Omron CP2E-N30DT-D — front view of the CP2E-N CPU showing the Omron model label, the green PWR LED, the green RUN LED, the red ERR LED, the input-output LED row and the two Ethernet RJ45 ports

Omron CP2E-N30DT-D — CP2E Network PLC, 30 I/O, Ethernet

SKU: CP2E-N30DT-D

USD 118.00

Omron CP2E-N30DT-D CP2E-N network micro PLC, 30 I/O (18 in / 12 out), 2-port Ethernet switch, USB. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP2E-N30DT-D is the network model of the CP2E micro PLC, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's CP2E dimensional table and product page.

The CPU carries 18 DC inputs and 12 NPN (sinking) transistor outputs. Supply is 24 VDC, 20.4 to 26.4 V allowable, 20 W max. Memory is 10K steps program and 16K words data with battery-free backup. Up to three CP1W expansion I/O units can be added to the right of the CPU.

Communication is two built-in Ethernet ports (PORT1A / PORT1B) that act as an Ethernet switch for daisy-chain wiring, plus a USB programming port. Four-axis positioning with linear interpolation is built in. The body is 90 x 80 x 130 mm at 580 g and runs from -20 to +60 degC. Add a CP1W-CIF11 in the option slot for RS-485 Modbus-RTU when the panel talks to older inverters.

Key Features

  • CP2E-N network micro PLC, 18 DC inputs, 12 NPN transistor outputs
  • Two built-in Ethernet ports with switching function for daisy-chain wiring
  • USB programming port, RS-232C and RS-485 on option board
  • 4-axis positioning with linear interpolation, 10K steps program, -20 to +60 degC
  • SKU: CP2E-N30DT-D
  • Series: Omron CP2E-N network micro PLC
  • Voltage: 24 VDC
  • I/O: 18 I/O

Best-Fit Applications

  • Small packaging machine where the dual-port Ethernet switch daisy-chains the PLC into the line PLC without an external switch
  • Distributed I/O drop on a conveyor where the CP2E-N aggregates four inverters over EtherNet/IP and feeds them up to a CJ2H
  • Spare replacement on a CP2E-N panel where the original CPU failed and the new CP2E-N30DT-D takes the same wiring and program

Buying Checklist

  • Pick the CP2E-N30DT-D for a CP2E-N network micro PLC with 30 I/O, two Ethernet ports and 4-axis positioning on 24 VDC.
  • Pick the CP2E-S30DT-D instead when the panel does not need Ethernet and the standard model covers the cabinet.
  • Pick the CP2E-N60DT-D instead when the rack needs 60 I/O on the same network platform.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP2E-N network micro PLC
Model / SKU CP2E-N30DT-D
Built-in I/O 18 DC inputs, 12 NPN transistor outputs
Power Supply 24 VDC, 20.4 to 26.4 VDC allowable, 20 W max
Program Memory 10K steps
Data Memory 16K words
Communication Ports 2 x Ethernet (switch), USB, RS-232C, RS-485 (option)
Positioning 4 axes with linear interpolation
Expandability Up to 3 CP1W / CPM1A expansion units
Operating Temperature -20 to 60 degC, hazardous-location Class I Div 2
Dimensions / Weight 90 (H) x 80 (D) x 130 (W) mm - Omron's CP2E table lists 30 I/O as 90 x 80 x 130 mm; 580 g

FAQ for CP2E-N30DT-D

What does the N in CP2E-N30DT-D mean?
N is the network model with two built-in Ethernet ports. The S suffix is the standard model without Ethernet. The body, I/O count and program memory are otherwise the same between the two.
Can the two Ethernet ports be used as a switch?
Yes. PORT1A and PORT1B function as an Ethernet switch so the PLC can be daisy-chained into a line topology without an external switch. Both ports support EtherNet/IP, Modbus-TCP and FINS.
Does the CP2E-N30DT-D need a battery?
No, the unit is battery-free for normal operation. Fit an optional CP2W-BAT02 cell only when the real-time clock must hold across a power-down.
How many CP1W expansion units can I add?
Up to three CP1W or CPM1A expansion I/O units attached to the right side of the CPU, taking the rack to 180 I/O points total.
What software programs the CP2E-N30DT-D?
CX-Programmer under CX-One. Projects from a CP1E-N can be reused with no change on a CP2E-N of the same I/O count.
