Omron CP1W-EXT01 — front view of the CJ Unit Adapter showing the Omron model label, the CP1W-Series mark, the CPU-side connector on the left and the CJ-side connector on the right

Omron CP1W-EXT01 — CP1W CJ Unit Adapter

SKU: CP1W-EXT01

USD 35.00

CJ Unit Adapter for CP1H / CP1L, lets the host talk to up to 2 CJ-series units. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1W-EXT01 is a CJ Unit Adapter that lets a CP1H or CP1L CPU host up to two CJ-series Special I/O or CPU Bus Units on the I/O bus It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. The adapter sits between the CP1H or CP1L CPU and the right-hand expansion chain. It carries a CJ-series end cover so the CJ unit chain clamps to the adapter with the same end-plate hardware. Use the CP1W-CN811 80 cm cable when the CJ chain needs to be physically offset from the CPU. Key specs: Function CJ Unit Adapter: lets a CP1H or CP1L CPU connect to CJ-series I/O bus units; Maximum CJ Units 2 CJ-series Special I/O or CPU Bus Units; Compatible CPUs CP1H, CP1L (not CP1E, not CJ1, not CJ2); I/O Connecting Cable CP1W-CN811 (80 cm) for offset mounting; End Cover CJ-series end cover included; Current Consumption Drawn from the CP1H / CP1L backplane; no separate supply; Mounting DIN rail (35 mm), right side of CPU; Documentation CP1H CPU Unit Operation Manual (W450).

Key Features

  • CJ Unit Adapter for CP1H and CP1L CPUs
  • Hosts up to 2 CJ-series Special I/O or CPU Bus Units on the I/O bus
  • Carries a CJ-series end cover so the CJ chain clamps on with the same end-plate hardware
  • Use a CP1W-CN811 80 cm I/O connecting cable when the CJ chain needs to be offset from the CPU
  • SKU: CP1W-EXT01
  • Series: Omron CP1W-series Expansion Accessory

Best-Fit Applications

  • Mid-size machine where a CP1L-M40DR-A needs a CJ1W-DA041 high-resolution analog output on the same I/O bus
  • Spare adapter drop-in for an existing CP1H cell where the previous EXT01 was lost and the CJ chain needs to be re-clipped
  • Retrofit panel where a CP1H replaces a CP1E and the existing CJ1W-CT021 high-speed counter needs to stay

Buying Checklist

  • Pick the CP1W-EXT01 for a CP1H or CP1L CPU that needs to host up to 2 CJ-series Special I/O or CPU Bus Units.
  • Pick a CJ1W-IC101 instead when the chain is CJ1 / CJ2 and the EXT01 is the wrong host adapter.
  • Pick a second CP1W-EXT01 plus a CP1W-CN811 when the CJ chain must sit offset from the CPU for panel layout.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP1W-series Expansion Accessory
Model / SKU CP1W-EXT01
Function CJ Unit Adapter: lets a CP1H or CP1L CPU connect to CJ-series I/O bus units
Maximum CJ Units 2 CJ-series Special I/O or CPU Bus Units
Compatible CPUs CP1H, CP1L (not CP1E, not CJ1, not CJ2)
I/O Connecting Cable CP1W-CN811 (80 cm) for offset mounting
End Cover CJ-series end cover included
Current Consumption Drawn from the CP1H / CP1L backplane; no separate supply
Mounting DIN rail (35 mm), right side of CPU
Documentation CP1H CPU Unit Operation Manual (W450) and CP1L Manual (W462)
Dimensions / Weight 90 (H) x 86 (W) x 50 (D) mm; 200 g

FAQ for CP1W-EXT01

Does the CP1W-EXT01 extend the I/O bus on a CP1E?
No. The CP1W-EXT01 is for the CP1H and CP1L CPU lines only. CP1E and CP2E CPUs do not support CJ-series I/O bus units.
How many CJ-series units can the CP1W-EXT01 host?
Up to 2 CJ-series Special I/O or CPU Bus Units. CP1H and CP1L are limited by the I/O bus cycle time and the current draw from the backplane, not by the adapter itself.
Do I need a CP1W-CN811 cable with the CP1W-EXT01?
Only when the CJ chain has to sit offset from the CPU. Direct-mount the CJ units against the adapter when the panel layout allows it.
Is the CP1W-EXT01 a CJ1W-IC101?
No. The CJ1W-IC101 is an I/O control unit on a CJ1 / CJ2 rack. The CP1W-EXT01 is a small adapter for a CP1H / CP1L host and does not have its own CPU-bus logic.
