Part of the Omron DRT2 Smart DeviceNet I/O Units series — see the full model table, lifecycle status and replacement parts.

Omron DRT2-DA02 — front face of the DRT2 analog output slave showing the two output screw terminals, the rotary node-address switch and the MS / NS LED status indicators

Omron DRT2-DA02 — DeviceNet 2-Ch Analog Output Slave

SKU: DRT2-DA02

USD 125.00

Smart DeviceNet analog output slave, 2 channels V/mA, 1/6000 FS. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron DRT2-DA02 is a DRT2-series DeviceNet smart slave with two analog outputs It is manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

Each output is independent and configurable for voltage (0-5 V, 1-5 V, 0-10 V or -10 to +10 V) or current (0-20 mA or 4-20 mA) via DIP switch or the Configurator tool. Resolution is 1/6000 full scale with +/-0.4 percent accuracy at 25 degC.

DIN-rail mount, 150 g, IP20, -10 to +55 degC. Key specs: Outputs 2 analog outputs, voltage or current, independently configurable; Voltage Ranges 0-5 V, 1-5 V, 0-10 V, -10 to +10 V; Current Ranges 0-20 mA, 4-20 mA; Resolution 1/6000 full scale; Accuracy +/-0.4 percent FS at 25 degC; +/-0.8 percent at 0-55 degC; Conversion Cycle 4 ms maximum for both outputs; Output Load Voltage mode >= 1 kOhm; current mode <= 600 Ohm; Isolation Photocoupler between outputs and DeviceNet bus.

Key Features

  • DRT2 Smart DeviceNet slave with 2 independent analog outputs
  • Voltage (0-5/1-5/0-10/+/-10 V) or current (0-20/4-20 mA) per channel
  • 1/6000 FS resolution, +/-0.4 percent accuracy at 25 degC, 4 ms cycle
  • 11 to 25 VDC DeviceNet power, photocoupler isolation, DIN rail
  • SKU: DRT2-DA02
  • Series: DRT2-series Smart DeviceNet slave
  • Voltage: 0-5 V

Best-Fit Applications

  • Driving an inverter speed reference and a control valve positioner on the same DeviceNet node.
  • Sending a 0-10 V setpoint to a temperature controller and a 4-20 mA reference to a pump drive from one slave.
  • Replacing a hardwired 4-20 mA signal panel on a process skid that already runs DeviceNet.

Buying Checklist

  • Choose the DRT2-AD04 instead when 4 analog inputs are needed instead of outputs.
  • Confirm DRT2-OD16 or CRT1-OD16 are added for 16 digital outputs on the same DeviceNet trunk.
  • Choose the DRT2-DA02 when the cabinet already runs DeviceNet and needs 2 analog outputs per node.

Technical Specifications

Series DRT2-series Smart DeviceNet slave
Outputs 2 analog outputs, voltage or current, independently configurable
Voltage Ranges 0-5 V, 1-5 V, 0-10 V, -10 to +10 V
Current Ranges 0-20 mA, 4-20 mA
Resolution 1/6000 full scale
Accuracy +/-0.4 percent FS at 25 degC; +/-0.8 percent at 0-55 degC
Conversion Cycle 4 ms maximum for both outputs
Output Load Voltage mode >= 1 kOhm; current mode <= 600 Ohm
Isolation Photocoupler between outputs and DeviceNet bus
Network Power 11 to 25 VDC, 120 mA at 24 VDC
Mounting DIN 35 mm rail, IP20, 150 g
Operating Temperature -10 to 55 degC (no corrosive gases)

FAQ for DRT2-DA02

Can the DRT2-DA02 mix voltage and current outputs on the same slave?
Yes - each output is set independently via DIP switch or the Configurator tool. Output 0 can be 4-20 mA while output 1 is 0-10 V, both active at the same time. The load limits differ per range (1 kOhm minimum for voltage, 600 Ohm maximum for current).
How accurate is the DRT2-DA02 at high temperatures?
At 25 degC the accuracy is +/-0.4 percent full scale. Across the operating range -10 to 55 degC the accuracy is +/-0.8 percent FS. For higher-switch levels over the full temperature range, mount the slave in a temperature-controlled panel or derate the design budget.
What master PLC works with the DRT2-DA02?
Any Omron PLC with a DeviceNet scanner: CJ1W-DRM21 on CJ1 / CJ2, CS1W-DRM21 on CS1, or a built-in DeviceNet port on the NJ501 / NX102 series. Configure with CX-Integrator over USB or Ethernet - the EDS file is on the Omron Europe support site.
Does the DRT2-DA02 need a separate power supply?
No - the slave takes 11 to 25 VDC straight from the DeviceNet cable and runs on that single supply. The DeviceNet scanner or a separate DeviceNet power supply feeds both the slave electronics and the analog output circuit. Total draw is 120 mA at 24 VDC.
