Omron NB10W-TW01B — 10.1" WVGA HMI, Ethernet, Black Bezel
SKU: NB10W-TW01BUSD 365.00
10.1-inch TFT colour touchscreen HMI, 800 × 480 WVGA resolution, 65,536 colours, LED backlight, Ethernet + 2 USB + 2 RS-232 + RS-422/485, IP65 front, NB-Designer programming, 24 VDC supply, black bezel.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The NB10W-TW01B is the 10.1-inch model of Omron's NB-series programmable terminals, the most popular mid-size HMI in the line between the 7-inch NB7W and the discontinued 12-inch NS series. It pairs a 10.1-inch WVGA TFT colour LCD (800 × 480, 65,536 simultaneous colours) with a matrix-resistive touch overlay, 50,000-hour LED backlight, and a built-in 10/100 Base-TX Ethernet port for connection to a CJ2, NJ, NX, or CP1H PLC over EtherNet/IP or FINS.
How the NB10W compares to the rest of the NB family
The NB series covers four screen sizes: NB3Q (3.5 inch 320 × 240), NB5Q (5.6 inch 320 × 234), NB7W (7 inch 800 × 480), and NB10W (10.1 inch 800 × 480) — with -TW00B being the no-Ethernet variant and -TW01B being the Ethernet + USB Host variant. Pick the NB10W-TW01B for 10-inch panels where you need a larger operating area than the 7-inch NB7W without going to a 12-inch NA5 widescreen.
Application in a typical machine
The NB10W-TW01B sits in the operator panel of a packaging line, an assembly cell, or a process skid, with the Ethernet port connecting to the machine's NJ or NX controller. Up to 32 host devices can be registered, so a single HMI can poll multiple controllers and present a unified view. The 60 MB screen memory is enough for thousands of pages and tens of thousands of tags. Operator workflows — recipe selection, parameter editing, alarm acknowledgement, manual jog — are all drag-and-drop objects in NB-Designer, with simulated runtime on the development PC for off-line testing before the project is downloaded to the HMI.
Key Features
- 10.1-inch TFT colour LCD, 800 × 480 resolution
- 65,536 simultaneous colours, LED backlight
- Analog resistive touch screen, IP65 front face
- Built-in 10/100 Base-TX Ethernet port
- 2 × RS-232C + 1 × RS-422 + 1 × RS-485 serial ports
- 2 × USB ports
- 24 VDC supply, low power consumption
- Black bezel, 24 VDC supply, IP65 front protection
- SKU: NB10W-TW01B
- Series: NB (Programmable Terminal)
- Voltage: 24 VDC
Best-Fit Applications
- Operator panel on a packaging line with recipe management and alarm logs
- Machine status dashboard on an assembly cell with multi-host polling
- Process HMI at the central station of a water-treatment skid with trend graphs
- Parameter editor on a test stand with user-level access control
Buying Checklist
- Pick NB10W-TW01B for 10.1-inch 800 × 480 HMI with Ethernet and black bezel
- Pick NB10W-TW00B if you do not need Ethernet
- Pick NB7W-TW01B for a 7-inch panel when 10 inches is too large for the cabinet
- Consider NA5-9W001B-V1 or NA5-12W101B-V1 for new designs — NB series discontinued March 2025
- Download NB-Designer free from Omron; supports simulated runtime on PC for off-line testing
- Use a USB memory stick for recipe transfer between machines without a network
Technical Specifications
| Model | NB10W-TW01B |
|---|---|
| Series | NB (Programmable Terminal) |
| Type | TFT colour touchscreen HMI |
| Display Size | 10.1 inch diagonal |
| Resolution | 800 × 480 (WVGA) |
| Number of Colors | 65,536 |
| Backlight | LED, 50,000 hours at 25 °C |
| Touch Panel | Analog resistive membrane |
| Touch Resolution | 1024 × 1024 |
| Supply Voltage | 24 VDC |
| Operating Temperature | 0 to +50 °C |
| Certifications | UL, CSA, CE, KC |
Resources & Downloads
FAQ for NB10W-TW01B
What is the difference between NB10W-TW01B and NB10W-TW00B?
The TW01B variant includes the built-in 10/100 Base-TX Ethernet port for connection to NJ / NX controllers over EtherNet/IP or FINS. The TW00B variant has no Ethernet and connects to the PLC only through RS-232C / RS-422 / RS-485 serial. If you need Ethernet, alarm e-mail, or web server features, pick the TW01B.
Is the NB10W-TW01B still in production?
The NB series has been moved to Omron's product discontinuation list, with production of the NB10W-TW01B ending March 2025. Existing stock remains available through authorised distributors like Hengyixin for service and expansion of installed lines, but new long-life-cycle designs should evaluate the NA5-9W001B-V1 (9 inch widescreen) or NA5-12W101B-V1 (12 inch 1280 × 800) as the recommended replacements.
What programming software does the NB10W-TW01B use?
NB-Designer, free download from Omron. NB-Designer supports drag-and-drop Smart Components for alarms, trends, recipes, and ladder-monitor I/O display, plus simulated runtime on the development PC for off-line testing. Projects can be downloaded over Ethernet, USB, or serial. CX-Designer is the older tool for the NS series and is not used for the NB.
Can the NB10W-TW01B connect to a CP1H or CP1L PLC?
Yes — via the RS-232C port using Host Link (CP1H supports Host Link natively; CP1L needs the CP1W-CIF01 RS-232C option board). For Ethernet connection, the CP1H and CP1L do not have built-in Ethernet, so use a CP1W-CIF41 Ethernet option board and connect to the NB10W-TW01B over FINS / TCP. For modern installations, the NJ501 or NX102 controller with built-in Ethernet is the more common pairing.
