Omron NA5-9W001B-V1 — 9" Sysmac HMI, 24 bit
SKU: NA5-9W001B-V1USD 1245.00
NA5-V1 9-inch widescreen TFT HMI, 800 x 480, 16.77M colors, dual Ethernet + 3 USB + RS-232 + SD. 24 VDC, IP65. Sysmac Studio.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NA5-9W001B-V1 is a 9-inch widescreen TFT color touchscreen in the NA5-V1 Sysmac HMI series. It is manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the NB-Designer project file on a USB drive included.
NA5-V1-series 9.0-inch widescreen Sysmac HMI panel 24 VDC supply, panel-mounting on 260 x 165 mm cutout 24 VDC supply, panel-mounting on 260 x 165 mm cutout 290 W x 190 H x 63.1 D mm bezel; weight about 1.7 kg unpacked
Compatible controllers and sibling SKUs are listed in the related products row below.
Key Features
- 24 VDC supply, panel-mounting on 260 x 165 mm cutout
- 290 W x 190 H x 63.1 D mm bezel; weight about 1.7 kg unpacked
- NA5-V1-series 9.0-inch widescreen Sysmac HMI panel
- IP65 front panel only (panel-face protection; rear IP20)
- SKU: NA5-9W001B-V1
- Series: Omron NA5-V1 Sysmac HMI
Best-Fit Applications
- Spare-panel upgrade on a panel that already runs a 7-inch NB7W and needs a wider footprint without the 10-inch NB10W
- SCADA-adjacent panel on an inline test rig with NJ-series ladder to HMI tag polling
- Operator screen for a multi-axis packaging machine driven by an NJ or NX motion controller
Buying Checklist
- Pick the NA5-9W001S-V1 instead when the cabinet wants a SILVER frame (the S suffix).
- Pick the NA5-12W101B-V1 instead when the build needs a larger 12.1-inch 1280 x 800 panel.
- Pick the NA5-7W001B-V1 instead for a smaller 7-inch panel on the same NA-V1 platform (same 800 x 480 resolution).
Technical Specifications
| Series | Omron NA5-V1 Sysmac HMI |
|---|---|
| Model | NA5-9W001B-V1 |
| Display | 9.0-inch widescreen TFT color LCD, 800 x 480 WVGA |
| Color Depth | 16,777,216 colors (24-bit) |
| Touch | Projected capacitive, multi-touch capable |
| Communication | 2 x 10/100 Base-TX Ethernet + 3 x USB + 1 x RS-232 + 1 x SD card slot |
| Frame | Black frame, metal chassis (B suffix; -P is the resin variant) |
| Front Protection | IP65 panel face only |
| Supply | 24 VDC |
| Dimensions | 290 W x 190 H x 63.1 D mm bezel, 260 x 165 mm panel cutout |
| Weight | About 1.7 kg unpacked |
| Programming | Sysmac Studio with NA-V1 device profile and IAG library |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NA5-9W001B-V1
What is the difference between NA5-9W001B-V1 and NB7W-TW01B-V1?
Display class and platform depth. The NA5-9W001B-V1 is the Sysmac platform HMI: 9-inch widescreen, 16.77-million-color 24-bit display, dual Ethernet, and Sysmac Studio programming under the NA-V1 device profile. The NB7W-TW01B-V1 is the NB-series 7-inch WVGA panel: 65,536 colors, NB-Designer drag-and-drop, runs with CP / CJ / NJ / NX controllers on a simpler programming environment. Pick the NA5 when the page design needs 24-bit color and a Sysmac Studio project; pick the NB7W when the build budget is tighter and the simpler NB-Designer covers the scope.
How many colors does the NA5-9W001B-V1 show?
16.77 million colors (24-bit color depth). The NA5 family is the 24-bit-color Sysmac HMI; the NB family is 65,536-color (16-bit) entry-level panel. The 65K-color figure that previously appeared on this page was a holdover from an NB-series spec.
What controllers does the NA5-9W001B-V1 talk to?
NJ and NX series machine automation controllers on the Sysmac platform, over EtherNet/IP tag data links (FINS / TCP for legacy FINS / UDP units), plus RS-232 serial for any Modbus RTU / Host Link third-party device. CX-One / Sysmac Studio at V1.20 or later is the programming environment. The NA5 cannot talk to the older CS1 / CJ1 series directly via the Sysmac Studio project -- program those from CX-Designer and use the OMRON industrial monitor family if a 9-inch wide display is needed on legacy CS / CJ builds.
Will the NA5-9W001B-V1 still be available after 2026?
Production of this SKU is scheduled to end on 2026-09-30 per the official Omron product page at industrial.omron.de. After that date, orders flow through existing stock only. For a project that sails past 2026, step up to the NA5-12W101B-V1 12.1-inch 1280 x 800 panel (production ended 30 September 2026; the -V2 is the live line), or to the NA5-9W001S-V1 silver-frame variant if the panel color is the only change.
