Omron CP1W-MAD44 — front view of the analog I/O expansion unit showing the screw terminal block, the 24 VDC power indicator, the Omron CP1W-Series model label and the 4 AI + 4 AO channel LEDs along the top edge

Omron CP1W-MAD44 — CP1W Analog I/O, 4-in / 4-out, 14-bit

SKU: CP1W-MAD44

USD 135.00

CP1W analog I/O expansion, 4 inputs + 4 outputs, 1/12000 (14-bit) resolution. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1W-MAD44 is a high-resolution analog I/O expansion unit for the CP1H and CP1L PLC families It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The unit adds 4 analog inputs and 4 analog outputs to the I/O bus. Each channel is software-configurable for voltage or current.

For a small option-board analog stage, pick the CP1W-MAB221. Key specs: Analog Inputs 4 inputs, voltage or current (software-configurable); Analog Outputs 4 outputs, voltage or current (software-configurable); Input Range -10 to 10 V, 0 to 10 V, 0 to 5 V, 1 to 5 V, 0 to 20 mA, 4 to 20 mA; Output Range -10 to 10 V, 0 to 10 V, 1 to 5 V, 0 to 20 mA, 4 to 20 mA; Resolution 1/12000 (14-bit) per channel; Conversion Time 1 ms per point; Power 5 V 90 mA from backplane + 24 VDC 200 mA external; Compatible CPUs CP1H, CP1L.

Key Features

  • CP1W analog I/O expansion: 4 inputs + 4 outputs, software-configurable voltage or current per channel
  • 1/12000 (14-bit) resolution on every channel, 1 ms per point conversion
  • Inputs and outputs cover -10 to 10 V, 0-10 V, 1-5 V, 0-20 mA, 4-20 mA
  • 5 V 90 mA from backplane + 24 VDC 200 mA external, 86 x 90 x 50 mm, 260 g, for CP1H / CP1L
  • SKU: CP1W-MAD44
  • Series: Omron CP1W-series Analog I/O Expansion Unit

Best-Fit Applications

  • Process cell where a CP1H-X40DR-A needs 4 load-cell inputs and 4 valve-positioning outputs at 14-bit resolution
  • Mid-size machine where a CP1L-M40DR-A reads 4 pressure transmitters and drives 4 proportional valves over the I/O bus
  • Spare drop-in for an existing CP1W analog chain where the previous CP1W-MAD42 needs to be replaced at higher resolution

Buying Checklist

  • Pick the CP1W-MAD44 for a 4-in / 4-out CP1W analog expansion at 14-bit resolution.
  • Pick the CP1W-MAD42 instead when 4 inputs + 2 outputs at 12-bit is enough and one slot can be saved.
  • Pick the CP1W-ADB21 and CP1W-DAB21V instead when the option is a small CP1L-EL / CP1L-EM option port, not the I/O bus.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP1W-series Analog I/O Expansion Unit
Model / SKU CP1W-MAD44
Analog Inputs 4 inputs, voltage or current (software-configurable)
Analog Outputs 4 outputs, voltage or current (software-configurable)
Input Range -10 to 10 V, 0 to 10 V, 0 to 5 V, 1 to 5 V, 0 to 20 mA, 4 to 20 mA
Output Range -10 to 10 V, 0 to 10 V, 1 to 5 V, 0 to 20 mA, 4 to 20 mA
Resolution 1/12000 (14-bit) per channel
Conversion Time 1 ms per point
Power 5 V 90 mA from backplane + 24 VDC 200 mA external
Compatible CPUs CP1H, CP1L
Dimensions (W x H x D) 86 × 90 × 50 mm; 260 g
