Part of the Omron CP-Series Compact PLCs series — see the full model table, lifecycle status and replacement parts.

Omron CP1W-32ET1 — front face of the 32-point PNP output expansion module showing the 18-point screw terminal block per group of 16 outputs and the 32 green status LEDs above each output

Omron CP1W-32ET1 — 32 PNP Output Expansion

SKU: CP1W-32ET1

USD 98.00

32-point PNP sourcing output expansion for CP1, 0.3 A, 4.5-30 VDC, screw terminals. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1W-32ET1 is a 32-point PNP sourcing transistor output expansion unit for the CP1E, CP1L and CP1H PLC families It is manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

Each of the 32 outputs switches 0.3 A at 4.5 to 30 VDC, with 0.9 A per common and 3.6 A per unit. Output ON response is 0.1 ms max and OFF response is 1 ms max.

The module mates with any CP1 CPU via the right-side CP1W-CN811 expansion cable. Key specs: Output Type 32 PNP sourcing transistor outputs (open collector); Output Current 0.3 A per point, 0.9 A per common, 3.6 A per unit; Permitted Voltage 4.5 to 30 VDC at output terminals; Output Response ON 0.1 ms max, OFF 1 ms max at 24 VDC +10% / -5%; Residual Voltage 1.5 V max; Leakage Current 0.1 mA max; Internal Consumption 113 mA at 5 VDC from CP1 I/O bus; Connection M3 screw terminals on output side.

Key Features

  • 32-point PNP sourcing transistor output expansion for CP1E, CP1L and CP1H CPUs
  • 0.3 A per output, 0.9 A per common, 3.6 A per unit, 4.5 to 30 VDC permitted
  • ON response 0.1 ms max, OFF response 1 ms max, 1.5 V residual, 0.1 mA leakage
  • 113 mA from 5 VDC CP1 bus - no external 24 V supply needed for the outputs
  • SKU: CP1W-32ET1
  • Series: CP1W expansion I/O (CP1E / CP1L / CP1H compatible)
  • Voltage: 4.5 TO 30 VDC

Best-Fit Applications

  • Driving a 32-station pneumatic solenoid manifold from a CP1L-M40DT-D without adding a second CP1L rack
  • Replacing a legacy C200H-OD212 group on a C200H-to-CP1E migration where the field wiring already expects sourcing outputs
  • Expanding a CP1L-M60DT-D when the 36 built-in outputs are full and the panel still has DIN-rail space

Buying Checklist

  • Choose the CP1W-32ET1 when the load is PNP-compatible and 32 sourcing 24 VDC pilot outputs are needed on one module.
  • Choose the CP1W-32ET instead when the load expects ground-side switching on a NPN sinking output.
  • Choose the CP1W-40EDT1 (24 in / 16 PNP out) when the same DIN slot also needs 24 DC inputs.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series CP1W expansion I/O (CP1E / CP1L / CP1H compatible)
Model / SKU CP1W-32ET1
Output Type 32 PNP sourcing transistor outputs (open collector)
Output Current 0.3 A per point, 0.9 A per common, 3.6 A per unit
Permitted Voltage 4.5 to 30 VDC at output terminals
Output Response ON 0.1 ms max, OFF 1 ms max at 24 VDC +10% / -5%
Residual Voltage 1.5 V max
Leakage Current 0.1 mA max
Internal Consumption 113 mA at 5 VDC from CP1 I/O bus
Connection M3 screw terminals on output side
Dimensions / Weight 150 x 90 x 50 mm, 325 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for CP1W-32ET1

What is the difference between CP1W-32ET and CP1W-32ET1?
Both are 32-point 0.3 A transistor output expansion modules for the CP1 family. The ET is NPN sinking - it switches the negative side to the load. The ET1 is PNP sourcing - it switches the positive side. Pick ET1 when the load expects a positive common; pick ET when the load expects a ground common. Form factor, current draw and response time are otherwise identical.
Does the CP1W-32ET1 need an external 24 VDC supply?
No - the module draws all its logic power from the 5 VDC CP1 I/O bus through the expansion connector. The 24 VDC switched at the outputs comes from the field wiring, not from an internal supply. One expansion cable to the CP1 CPU is all the wiring needed on the bus side.
Can the CP1W-32ET1 be used with a CP1E-N14 or CP1E-N20 CPU?
No - the CP1E N14 and N20 CPUs do not have an expansion connector on the right side, so no CP1W expansion can be attached. Use a CP1E N30 or larger, or a CP1L / CP1H CPU. The CP1E N30 / N40 / N60 and NA20 models all accept CP1W expansion units via the right-side connector.
How is the CP1W-32ET1 wired to the CP1 CPU?
Attach the module to the right side of the CPU using the built-in ribbon connector on the 32ET1 itself - no cable is needed for the first expansion unit. For subsequent units (up to seven total), use the CP1W-CN811 80 cm I/O expansion cable between units. The module mounts to DIN rail and clips into the adjacent module's connector.
