Omron NA5-15W101B-V1 — 15.4 inch HMI, 1280x800
SKU: NA5-15W101B-V1USD 2175.00
Omron NA5-15W101B-V1 NA5-V1 HMI, 15.4 inch widescreen TFT, 1280x800. 2 Ethernet, 3 USB. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NA5-15W101B-V1 is a 15.4 inch widescreen programmable terminal, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the Sysmac Studio or NB-Designer project file on a USB drive included.
The display is a 15.4 inch TFT LCD with 1280 x 800 resolution and 24-bit color (about 16.7 million colors). The frame is black. Two Ethernet ports, three USB ports, and one RS-232C port cover most modern cabinet wiring. A micro SD card slot takes project files and data logs.
Power supply is 24 VDC. Panel cutout is 391 x 267 mm and the front face is IP65 against water and dust. The unit weighs about 3.2 kg. Production end is planned for 2026-09-30 -- distributor stock is the right play today. For a 12.1 inch widescreen sibling on the same NA5 family, use the NA5-12W101B-V1. For a 9 inch widescreen, use the NA5-9W001B-V1.
Key Features
- NA5-V1 15.4 inch widescreen HMI, 1280 x 800 TFT, 24-bit color (16.7M colors)
- 2 Ethernet, 3 USB, 1 RS-232C, micro SD card slot for projects and logs
- Black frame, panel cutout 391 x 267 mm, IP65 front face, 24 VDC supply
- 3.2 kg, projects built in Sysmac Studio NA series configuration
- SKU: NA5-15W101B-V1
- Series: Omron NA5-V1 series programmable terminal
- Voltage: 24 VDC
Best-Fit Applications
- Line-overview screen on a bottling line where the 1280 x 800 panel shows live trend graphs from the line PLC
- Spare replacement for an NS15-TX01B-V2 on a retrofit where the cabinet has been re-cut to the NA5 cutout
- Building-management SCADA terminal where two Ethernet ports segregate the BMS LAN from the operator workstation
Buying Checklist
- Pick the NA5-15W101B-V1 for a 15.4 inch widescreen HMI on Sysmac Studio with two Ethernet ports and three USB ports.
- Pick the NA5-12W101B-V1 instead when a 12.1 inch panel fits the existing cabinet cutout.
- Pick the NS15-TX01B-V2 instead when the line still runs CX-Designer and the migration to Sysmac Studio has not been scheduled.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NA5-V1 series programmable terminal |
| Model / SKU | NA5-15W101B-V1 |
| Display | 15.4 inch TFT LCD, 1280 x 800, 16,777,216 colors |
| Touch Panel | Analog resistive |
| Frame Color | Black |
| Communication Ports | 2 Ethernet, 3 USB, 1 RS-232C |
| Memory Card | micro SD card slot |
| Supply Voltage | 24 VDC |
| Panel Cutout | 391 x 267 mm |
| Front Protection | IP65 against dust and water |
| Dimensions / Weight | 420 (W) x 291 (H) x 69 (D) mm, 3.2 kg |
FAQ for NA5-15W101B-V1
Is the NA5-15W101B-V1 still in production?
Production ended on 30 September 2026. Omron Europe and the UK site both record it as discontinued; the successor is the same model on the -V2 hardware revision. Spare stock at distributors is the right option today, or move to the NB7W-TW01B-V1 for new builds.
How is the NA5-15W101B-V1 programmed?
With Sysmac Studio and the NA-series screen editor. Projects can be loaded over USB, Ethernet, or a micro SD card.
Does the NA5-15W101B-V1 have Ethernet?
Yes -- two Ethernet ports. The two ports let you split plant and device networks without an extra router.
Does the NA5-15W101B-V1 replace the NS15-TX01B-V2?
Yes. The NA5-V1 series is the official NS replacement. The NS to NA Replacement Guide (PDF on industrial.omron.eu) lists CX-Designer project conversion steps.
