Omron CP1W-30ET1 — Expansion I/O, 30-pt, PNP Out

SKU: CP1W-30ET1

USD 98.00

Omron CP1W-30ET1 CP1W expansion I/O, 30 points, 18 DC in / 12 PNP sourcing out, 0.3 A. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1W-30ET1 is a 30-point expansion I/O unit for the CP1E and CP1L PLC families, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The unit adds 18 digital inputs (24 VDC) and 12 PNP sourcing transistor outputs (12-24 VDC, 0.3 A per point) on a removable terminal block. The ET1 suffix marks PNP sourcing (the ET suffix is NPN sinking). The module draws 5 V at 0.13 A from the CPU via the CP1W-CN811 I/O connecting cable.

Compatible CPUs are CP1E E30 / E40 / E60, N30 / N40 / N60 and NA20, plus all CP1L and CP1H. The body is 130 x 90 x 85 mm in a 30-point form factor. For a 20-point PNP I/O expansion, pick the CP1W-20EDT1. For a 40-point PNP I/O expansion, pick the CP1W-40EDT1. For 32 PNP-only outputs on the same width, pick the CP1W-32ET1.

Key Features

  • CP1W 30-point expansion I/O, 18 DC inputs + 12 PNP sourcing transistor outputs
  • PNP sourcing outputs at 12-24 VDC, 0.3 A per point, 0.5 ms ON delay
  • 5 V 0.13 A current consumption from the CPU via CP1W-CN811 cable
  • Compatible with CP1E E30/40/60 + N30/40/60 + NA20, CP1L and CP1H
  • SKU: CP1W-30ET1
  • Series: Omron CP1W-series expansion I/O unit
  • I/O: 30 I/O

Best-Fit Applications

  • Adding 30 PNP outputs to a CP1E-N30DR-A or CP1L-M30DR-A cell that has run out of CPU outputs for a new divert arm and stack light
  • Existing 30-point field replacement where the prior CP1W-30ET1 unit (PNP sourcing) has failed and the wiring colour code matches
  • Spare expansion module for a CP1H-X40DR-A cabinet where the new I/O needs to land on PNP sourcing outputs to drive 24 VDC indicator stacks

Buying Checklist

  • Pick the CP1W-30ET1 for a 30-point CP1W expansion I/O with 18 DC inputs and 12 PNP sourcing transistor outputs.
  • Pick the CP1W-20EDT1 instead when the cabinet only adds 20 points (12 in / 8 out) on the same PNP sourcing form factor.
  • Pick the CP1W-32ET1 instead when the cabinet needs 32 PNP sourcing outputs (no additional inputs).

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP1W-series expansion I/O unit
Model / SKU CP1W-30ET1
Total Points 30 (18 inputs + 12 outputs)
Digital Inputs 18 x 24 VDC, PNP or NPN, 5 mA typical
Digital Outputs 12 x PNP sourcing transistor (sourcing), 12-24 VDC, 0.3 A per point
Output Leakage Current 0.1 mA max
Output Response Time ON 0.5 ms max; OFF 1.5 ms max
Current Consumption 5 VDC 0.13 A from CPU bus
Compatible CPUs CP1E E30 / E40 / E60 / N30 / N40 / N60 / NA20; CP1L; CP1H
Connection CP1W-CN811 80 cm I/O cable (one cable per PLC)
Dimensions / Weight 130 (W) x 90 (H) x 50 (D) mm; approx. 200 g

FAQ for CP1W-30ET1

What is the difference between CP1W-30ET and CP1W-30ET1?
CP1W-30ET is NPN sinking (load on the high side). CP1W-30ET1 is PNP sourcing (load on the low side). The two are NOT interchangeable. Always match the output polarity to the field wiring; swapping ET for ET1 without rewiring will short 24 VDC to ground through the load.
Does the CP1W-30ET1 need a separate 24 VDC supply?
Yes. The transistor outputs need an external 24 VDC field power supply to drive the loads. The unit itself draws 5 V logic power from the CPU via the CP1W-CN811 I/O cable.
How many CP1W-30ET1 units can I add to one PLC?
Up to 3 CP1W expansion units total per CP1E N30 / N40 / N60 / NA20 or CP1L PLC. On the CP1H the limit is 7 CP1W expansion units (plus 2 CJ-series via the CP1W-EXT01 adapter). Mix and match 30ET1 with 20EDT1 and 40EDT1 in any combination.
