The body, dimensions, current consumption and mounting are the same; only the output polarity differs.
