Omron CP1W-MAD42 — 4-In / 2-Out Analog, 14-Bit
SKU: CP1W-MAD42USD 100.00
Omron CP1W-MAD42 mixed analog I/O expansion for CP1 PLCs, 4 inputs, 2 outputs, 14-bit, voltage and current ranges. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CP1W-MAD42 is a mixed analog I/O expansion unit for the CP1-series compact PLCs, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
It adds 4 analog inputs and 2 analog outputs to a CP1L, CP1H, CP1E N-series, or CP2E CPU via the CP1W expansion bus. Each channel supports -10 to 10 V, 0 to 10 V, 0 to 5 V, 1 to 5 V, 0 to 20 mA, and 4 to 20 mA ranges. Resolution is 1/12000 (full scale) on every input and output. Conversion takes 1 ms per point, or 6 ms for all six points.
Photocoupler isolation separates the analog terminals from the internal logic. For a matched 4-in / 4-out analog combo, pick the CP1W-MAD44. For analog input only, pick the CP1W-AD042. For analog output only, pick the CP1W-DA021. Configuration runs in CX-Programmer under the CX-One suite; no extra option board is needed.
Key Features
- 4 analog inputs and 2 analog outputs in one CP1W expansion module, voltage and current ranges per channel
- 14-bit resolution (1/12000 full scale), 1 ms per point conversion time, overall accuracy 0.3 percent at 25 C
- Photocoupler isolation between analog terminals and internal logic, 18-point detachable M3 screw terminal block
- Compatible with CP1L, CP1H, CP1E N-series, and CP2E N-series CPUs that accept CP1W expansion I/O
- SKU: CP1W-MAD42
- Series: CP1W-series analog I/O expansion units for the CP1 compact PLC family
Best-Fit Applications
- Temperature and pressure loop on a CP1L-EM30DT1-D driven by four Pt100-to-4-20 mA transmitters wired into the four CP1W-MAD42 inputs
- Speed reference on a packaging line where two CP1W-MAD42 outputs command variable-frequency drives with 4-20 mA setpoints updated every 100 ms
- Spare replacement on a water-treatment skid where the original CP1W-AD042 + CP1W-DA021 pair is replaced by one CP1W-MAD42 to save panel space
Buying Checklist
- Pick the CP1W-MAD42 for a 4-input / 2-output mixed analog I/O expansion on a CP1L, CP1H, CP1E N, or CP2E N CPU.
- Pick the CP1W-MAD44 instead when the cell needs 4 analog inputs and 4 analog outputs in one module on the same CP1W bus.
- Pick the CP1W-AD042 + CP1W-DA021 pair instead when the cabinet needs input-only and output-only modules in separate slots for serviceability.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | CP1W-series analog I/O expansion units for the CP1 compact PLC family |
| Model / SKU | CP1W-MAD42 |
| Analog Inputs | 4 single-ended, ranges -10 to 10 V, 0 to 10 V, 0 to 5 V, 1 to 5 V, 0 to 20 mA, 4 to 20 mA |
| Analog Outputs | 2 single-ended, ranges -10 to 10 V, 0 to 10 V, 1 to 5 V, 0 to 20 mA, 4 to 20 mA |
| Resolution | 14-bit (1/12000 full scale) on every input and output |
| Conversion Time | 1 ms per point (6 ms for all six points scanned in order) |
| Accuracy | 0.3 percent of full scale at 25 C ambient, 0.7 percent at 0 to 55 C ambient |
| Isolation | Photocoupler between analog I/O terminals and internal circuits; no isolation between analog I/O signals |
| Current Draw | 120 mA at 5 VDC, 120 mA at 24 VDC from the CP1W expansion bus |
| Dimensions (W x H x D) | 86 × 90 × 50 mm; approximately 260 g |
| Environment / Wiring | 0 to 55 C operating, -20 to 75 C storage, 10 to 90 percent humidity (no condensation); 18-point detachable terminal block with M3 screws |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for CP1W-MAD42
What is the Omron CP1W-MAD42 used for?
It is a mixed analog I/O expansion module for the CP1-series compact PLCs. It adds 4 analog inputs and 2 analog outputs to a CP1L, CP1H, CP1E N, or CP2E CPU via the CP1W expansion bus. Each channel accepts voltage or current signals at 14-bit resolution and updates in 1 ms per point. Typical uses are temperature and pressure loops, variable-frequency drive references, and load-cell weighing with a 4-20 mA transmitter.
CP1W-MAD42 vs CP1W-MAD44 - what is the difference?
Both are CP1W mixed analog I/O expansion modules with 14-bit resolution and the same voltage and current ranges. The -MAD42 has 4 inputs and 2 outputs; the -MAD44 has 4 inputs and 4 outputs. Pick the -42 when the cabinet only needs 2 outputs; pick the -44 when 4 outputs are required on the same CP1W bus.
Does the CP1W-MAD42 work with the CP1E E-series CPUs?
No. The CP1E E-series (economy) does not support CP1W expansion I/O. The CP1W-MAD42 works with the CP1E N-series (standard), the CP1L, the CP1H, and the CP2E N-series. Pick a CP1E-NA20DR-A CPU with a CP1W option board if analog I/O is needed on an E-series panel.
Does the CP1W-MAD42 need an external power supply?
No. The CP1W-MAD42 draws its 5 VDC and 24 VDC from the CP1W expansion bus on the CPU Rack. The 24 V analog loop power for 4-20 mA transmitters must come from an external 24 VDC supply. No separate power terminal is needed for the module itself.
