Omron CP2E-N30DT1-D — Compact PLC, 30 I/O, Ethernet
SKU: CP2E-N30DT1-DUSD 128.00
Omron CP2E-N30DT1-D CP2E-N compact PLC, 30 I/O (18 in / 12 PNP out), 24 VDC, dual Ethernet, 10K steps. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CP2E-N30DT1-D is the CP2E Network-type compact PLC with 30 I/O points, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
It runs from 24 VDC and gives 18 DC inputs plus 12 sourcing PNP transistor outputs in a 130 x 90 x 80 mm body. Program capacity 10K steps; data memory 16K words; LD instruction 0.23 microseconds. Two built-in Ethernet ports form a switching hub, so you can daisy-chain the PLC to an NB-series HMI without an external switch. 4 PTP axes and 6 high-speed counter channels at 100 kHz.
No built-in USB or RS-232C on this -DT1 variant - serial ports come as CP1W option cards. For Modbus-RTU add a CP1W-CIF11. The -DT1 means PNP; -DT1 variant is NPN. For relay outputs on the same dual-Ethernet body choose the CP2E-N40DR-A.
Key Features
- CP2E Network-type compact PLC with 30 I/O points: 18 DC inputs plus 12 sourcing PNP transistor outputs in a 130 x 90 x 80 mm body
- 10K steps program capacity, 16K words data memory, 0.23 microsecond LD instruction, battery-free memory backup, real-time clock
- Dual built-in 100BASE-TX Ethernet ports with switching hub for daisy-chain to an NB HMI without an external switch
- 4-axis PTP positioning at 100 kHz, 6-channel high-speed counter at 100 kHz, -20 to 60 C operating temperature
- SKU: CP2E-N30DT1-D
- Series: CP2E-series compact PLC, Network type (CP2E-N)
- Voltage: 24 VDC
- I/O: 30 points
Best-Fit Applications
- Standalone packaging machine where the CP2E-N30DT1-D daisy-chains to an NB5Q-TW01B-V2 HMI over the built-in Ethernet switching hub
- Pump station that needs 4-axis PTP motion plus Modbus-TCP to a CP2E-N40DR-D master PLC, polled over the same dual Ethernet port
- Spare replacement on a small conveyor cell that drives two stepper indexers from the built-in 100 kHz pulse axes
Buying Checklist
- Pick the CP2E-N30DT1-D when the panel needs 30 I/O, PNP outputs, and dual Ethernet in a single 24 VDC compact PLC.
- Pick the CP2E-N30DT-D instead when the loads need sinking NPN outputs instead of sourcing PNP outputs.
- Pick the CP2E-N30DR-D instead when the outputs need 16 relay contacts rather than transistor outputs on the same dual-Ethernet body.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | CP2E-series compact PLC, Network type (CP2E-N) |
| Model / SKU | CP2E-N30DT1-D |
| Total I/O | 30 points; 18 DC inputs + 12 PNP (sourcing) transistor outputs |
| Power Supply | 24 VDC, operating range 20.4 to 26.4 VDC, 13 W max with full expansion |
| Program / Data Memory | 10K steps program; 16K words data; built-in flash backup; battery-free DM retention |
| Logic Execution | LD instruction 0.23 microseconds; basic instructions and special instructions in CX-Programmer |
| Built-in Ports | 2 Ethernet 100BASE-TX ports with switching hub; no built-in USB or RS-232C on the -DT1 variant |
| Motion / Counters | 4 PTP axes at 100 kHz max pulse output; 6 high-speed counter channels at 100 kHz max; linear interpolation |
| Expansion | Up to 3 CP1W expansion units; up to 150 local I/O; up to 32 analog I/O channels via option boards (CP1W-ADB21 / CP1W-DAB21V) |
| Environment | Operating -20 to 60 C; storage -20 to 75 C; humidity 10 to 90 percent non-condensing; CE, cULus, KC, Lloyd, RCM, UKCA |
| Dimensions / Weight | 130 (W) x 90 (H) x 80 (D) mm; 565 g |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for CP2E-N30DT1-D
What is the Omron CP2E-N30DT1-D used for?
It is the CP2E Network-type compact PLC with 30 I/O points (18 in, 12 out PNP) and a 24 VDC supply. Typical uses are standalone packaging machines, pump stations with Modbus-TCP back to a master PLC, and conveyor cells with 4 PTP axes and 6 high-speed counter channels.
CP2E-N30DT1-D vs CP2E-N30DT-D - what is the difference?
Both are CP2E-N 30-I/O network PLCs with the same dual Ethernet and the same 24 VDC supply. The DT1 has PNP (sourcing) outputs that switch the high side of a load to 0 V. The DT has NPN (sinking) outputs that switch the low side of a load to 0 V. Pick the DT1 for PNP-input field devices; pick the DT for NPN-input field devices.
Does the CP2E-N30DT1-D have built-in USB or RS-232C?
No. The -DT1 Network variant has two built-in Ethernet ports and no USB, no RS-232C, no RS-485. For serial communication add a CP1W option board: CP1W-CIF01 for RS-232C, CP1W-CIF11 for RS-422A/485, or CP1W-CIF12-V1 for isolated RS-485. Programming over USB still works through the CX-Programmer Ethernet connection.
What is the maximum I/O expansion on the CP2E-N30DT1-D?
Up to 3 CP1W expansion I/O units, up to 150 local I/O points, and up to 32 analog I/O channels through CP1W analog option boards (CP1W-ADB21 for 2-ch voltage or current in, CP1W-DAB21V for 2-ch voltage out, CP1W-MAD42 for 4 in / 2 out mixed). All expansion sits on the right-hand side of the CPU on the same DIN rail.
