Omron NA5-7W001B-V1 — 7-Inch NA HMI, 800x480, Black
SKU: NA5-7W001B-V1USD 1038.00
Omron NA5-7W001B-V1 7-inch NA-series HMI, 800x480 WVGA, 16.7M colors, 2 Ethernet + 3 USB, black metal bezel. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NA5-7W001B-V1 is a 7-inch wide-screen HMI in the NA-series Sysmac terminal family, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the Sysmac Studio or NB-Designer project file on a USB drive included.
The display is a 7-inch TFT LCD at 800 x 480 (WVGA) with 16,770,000 colors (24-bit full color). The front face is rated IP65 against panel-mount dust and water spray. Communication ports are 2 Ethernet, 3 USB, and 1 RS-232C. Frame color is black with a metal case.
Front bezel is 236 x 165 mm and the panel cutout is 196 x 140 mm. Built-in depth behind the panel is 63.1 mm. Weight is 1300 g. Programming runs in Sysmac Studio and the project can share NJ / NX / NY controller tags directly. For a 9-inch panel with the same 800 x 480 resolution, pick the NA5-9W001B-V1. For a 12.1-inch WXGA panel, pick the NA5-12W101B-V1. For a silver bezel, pick the NA5-7W001S-V1.
Key Features
- 7-inch wide-screen TFT LCD at 800 x 480 (WVGA), 16,770,000 colors (24-bit full color)
- 2 Ethernet + 3 USB + 1 RS-232C port, IP65 front face, black metal bezel
- Shares NJ / NX / NY controller tags directly through Sysmac Studio
- Front bezel 236 x 165 mm, panel cutout 196 x 140 mm, built-in depth 63.1 mm, 1300 g
- SKU: NA5-7W001B-V1
- Series: Omron NA-series Programmable Terminal (-V1)
Best-Fit Applications
- Operator panel on a small packaging machine wired to an NJ101-1000 controller over Ethernet cable
- Spare HMI replacement on an existing NA-series line where the previous panel failed and the cutout is 196 x 140 mm
- Secondary status display on a Sysmac cell where the primary HMI is a 12-inch NA5-12W101B-V1 and a smaller local readout is needed
Buying Checklist
- Pick the NA5-7W001B-V1 for a 7-inch 800 x 480 NA-series HMI with a black metal bezel.
- Pick the NA5-9W001B-V1 instead when the operator station needs a 9-inch panel at the same 800 x 480 resolution.
- Pick the NA5-7W001S-V1 instead when the cabinet calls for a silver bezel rather than black.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NA-series Programmable Terminal (-V1) |
| Model / SKU | NA5-7W001B-V1 |
| Display Size | 7-inch wide-screen TFT LCD |
| Resolution | 800 x 480 dots (WVGA) |
| Colors | 16,770,000 (24-bit full color) |
| Frame Color / Case | Black metal bezel |
| Communication Ports | 2 Ethernet, 3 USB, 1 RS-232C |
| Front Protection | IP65 |
| Programming Software | Sysmac Studio (NA-series runtime) |
| Front Bezel / Cutout | 236 x 165 mm front / 196 x 140 mm cutout |
| Dimensions / Weight | 63.1 mm built-in depth; 1300 g |
FAQ for NA5-7W001B-V1
What is the difference between NA5-7W001B-V1 and NB5Q-TW01B-V1?
Both are 7-inch class Omron HMIs, but the NA5 runs on Sysmac Studio and is the NA platform for NJ / NX / NY controllers; note the -V1 hardware ended production on 30 September 2026 and the -V2 is the current line. The NB5Q runs on NB-Designer and is the legacy CP / NJ line. The NA5 also has a wider 800 x 480 WVGA panel; the NB5Q is 320 x 240 QVGA on the 5.7-inch and 800 x 480 on the 7-inch.
Does the NA5-7W001B-V1 have Ethernet?
Yes. Two Ethernet ports are on the back. Port 1 connects to the controller and Port 2 connects to the plant network, supporting tag data links with NJ / NX / NY controllers.
What software programs the NA5-7W001B-V1?
Sysmac Studio, the same suite used for NJ / NX / NY controller programming. The project can share controller tags directly so screen objects update from live PLC variables without separate mapping.
